GL.iNet GL-MT3600BE

The GL-MT3600BE Beryl 7 travel router is based on MediaTek Filogic 850 (MT7987A) SoC with dual-band 2×2 WiFi-7, 1x 2.5Gbit WAN, 1x 2.5Gbit LAN, 512MB DDR4 RAM, 512MB NAND flash storage, and 1x USB 3.0 port.

Status of OpenWrt support :

Currently Stable release 25.12.5 & Nightly Snapshot build are working.
mt76 driver wireless performance & stability on MT7990 WLAN hardware needs further optimization & improvement.
See more in comments in below GitHub issues:
- (Merged) OpenWrt PR# 22476 (Main Snapshot)
- (Merged) OpenWrt PR# 23368 (25.12 branch)
- mt7990 WLAN performance problem in mt76 Issue #1065 & mt76 Issue #1043
- OpenWrt Forum: Beryl7: fixed the broken TX path on the MT7990

The GL-MT3600BE ships with a modified fork of OpenWrt. To install official OpenWrt simply flash a sysupgrade image. DO NOT use a factory image.

Installation from the GL-iNet web UI

Download the latest sysupgrade image for GL-MT3600BE from Firmware Selector.
Use an Ethernet cable to connect to one of the router's LAN ports.
Browse to the GL.iNet web interface, default IP is 192.168.8.1.
Go to the Upgrade page and drag in your downloaded sysupgrade image. When prompted, select Do not keep configuration.
This will flash and reboot the router into OpenWrt, default IP address is now 192.168.1.1.
After flashing, OpenWrt can be configured as described in the Quick Start guide.

Snapshots do not include the LuCI web interface by default

If you are flashing a nightly Snapshot build, it does not include the LuCI web interface by default. You will need to install LuCI first, then access 192.168.1.1 via a web browser.

On snapshots, LuCI has to be installed if desired.
To install LuCI, follow the LuCI installation guide but using APK.

Architecture	ARM64
Vendor	MediaTek
Bootloader	U-Boot
System-On-Chip	MediaTek MT7987A 4x A53
CPU/Speed	2000 MHz
Flash size	512 MiB SPI-NAND
RAM	512 MiB DDR4
Wireless	MediaTek MT7987AV, MediaTek MT7976CN, 2.4GHz b/g/n/ax/be, 5GHz a/n/ac/ax/be
Ethernet	2x 2.5GbE (built-in + RTL8221B)
USB	1x 3.0
Serial	Yes
JTAG	Not populated

Remove the rubber feet and screws. Use a plastic pry tool to separate the case starting on the rear notch.

→ port.serial general information about the serial port, serial port cable, etc.

How to connect to the Serial Port of this specific device:

Serial connection parameters for GL.iNet GL-MT3600BE (Beryl 7)	115200, 8N1, 3.3V

The serial port is located on the same side of the PCB as the LED lights.

→ port.jtag general information about the JTAG port, JTAG cable, etc.

No JTAG pads on the PCB, but there is SDA & SCL for I2C control.

SPI flash pads are present and supported via the GL.iNet SPI/JTAG tile board. This is not CPU JTAG — it is flash‑level access for reprogramming U‑Boot or NAND.

[ 0.000000] Booting Linux on physical CPU 0x0000000000 [0x410fd034] [ 0.000000] Linux version 5.4.281 (xinxing@gl-System-Product-Name) (gcc version 8.4.0 (OpenWrt GCC 8.4.0 )) #0 SMP Wed Apr 15 14:00:44 2026 [ 0.000000] Machine model: GL.iNet GL-MT3600BE [ 0.000000] earlycon: uart8250 at MMIO32 0x0000000011000000 (options '') [ 0.000000] printk: bootconsole [uart8250] enabled [ 0.000000] On node 0 totalpages: 130752 [ 0.000000] DMA32 zone: 2047 pages used for memmap [ 0.000000] DMA32 zone: 0 pages reserved [ 0.000000] DMA32 zone: 130752 pages, LIFO batch:31 [ 0.000000] psci: probing for conduit method from DT. [ 0.000000] psci: PSCIv1.1 detected in firmware. [ 0.000000] psci: Using standard PSCI v0.2 function IDs [ 0.000000] psci: MIGRATE_INFO_TYPE not supported. [ 0.000000] psci: SMC Calling Convention v1.0 [ 0.000000] percpu: Embedded 20 pages/cpu s44760 r8192 d28968 u81920 [ 0.000000] pcpu-alloc: s44760 r8192 d28968 u81920 alloc=20*4096 [ 0.000000] pcpu-alloc: [0] 0 [0] 1 [0] 2 [0] 3 [ 0.000000] Detected VIPT I-cache on CPU0 [ 0.000000] CPU features: detected: GIC system register CPU interface [ 0.000000] CPU features: kernel page table isolation disabled by kernel configuration [ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 128705 [ 0.000000] Kernel command line: console=ttyS0,115200n1 loglevel=8 earlycon=uart8250,mmio32,0x11000000 pci=pcie_bus_perf [ 0.000000] Dentry cache hash table entries: 65536 (order: 7, 524288 bytes, linear) [ 0.000000] Inode-cache hash table entries: 32768 (order: 6, 262144 bytes, linear) [ 0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off [ 0.000000] Memory: 492376K/523008K available (7934K kernel code, 644K rwdata, 2524K rodata, 448K init, 308K bss, 30632K reserved, 0K cma-reserved) [ 0.000000] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=4, Nodes=1 [ 0.000000] rcu: Hierarchical RCU implementation. [ 0.000000] rcu: CONFIG_RCU_FANOUT set to non-default value of 32. [ 0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 25 jiffies. [ 0.000000] NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0 [ 0.000000] GICv3: GIC: Using split EOI/Deactivate mode [ 0.000000] GICv3: 640 SPIs implemented [ 0.000000] GICv3: 0 Extended SPIs implemented [ 0.000000] GICv3: Distributor has no Range Selector support [ 0.000000] GICv3: 16 PPIs implemented [ 0.000000] GICv3: no VLPI support, no direct LPI support [ 0.000000] GICv3: CPU0: found redistributor 0 region 0:0x000000000c080000 [ 0.000000] arch_timer: cp15 timer(s) running at 13.00MHz (phys). [ 0.000000] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x2ff89eacb, max_idle_ns: 440795202429 ns [ 0.000002] sched_clock: 56 bits at 13MHz, resolution 76ns, wraps every 4398046511101ns [ 0.008201] Calibrating delay loop (skipped), value calculated using timer frequency.. 26.00 BogoMIPS (lpj=52000) [ 0.018524] pid_max: default: 32768 minimum: 301 [ 0.023234] Mount-cache hash table entries: 1024 (order: 1, 8192 bytes, linear) [ 0.030587] Mountpoint-cache hash table entries: 1024 (order: 1, 8192 bytes, linear) [ 0.039188] ASID allocator initialised with 65536 entries [ 0.044669] rcu: Hierarchical SRCU implementation. [ 0.049782] smp: Bringing up secondary CPUs ... [ 0.054594] Detected VIPT I-cache on CPU1 [ 0.054612] GICv3: CPU1: found redistributor 1 region 0:0x000000000c0a0000 [ 0.054632] CPU1: Booted secondary processor 0x0000000001 [0x410fd034] [ 0.054901] Detected VIPT I-cache on CPU2 [ 0.054910] GICv3: CPU2: found redistributor 2 region 0:0x000000000c0c0000 [ 0.054919] CPU2: Booted secondary processor 0x0000000002 [0x410fd034] [ 0.055150] Detected VIPT I-cache on CPU3 [ 0.055157] GICv3: CPU3: found redistributor 3 region 0:0x000000000c0e0000 [ 0.055165] CPU3: Booted secondary processor 0x0000000003 [0x410fd034] [ 0.055192] smp: Brought up 1 node, 4 CPUs [ 0.111783] SMP: Total of 4 processors activated. [ 0.116509] CPU features: detected: 32-bit EL0 Support [ 0.121672] CPU features: detected: CRC32 instructions [ 0.126927] CPU: All CPU(s) started at EL2 [ 0.131048] alternatives: patching kernel code [ 0.137874] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 7645041785100000 ns [ 0.147703] futex hash table entries: 1024 (order: 4, 65536 bytes, linear) [ 0.154704] pinctrl core: initialized pinctrl subsystem [ 0.160534] NET: Registered protocol family 16 [ 0.165199] DMA: preallocated 256 KiB pool for atomic allocations [ 0.172305] printk: console [pstore-1] enabled [ 0.176835] pstore: Registered ramoops as persistent store backend [ 0.183052] ramoops: using 0x10000@0x5ffb0000, ecc: 0 [ 0.189740] GPIO line 498 (pcie1pereset) hogged as output/high [ 0.202526] cryptd: max_cpu_qlen set to 1000 [ 0.208656] SCSI subsystem initialized [ 0.212642] libata version 3.00 loaded. [ 0.216694] usbcore: registered new interface driver usbfs [ 0.222230] usbcore: registered new interface driver hub [ 0.227585] usbcore: registered new device driver usb [ 0.232672] videodev: Linux video capture interface: v2.00 [ 0.238204] pps_core: LinuxPPS API ver. 1 registered [ 0.243195] pps_core: Software ver. 5.3.6 - Copyright 2005-2007 Rodolfo Giometti <giometti@linux.it> [ 0.252387] PTP clock support registered [ 0.257053] Bluetooth: Core ver 2.22 [ 0.260675] NET: Registered protocol family 31 [ 0.265137] Bluetooth: HCI device and connection manager initialized [ 0.271527] Bluetooth: HCI socket layer initialized [ 0.276429] Bluetooth: L2CAP socket layer initialized [ 0.281510] Bluetooth: SCO socket layer initialized [ 0.286703] clocksource: Switched to clocksource arch_sys_counter [ 0.293385] thermal_sys: Registered thermal governor 'step_wise' [ 0.293388] thermal_sys: Registered thermal governor 'user_space' [ 0.299799] NET: Registered protocol family 2 [ 0.310383] IP idents hash table entries: 8192 (order: 4, 65536 bytes, linear) [ 0.318544] tcp_listen_portaddr_hash hash table entries: 256 (order: 0, 4096 bytes, linear) [ 0.327039] TCP established hash table entries: 4096 (order: 3, 32768 bytes, linear) [ 0.334843] TCP bind hash table entries: 4096 (order: 4, 65536 bytes, linear) [ 0.342055] TCP: Hash tables configured (established 4096 bind 4096) [ 0.348506] mptcp init [ 0.348544] MPTCP token hash table entries: 512 (order: 1, 12288 bytes, linear) [ 0.358287] UDP hash table entries: 256 (order: 1, 8192 bytes, linear) [ 0.364858] UDP-Lite hash table entries: 256 (order: 1, 8192 bytes, linear) [ 0.371938] NET: Registered protocol family 1 [ 0.376331] PCI: CLS 0 bytes, default 64 [ 0.382420] workingset: timestamp_bits=46 max_order=17 bucket_order=0 [ 0.391195] squashfs: version 4.0 (2009/01/31) Phillip Lougher [ 0.397072] jffs2: version 2.2 (NAND) (SUMMARY) (LZMA) (RTIME) (CMODE_PRIORITY) (c) 2001-2006 Red Hat, Inc. [ 0.428061] Debug interface error [ 0.431501] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 246) [ 0.439449] phy phy-soc:usb-phy@11c50000.1: type_sw - reg 0x218, index 0 [ 0.446532] gpio-export gpio-export: 1 gpio(s) exported [ 0.452247] mtk-pcie 11280000.pcie: host bridge /soc/pcie@11280000 ranges: [ 0.459172] mtk-pcie 11280000.pcie: Parsing ranges property... [ 0.465046] mtk-pcie 11280000.pcie: IO 0x20000000..0x201fffff -> 0x20000000 [ 0.472316] mtk-pcie 11280000.pcie: MEM 0x20200000..0x2fffffff -> 0x20200000 [ 0.479616] mtk-pcie 11280000.pcie: failed to get max link width [ 0.711882] mtk-pcie 11280000.pcie: PCI host bridge to bus 0000:00 [ 0.718106] pci_bus 0000:00: root bus resource [bus 00-ff] [ 0.723622] pci_bus 0000:00: root bus resource [io 0x0000-0x1fffff] (bus address [0x20000000-0x201fffff]) [ 0.733333] pci_bus 0000:00: root bus resource [mem 0x20200000-0x2fffffff] [ 0.740247] pci_bus 0000:00: scanning bus [ 0.744292] pci 0000:00:00.0: [14c3:7987] type 01 class 0x060400 [ 0.750358] pci 0000:00:00.0: reg 0x10: [mem 0x00000000-0x00007fff 64bit] [ 0.757254] pci 0000:00:00.0: PME# supported from D0 D3hot D3cold [ 0.763383] pci 0000:00:00.0: PME# disabled [ 0.768551] pci_bus 0000:00: fixups for bus [ 0.772759] pci 0000:00:00.0: scanning [bus 00-00] behind bridge, pass 0 [ 0.779497] pci 0000:00:00.0: bridge configuration invalid ([bus 00-00]), reconfiguring [ 0.787553] pci 0000:00:00.0: scanning [bus 00-00] behind bridge, pass 1 [ 0.794348] pci_bus 0000:01: scanning bus [ 0.798398] pci 0000:01:00.0: [14c3:7993] type 00 class 0x028000 [ 0.804490] pci 0000:01:00.0: reg 0x10: [mem 0x00000000-0x001fffff 64bit] [ 0.811335] pci 0000:01:00.0: reg 0x18: [mem 0x00000000-0x00007fff 64bit] [ 0.818313] pci 0000:01:00.0: PME# supported from D0 D3hot D3cold [ 0.824442] pci 0000:01:00.0: PME# disabled [ 0.839524] pci_bus 0000:01: fixups for bus [ 0.843734] pci_bus 0000:01: bus scan returning with max=01 [ 0.849338] pci_bus 0000:01: busn_res: [bus 01-ff] end is updated to 01 [ 0.855991] pci_bus 0000:00: bus scan returning with max=01 [ 0.861607] pci 0000:00:00.0: BAR 8: assigned [mem 0x20200000-0x204fffff] [ 0.868433] pci 0000:00:00.0: BAR 0: assigned [mem 0x20500000-0x20507fff 64bit] [ 0.875792] pci 0000:01:00.0: BAR 0: assigned [mem 0x20200000-0x203fffff 64bit] [ 0.883157] pci 0000:01:00.0: BAR 2: assigned [mem 0x20400000-0x20407fff 64bit] [ 0.890522] pci 0000:00:00.0: PCI bridge to [bus 01] [ 0.895514] pci 0000:00:00.0: bridge window [mem 0x20200000-0x204fffff] [ 0.902355] pci 0000:00:00.0: Max Payload Size set to 256/ 256 (was 128), Max Read Rq 256 [ 0.910862] pci 0000:01:00.0: Max Payload Size set to 256/ 256 (was 128), Max Read Rq 256 [ 0.919431] pcieport 0000:00:00.0: assign IRQ: got 79 [ 0.924517] pcieport 0000:00:00.0: enabling device (0000 -> 0002) [ 0.930653] pcieport 0000:00:00.0: enabling bus mastering [ 0.936835] pcieport 0000:00:00.0: PME: Signaling with IRQ 80 [ 0.943487] Serial: 8250/16550 driver, 16 ports, IRQ sharing enabled [ 0.951383] printk: console [ttyS0] disabled [ 0.975815] 11000000.serial: ttyS0 at MMIO 0x11000000 (irq = 59, base_baud = 2500000) is a ST16650V2 [ 0.985030] printk: console [ttyS0] enabled [ 0.993392] printk: bootconsole [uart8250] disabled [ 1.003638] mtk_rng soc:trng@1020f000: registered RNG driver [ 1.003667] random: crng init done [ 1.012976] Loading iSCSI transport class v2.0-870. [ 1.020558] spi-nand spi1.0: calibration result: 0x2 [ 1.026274] spi-nand spi1.0: CASN page check failed [ 1.031162] spi-nand spi1.0: Fallback to read ID [ 1.035863] spi-nand spi1.0: Macronix SPI NAND was found. [ 1.041260] spi-nand spi1.0: 512 MiB, block size: 256 KiB, page size: 4096, OOB size: 128 [ 1.052287] [mtk_hw_init] reset_lock:0, force:0 [ 1.056940] [mtk_hw_init] execute fe cold reset [ 1.072476] mtk_soc_eth 15100000.ethernet: MDC is running on 2500000 Hz [ 1.456497] MediaTek MT7987 2.5GbE PHY mdio-bus:0f: Firmware date code: 2025/8/22, version: 7.1.0 [ 1.477153] mtk_soc_eth 15100000.ethernet: generated random MAC address f6:2f:61:5d:58:95 [ 1.485888] mtk_soc_eth 15100000.ethernet eth0: mediatek frame engine at 0xffffffc011f00000, irq 71 [ 1.494968] mtk_soc_eth 15100000.ethernet: generated random MAC address a6:74:d2:b7:10:bb [ 1.503655] mtk_soc_eth 15100000.ethernet eth1: mediatek frame engine at 0xffffffc011f00000, irq 71 [ 1.512701] (unnamed net_device) (dummy): netif_napi_add() called with weight 256 [ 1.520464] mtk_soc_eth 15100000.ethernet: DMA Monitor is running ! (v1.1.0) [ 1.527626] usbcore: registered new interface driver r8152 [ 1.533122] usbcore: registered new interface driver ax88179_178a [ 1.539356] xhci-mtk 11200000.xhci: 11200000.xhci supply vbus not found, using dummy regulator [ 1.547984] xhci-mtk 11200000.xhci: 11200000.xhci supply vusb33 not found, using dummy regulator [ 1.556881] phy phy-soc:usb-phy@11c50000.0: try to get sw efuse [ 1.562793] phy phy-soc:usb-phy@11c50000.0: try to get sw efuse+ [ 1.568804] phy phy-soc:usb-phy@11c50000.0: u2 auto load valid efuse: ENABLE with value: 1 [ 1.577060] phy phy-soc:usb-phy@11c50000.0: u2 efuse - intr 13 [ 1.582888] phy phy-soc:usb-phy@11c50000.1: try to get sw efuse [ 1.588797] phy phy-soc:usb-phy@11c50000.1: try to get sw efuse+ [ 1.594799] phy phy-soc:usb-phy@11c50000.1: u3 auto load valid efuse: ENABLE with value: 1 [ 1.603069] phy phy-soc:usb-phy@11c50000.1: u3 efuse - intr 0, rx_imp f, tx_imp d [ 1.610710] xhci-mtk 11200000.xhci: xHCI Host Controller [ 1.616022] xhci-mtk 11200000.xhci: new USB bus registered, assigned bus number 1 [ 1.626482] xhci-mtk 11200000.xhci: hcc params 0x01443f99 hci version 0x120 quirks 0x0000000020210010 [ 1.635725] xhci-mtk 11200000.xhci: irq 63, io mem 0x11200000 [ 1.641535] xhci-mtk 11200000.xhci: xHCI Host Controller [ 1.646841] xhci-mtk 11200000.xhci: new USB bus registered, assigned bus number 2 [ 1.654319] xhci-mtk 11200000.xhci: Host supports USB 3.2 Enhanced SuperSpeed [ 1.661740] hub 1-0:1.0: USB hub found [ 1.665515] hub 1-0:1.0: 1 port detected [ 1.669624] usb usb2: We don't know the algorithms for LPM for this host, disabling LPM. [ 1.677911] hub 2-0:1.0: USB hub found [ 1.681669] hub 2-0:1.0: 1 port detected [ 1.685935] usbcore: registered new interface driver uas [ 1.691296] usbcore: registered new interface driver usb-storage [ 1.697410] i2c /dev entries driver [ 1.701868] mtk-soc-temp-lvts 1100a000.lvts: [lvts_cal] golden_temp = 60 [ 1.708574] mtk-soc-temp-lvts 1100a000.lvts: [lvts_cal] num:g_count:g_count_rc 0:19527:5497 1:19590:0 [ 1.718515] mtk-soc-temp-lvts 1100a000.lvts: [COUNT_RC_NOW] 0:5508 1:5516 [ 1.725405] mtk-soc-temp-lvts 1100a000.lvts: set_polling_speed 0, LVTSMONCTL1_0= 0x10000c,LVTSMONCTL2_0= 0x10001 [ 1.735571] mtk-soc-temp-lvts 1100a000.lvts: set_hw_filter 0, LVTSMSRCTL0_0= 0xb6d [ 1.743130] mtk-soc-temp-lvts 1100a000.lvts: lvts0: read all 2 sensors in 5040 us, one in 2404 us [ 1.751990] mtk-soc-temp-lvts 1100a000.lvts: set_tc_hw_reboot_threshold: LVTS0, the dominator sensing point= 4 [ 1.762411] mtk-wdt 1001c000.watchdog: Watchdog enabled (timeout=31 sec, nowayout=0) [ 1.770353] device-mapper: ioctl: 4.41.0-ioctl (2019-09-16) initialised: dm-devel@redhat.com [ 1.778872] Bluetooth: HCI UART driver ver 2.3 [ 1.783311] Bluetooth: HCI UART protocol H4 registered [ 1.788444] Bluetooth: HCI UART protocol BCSP registered [ 1.793745] Bluetooth: HCI UART protocol ATH3K registered [ 1.799209] Bluetooth: HCI UART protocol Broadcom registered [ 1.804870] Bluetooth: HCI UART protocol QCA registered [ 1.810325] cpu cpu0: dummy supplies not allowed for exclusive requests [ 1.818578] NET: Registered protocol family 10 [ 1.823611] Segment Routing with IPv6 [ 1.827347] NET: Registered protocol family 17 [ 1.831817] Bridge firewalling registered [ 1.835882] 8021q: 802.1Q VLAN Support v1.8 [ 1.846198] nmbm nmbm_spim_nand: Signature found at block 2047 [0x1ffc0000] [ 1.854406] nmbm nmbm_spim_nand: First info table with writecount 0 found in block 1920 [ 1.866053] nmbm nmbm_spim_nand: Second info table with writecount 0 found in block 1923 [ 1.874146] nmbm nmbm_spim_nand: NMBM has been successfully attached [ 1.880728] 7 fixed-partitions partitions found on MTD device nmbm_spim_nand [ 1.887769] Creating 7 MTD partitions on "nmbm_spim_nand": [ 1.893249] 0x000000000000-0x000000100000 : "BL2" [ 1.898399] 0x000000100000-0x000000180000 : "u-boot-env" [ 1.904019] 0x000000180000-0x000000580000 : "Factory" [ 1.909346] 0x000000580000-0x000000780000 : "FIP" [ 1.914347] 0x000000780000-0x0000007c0000 : "log" [ 1.919349] 0x0000007c0000-0x000000800000 : "CFG" [ 1.924359] 0x000000800000-0x00001e000000 : "ubi" [ 1.930108] UBI: auto-attach mtd7 [ 1.933438] ubi0: attaching mtd7 [ 3.002372] ubi0: scanning is finished [ 3.010616] ubi0: attached mtd7 (name "ubi", size 472 MiB) [ 3.016105] ubi0: PEB size: 262144 bytes (256 KiB), LEB size: 253952 bytes [ 3.022969] ubi0: min./max. I/O unit sizes: 4096/4096, sub-page size 4096 [ 3.029746] ubi0: VID header offset: 4096 (aligned 4096), data offset: 8192 [ 3.036694] ubi0: good PEBs: 1888, bad PEBs: 0, corrupted PEBs: 0 [ 3.042777] ubi0: user volume: 3, internal volumes: 1, max. volumes count: 128 [ 3.049987] ubi0: max/mean erase counter: 6/3, WL threshold: 4096, image sequence number: 1755502931 [ 3.059105] ubi0: available PEBs: 0, total reserved PEBs: 1888, PEBs reserved for bad PEB handling: 38 [ 3.068401] ubi0: background thread "ubi_bgt0d" started, PID 942 [ 3.074979] block ubiblock0_1: created from ubi0:1(rootfs) [ 3.080463] ubiblock: device ubiblock0_1 (rootfs) set to be root filesystem [ 3.087419] hctosys: unable to open rtc device (rtc0) [ 3.092629] clk: Disabling unused clocks [ 3.099110] VFS: Mounted root (squashfs filesystem) readonly on device 253:0. [ 3.106407] Freeing unused kernel memory: 448K [ 3.126737] Run /sbin/init as init process [ 3.279011] init: Console is alive [ 3.282500] init: - watchdog - [ 3.841429] kmodloader: loading kernel modules from /etc/modules-boot.d/* [ 3.873023] install gl_hw_info [ 3.888555] loop: module loaded [ 3.892668] ehci_hcd: USB 2.0 'Enhanced' Host Controller (EHCI) Driver [ 3.900564] fsl-ehci: Freescale EHCI Host controller driver [ 3.906728] ehci-platform: EHCI generic platform driver [ 3.913345] ohci_hcd: USB 1.1 'Open' Host Controller (OHCI) Driver [ 3.920027] ohci-platform: OHCI generic platform driver [ 3.926027] uhci_hcd: USB Universal Host Controller Interface driver [ 3.934489] Loading modules backported from Linux version v6.5-0-g2dde18cd1d8f [ 3.941726] Backport generated by backports.git v5.15.92-1-56-g5fb2ccb6b9e8 [ 3.955236] mt_osal_proc:mt_osal_proc_init:196:mt_osal_proc_init loaded [ 3.957747] mediatek_soc_hnat 15100000.hnat: wan = eth0 [ 3.969619] mediatek_soc_hnat 15100000.hnat: lan = eth1 [ 3.974838] mediatek_soc_hnat 15100000.hnat: lan2 = none [ 3.980140] mediatek_soc_hnat 15100000.hnat: ppd = eth1 [ 3.985356] mediatek_soc_hnat 15100000.hnat: gmac num = 2 [ 3.990746] mediatek_soc_hnat 15100000.hnat: ppe num = 2 [ 3.996620] mediatek_soc_hnat 15100000.hnat: PPE0 entry number = 8192 [ 4.013602] mediatek_soc_hnat 15100000.hnat: PPE0 hwnat start [ 4.019684] mediatek_soc_hnat 15100000.hnat: PPE1 entry number = 8192 [ 4.036653] mediatek_soc_hnat 15100000.hnat: PPE1 hwnat start [ 4.042452] hnat roaming work enable [ 4.048344] warp_module_init(): module init and register callback for warp [ 4.055278] create warp_ctrl ok!!! [ 4.058802] wed_get_slot_map(): assign slot_id:0 for entry: 0! [ 4.065788] kmodloader: done loading kernel modules from /etc/modules-boot.d/* [ 4.083250] init: - preinit - [ 4.566756] mtk_soc_eth 15100000.ethernet eth0: PHY [mdio-bus:07] driver [RTL8221B-VB-CG 2.5Gbps PHY (C45)] [ 4.576504] mtk_soc_eth 15100000.ethernet eth0: configuring for phy/2500base-x link mode [ 8.686453] mount_root: loading kmods from internal overlay [ 8.701291] kmodloader: loading kernel modules from //etc/modules-boot.d/* [ 8.709784] kmodloader: done loading kernel modules from //etc/modules-boot.d/* [ 9.872298] UBIFS (ubi0:2): Mounting in unauthenticated mode [ 9.878020] UBIFS (ubi0:2): background thread "ubifs_bgt0_2" started, PID 1099 [ 9.913365] UBIFS (ubi0:2): recovery needed [ 10.025344] UBIFS (ubi0:2): recovery completed [ 10.029838] UBIFS (ubi0:2): UBIFS: mounted UBI device 0, volume 2, name "rootfs_data" [ 10.037659] UBIFS (ubi0:2): LEB size: 253952 bytes (248 KiB), min./max. I/O unit sizes: 4096 bytes/4096 bytes [ 10.047561] UBIFS (ubi0:2): FS size: 394387456 bytes (376 MiB, 1553 LEBs), journal size 19808256 bytes (18 MiB, 78 LEBs) [ 10.058416] UBIFS (ubi0:2): reserved for root: 4952683 bytes (4836 KiB) [ 10.065022] UBIFS (ubi0:2): media format: w5/r0 (latest is w5/r0), UUID 682E2E95-5965-4AEC-BB7B-474FB8398FAF, small LPT model [ 10.078213] block: attempting to load /tmp/ubifs_cfg/upper/etc/config/fstab [ 10.091715] block: extroot: not configured [ 10.095912] UBIFS (ubi0:2): un-mount UBI device 0 [ 10.100620] UBIFS (ubi0:2): background thread "ubifs_bgt0_2" stops [ 10.109483] UBIFS (ubi0:2): Mounting in unauthenticated mode [ 10.115203] UBIFS (ubi0:2): background thread "ubifs_bgt0_2" started, PID 1102 [ 10.185744] UBIFS (ubi0:2): UBIFS: mounted UBI device 0, volume 2, name "rootfs_data" [ 10.193577] UBIFS (ubi0:2): LEB size: 253952 bytes (248 KiB), min./max. I/O unit sizes: 4096 bytes/4096 bytes [ 10.203479] UBIFS (ubi0:2): FS size: 394387456 bytes (376 MiB, 1553 LEBs), journal size 19808256 bytes (18 MiB, 78 LEBs) [ 10.214334] UBIFS (ubi0:2): reserved for root: 4952683 bytes (4836 KiB) [ 10.220939] UBIFS (ubi0:2): media format: w5/r0 (latest is w5/r0), UUID 682E2E95-5965-4AEC-BB7B-474FB8398FAF, small LPT model [ 10.236165] mount_root: loading kmods from internal overlay [ 10.249095] kmodloader: loading kernel modules from /tmp/overlay/upper/etc/modules-boot.d/* [ 10.258834] kmodloader: done loading kernel modules from /tmp/overlay/upper/etc/modules-boot.d/* [ 11.376329] block: attempting to load /tmp/ubifs_cfg/upper/etc/config/fstab [ 11.387843] block: extroot: not configured [ 11.393847] mount_root: switching to ubifs overlay [ 11.409348] urandom-seed: Seeding with /etc/urandom.seed [ 11.558224] procd: - early - [ 11.561181] procd: - watchdog - [ 12.103508] procd: - watchdog - [ 12.108742] procd: - ubus - [ 12.163162] procd: - init - [ 12.554083] mtdoops: MTD partition 5 not big enough for mtdoops [ 12.714268] urngd: v1.0.2 started. [ 13.001946] kmodloader: loading kernel modules from /etc/modules.d/* [ 13.016762] ntfs: driver 2.1.32 [Flags: R/O MODULE]. [ 13.024830] DNS Mark module loaded [ 13.030366] OpenVPN data channel offload (ovpn-dco) 2.0.0 -- (C) 2020- OpenVPN, Inc. [ 13.039342] tun: Universal TUN/TAP device driver, 1.6 [ 13.820874] mt_wifi: module license 'Proprietary' taints kernel. [ 13.826911] Disabling lock debugging due to kernel taint [ 13.870916] physical_device_init! [ 13.874302] ser_mngr_init() [ 13.875362] wmcpu-reserved: erase: phy(0x0000000050000000), vir(ffffffc013700000-ffffffc013800000)(size=0x100000) [ 13.896156] mtk_hwifi: module uses symbols from proprietary module mt_wifi, inheriting taint. [ 13.906592] connac_if: module uses symbols from proprietary module mt_wifi, inheriting taint. [ 13.916142] mtk_pci: module uses symbols from proprietary module mtk_hwifi, inheriting taint. [ 13.926093] mtk_wed: module uses symbols from proprietary module mtk_hwifi, inheriting taint. [ 14.153456] mt7993: module uses symbols from proprietary module mtk_hwifi, inheriting taint. [ 14.163182] mt7993 0000:01:00.0: assign IRQ: got 79 [ 14.168135] mt7993 0000:01:00.0: enabling device (0000 -> 0002) [ 14.174131] mt7993 0000:01:00.0: enabling bus mastering [ 14.179367] mt7993 0000:01:00.0: Using 36bit DMA for streaming map [ 14.185574] mt7993 0000:01:00.0: Using 32bit DMA for coherent map [ 14.191672] mt7993 0000:01:00.0: connac_if_alloc_device() [ 14.197112] --> RTMPAllocAdapterBlock [ 14.201630] [ 14.201630] [ 14.201630] === pAd = 000000001342d740, size = 2481472 === [ 14.201630] [ 14.211933] <-- RTMPAllocAdapterBlock, Status=0 [ 14.216478] mt7993 0000:01:00.0: connac_if_alloc_device(): hw:000000000bfea2df, priv:000000007355eb0a, phy_size = 288 [ 14.228800] mtk_mat_tb_init(): tb_size 64, mem_size 576 [ 14.234313] mt7993_init_default()--> [ 14.237884] Use the default iPAiLNA bin image! [ 14.242326] <--mt7993_init_default() [ 14.245998] llget_profile_setting: dev_idx = 0! [ 14.250701] load l1profile succeed! [ 14.254250] BN0_profile_path: /etc/wireless/mediatek/mt7993.b0.dat [ 14.260462] BN1_profile_path: /etc/wireless/mediatek/mt7993.b1.dat [ 14.266738] E2pAccessMode=2 [ 14.269736] WHNAT=1 [ 14.272076] read_red_parms_from_file: RED_Enable --> 1 [ 14.277478] TestModeEn=0 [ 14.280288] rtmp_read_physical_device_parms: EDCCARegion:0 [ 14.286000] rtmp_read_physical_device_parms: PciL1ss:1 [ 14.291217] rtmp_read_physical_device_parms: LpOption=2:1, arg_len=3 [ 14.297722] rtmp_read_physical_device_parms: TpoEn=1 [ 14.303846] entry_table_init: PD_GET_HW_WTBL_MAX(device)=544 [ 14.311574] pause_bitmap_init: band_num=2, all_ac=68, per_ac=17, twt=18, pause=00000000a9839856, twt_pause=0000000073426ca3 [ 14.322700] pause[0]=00000000a685b939 [ 14.326349] twt_pause[0]=00000000483bb05e [ 14.330350] pause[1]=000000001de081f6 [ 14.334002] twt_pause[1]=000000004c2bd243 [ 14.338066] physical_device_add_main_device: add physical device obj 0000000053120dfc, device(=000000000f134cff), index(=0), chip=(0x7993)! [ 14.350577] mt7993 0000:01:00.0: connac_if_register_device_with_phy() [ 14.357047] physical_device_add_mac_adapter(): device(=000000000f134cff, index=0), mac_ad index(=0)! [ 14.366967] 7993@ERROR.HIF,ra0,hwifi_mcu_tx() 1557: send cmd fail! ret -22 [ 14.373883] invalid ctrl_info_ram_addr= 0x00000000, return [ 14.379417] mt7993 0000:01:00.0: connac_if_alloc_phy() [ 14.384557] --> RTMPAllocAdapterBlock [ 14.389210] [ 14.389210] [ 14.389210] === pAd = 000000004fc94e6c, size = 2481472 === [ 14.389210] [ 14.399566] <-- RTMPAllocAdapterBlock, Status=0 [ 14.404130] mt7993 0000:01:00.0: connac_if_alloc_phy(): hw:00000000397c342c, priv:00000000aecfa10d [ 14.413101] mt7993 0000:01:00.0: connac_if_register_device_with_phy() [ 14.419601] physical_device_add_mac_adapter(): device(=000000000f134cff, index=0), mac_ad index(=1)! [ 14.429617] 7993@ERROR.HIF,rai0,hwifi_mcu_tx() 1557: send cmd fail! ret -22 [ 14.436608] invalid ctrl_info_ram_addr= 0x00000000, return [ 14.442139] vendor: 14c3, device: 7993 [ 14.445907] subvendor: ffffffff, subdevice: ffffffff [ 14.450877] class: 0, class_mask: 0 [ 14.454364] driver_data : 0000000000000000 [ 14.458486] mt7993 0000:01:00.0: connac_if_start() [ 14.506746] warp_cap_support(): chip_id=7993 is in WHNAT support list [ 14.513236] warp_get_pcie_slot():domain_nr: 0 [ 14.517612] warp_entry_acquire(): bus slot:0, hook to WARP, entry id=0, entry: 00000000e2b1d9dd, slot_id:0 [ 14.527439] warp_entry_assign_by_pdev():prob success!return entry[0] [ 14.533826] warp_dev0 15010000.wed0: Using 36bit DMA for streaming map [ 14.540360] warp_dev0 15010000.wed0: Using 32bit DMA for coherent map [ 14.546846] wed_init(0): res_start = 0x0000000015010000[p], size = 2000, irq=64,base_addr=0xffffffc0112f2000 [ 14.557254] create wed ok!!! [ 14.565617] mt7993 0000:01:00.0: dump_chip_info(): chip id: 7993 [ 14.617531] wdma_dma_ctrl(): WDMA_GLO_CFG0=5a274, txrx = 3 [ 14.623052] mt7993 0000:01:00.0: mt7993_check_fwdl_state(): check target stat=1, cur state=1 [ 14.631824] mt7993 0000:01:00.0: HW/SW Version: 0x8a108a10, Build Time: 20250623123248a [ 14.631824] [ 14.651969] mt7993 0000:01:00.0: WM Firmware Version: ____000000, Build Time: 20250623123332, FW Mode: 0 [ 15.100255] mt7993 0000:01:00.0: mt7993_check_fwdl_state(): check target stat=3, cur state=3 [ 15.250630] mt7993_prek_preinit()--> [ 15.254255] <--mt7993_prek_preinit() [ 15.259200] SKU: #1.MT7993-BE3600-7976C [ 15.278208] SKU: #1.MT7993-BE3600-7976C [ 15.295998] 7993@ERROR.HW,ra0,cal_free_data_get() 1081: [ 17.199240] GACT probability on [ 17.203086] Mirror/redirect action on [ 17.209704] u32 classifier [ 17.212424] input device check on [ 17.216076] Actions configured [ 17.223611] fuse: init (API version 7.31) [ 17.229694] crypto-safexcel 15600000.crypto: EIP196:121(0,1,4,4)-HIA:282(0,6,6),PE:152/480(alg:7fc1ff00)/0/0/0 [ 17.246501] usbcore: registered new interface driver cdc_acm [ 17.252175] cdc_acm: USB Abstract Control Model driver for USB modems and ISDN adapters [ 17.260826] usbcore: registered new interface driver cdc_ether [ 17.267526] usbcore: registered new interface driver cdc_ncm [ 17.273847] usbcore: registered new interface driver cdc_wdm [ 17.281538] usbcore: registered new interface driver huawei_cdc_ncm [ 17.289922] usbcore: registered new interface driver ipheth [ 17.299605] Current mapfilter version v3.0.1.2 [ 17.304862] -->mtfwd_init(ver:2.0) [ 17.304896] <-- [ 17.309306] -->mtqos_init(), mtqos ver:1.0 [ 17.311135] <-- [ 17.337732] usbcore: registered new interface driver qmi_wwan [ 17.344334] usbcore: registered new interface driver rndis_host [ 17.353075] usbcore: registered new interface driver usbserial_generic [ 17.359643] usbserial: USB Serial support registered for generic [ 17.367193] wireguard: WireGuard 1.0.0 loaded. See www.wireguard.com for information. [ 17.375028] wireguard: Copyright (C) 2015-2019 Jason A. Donenfeld <Jason@zx2c4.com>. All Rights Reserved. [ 17.401118] xt_time: kernel timezone is -0000 [ 17.407482] PPP generic driver version 2.4.2 [ 17.412748] NET: Registered protocol family 24 [ 17.419151] usbcore: registered new interface driver option [ 17.424803] usbserial: USB Serial support registered for GSM modem (1-port) [ 17.433333] kmodloader: done loading kernel modules from /etc/modules.d/* [ 20.273208] kmwan: sensitivity and mode are set. [ 20.345484] get_dev_l2profile: Band0: profile path=/etc/wireless/mediatek/mt7993.b0.dat [ 20.356068] RtmpMgmtTaskInit(939): task_name is RtmpCmdQTask_00 [ 20.362116] WscThreadInit(11527): task_name is RtmpWscTask_00 [ 20.367995] bcn_bpcc_TaskInit(3904): task_name is BPCCCmdQTask_00 [ 20.374251] ser_init(309): task_name is ser_task_00 [ 20.379684] get_dev_l2profile: Band0: profile path=/etc/wireless/mediatek/mt7993.b0.dat [ 20.393172] : PartialScanACS=0 [ 20.397163] : ScanningDwell=200 [ 20.401230] : RestoreDwell=150 [ 20.405335] : ChUtilThr=0 [ 20.408883] : ACSIceChUtilThr=0 [ 20.412932] : ACSMaxACSTimes=0 [ 20.416887] : StaNumThr=1 [ 20.420421] : ACSSwChThr=0 [ 20.431374] configure(ra0)bVLAN_Tag=1 [ 20.465281] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.470440] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.475582] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.480736] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.485888] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.491024] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.496160] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.501316] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.506469] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.511609] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.516760] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.521913] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.527057] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.532199] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.537340] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.542477] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 20.547676] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.552831] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.557974] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.563117] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.568270] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.573407] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.578540] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.583688] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.588831] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.593980] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.599121] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.604278] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.609435] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.614590] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.619736] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.624891] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 20.668501] BSS0 mld_grp_idx=0 [ 20.671565] BSS1 mld_grp_idx=0 [ 20.674614] BSS2 mld_grp_idx=0 [ 20.677686] BSS3 mld_grp_idx=0 [ 20.680873] BSS0 TidMapping=0xff [ 20.684109] BSS1 TidMapping=0xff [ 20.687344] BSS2 TidMapping=0xff [ 20.690567] BSS3 TidMapping=0xff [ 20.693922] Line.1156 - AP Band0(MBSS0) ==> wlan_config_set_nsep_priority_access: cfg nsep_priority_access_enable = 1 [ 20.704538] Line.1156 - AP Band0(MBSS1) ==> wlan_config_set_nsep_priority_access: cfg nsep_priority_access_enable = 1 [ 20.715146] Line.1156 - AP Band0(MBSS2) ==> wlan_config_set_nsep_priority_access: cfg nsep_priority_access_enable = 1 [ 20.725748] Line.1156 - AP Band0(MBSS3) ==> wlan_config_set_nsep_priority_access: cfg nsep_priority_access_enable = 1 [ 20.736591] Line.1198 - AP Band0(MBSS0) ==> wlan_config_set_eht_om_ctrl: cfg eht_om_ctrl_enable = 1 [ 20.745747] Line.1219 - AP Band0(MBSS0) ==> wlan_config_set_eht_txop_sharing_trigger: cfg txop_sharing_trigger_enable = 0 [ 20.756699] Line.1219 - AP Band0(MBSS1) ==> wlan_config_set_eht_txop_sharing_trigger: cfg txop_sharing_trigger_enable = 0 [ 20.767654] Line.1219 - AP Band0(MBSS2) ==> wlan_config_set_eht_txop_sharing_trigger: cfg txop_sharing_trigger_enable = 0 [ 20.778612] Line.1219 - AP Band0(MBSS3) ==> wlan_config_set_eht_txop_sharing_trigger: cfg txop_sharing_trigger_enable = 0 [ 20.789818] Line.1283 - AP Band0(MBSS0) ==> wlan_config_set_eht_scs_traffic: cfg restricted_twt_support = 1 [ 20.800166] Line.1393 - AP Band0(MBSS0) ==> wlan_config_set_emlsr_mr: cfg emlsr_mr = 1 [ 20.808085] Line.1393 - AP Band0(MBSS1) ==> wlan_config_set_emlsr_mr: cfg emlsr_mr = 0 [ 20.816007] Line.1393 - AP Band0(MBSS2) ==> wlan_config_set_emlsr_mr: cfg emlsr_mr = 0 [ 20.823928] Line.1393 - AP Band0(MBSS3) ==> wlan_config_set_emlsr_mr: cfg emlsr_mr = 0 [ 20.831966] Line.1414 - AP Band0(MBSS0) ==> wlan_config_set_trans_to: cfg trans_to = 0 [ 20.839890] Line.1414 - AP Band0(MBSS1) ==> wlan_config_set_trans_to: cfg trans_to = 0 [ 20.847818] Line.1414 - AP Band0(MBSS2) ==> wlan_config_set_trans_to: cfg trans_to = 0 [ 20.855742] Line.1414 - AP Band0(MBSS3) ==> wlan_config_set_trans_to: cfg trans_to = 0 [ 20.863782] Line.1435 - AP Band0(MBSS0) ==> wlan_config_set_eml_omn_en: cfg EML OMN enable = 0 [ 20.872419] Line.1435 - AP Band0(MBSS1) ==> wlan_config_set_eml_omn_en: cfg EML OMN enable = 0 [ 20.881042] Line.1435 - AP Band0(MBSS2) ==> wlan_config_set_eml_omn_en: cfg EML OMN enable = 0 [ 20.889667] Line.1435 - AP Band0(MBSS3) ==> wlan_config_set_eml_omn_en: cfg EML OMN enable = 0 [ 20.898404] Line.1461 - AP Band0(MBSS0) ==> wlan_config_set_eht_bw: cfg bw = 1 [ 20.905641] wlan_config_set_eht_bw: cfg bw = 1 [ 20.910100] wlan_config_set_eht_bw: cfg bw = 1 [ 20.914551] wlan_config_set_eht_bw: cfg bw = 1 [ 20.919000] wlan_config_set_eht_bw: cfg bw = 1 [ 20.923453] wlan_config_set_eht_bw: cfg bw = 1 [ 20.927906] wlan_config_set_eht_bw: cfg bw = 1 [ 20.932370] wlan_config_set_eht_bw: cfg bw = 1 [ 20.936825] wlan_config_set_eht_bw: cfg bw = 1 [ 20.941273] wlan_config_set_eht_bw: cfg bw = 1 [ 20.945732] wlan_config_set_eht_bw: cfg bw = 1 [ 20.950196] wlan_config_set_eht_bw: cfg bw = 1 [ 20.954657] wlan_config_set_eht_bw: cfg bw = 1 [ 20.959110] wlan_config_set_eht_bw: cfg bw = 1 [ 20.963562] wlan_config_set_eht_bw: cfg bw = 1 [ 20.968011] wlan_config_set_eht_bw: cfg bw = 1 [ 20.972452] Line.1461 - AP Band0(MBSS1) ==> wlan_config_set_eht_bw: cfg bw = 1 [ 20.979666] Line.1461 - AP Band0(MBSS2) ==> wlan_config_set_eht_bw: cfg bw = 1 [ 20.986881] Line.1461 - AP Band0(MBSS3) ==> wlan_config_set_eht_bw: cfg bw = 1 [ 20.994712] Line.1574 - AP Band0(MBSS0) ==> wlan_config_set_t2lm_nego_support: cfg t2lm_nego_support = 1 [ 21.004181] Line.1574 - AP Band0(MBSS1) ==> wlan_config_set_t2lm_nego_support: cfg t2lm_nego_support = 0 [ 21.013650] Line.1574 - AP Band0(MBSS2) ==> wlan_config_set_t2lm_nego_support: cfg t2lm_nego_support = 0 [ 21.023121] Line.1574 - AP Band0(MBSS3) ==> wlan_config_set_t2lm_nego_support: cfg t2lm_nego_support = 0 [ 21.034921] I/F STA (ra0) ==> ApcliMloDisable = 1 [ 21.040768] bss_color_profile_enable: value = 255 [ 21.048582] HwCmdThreadInit: task_name is HwCtrlTask_0 [ 21.053794] <--- HwCmdThreadInit(): status=0! [ 21.058164] mt7993 0000:01:00.0: connac_if_start() [ 21.076866] mt7993_set_rro_timeout(12161):ret=0x0,step_one_timeout = 128,flush_all_timeout = 256 [ 21.086247] mt7993_set_rro_rss_map(12176):ret=0x0,rro_rss_map0 = 0x32103210,rro_rss_map1 = 0x32103210 [ 21.096918] hwifi_init_sdo_override(2366): hw->override_info->enable 1 [ 21.104028] hwifi_init_hw_ring_setting(2337): ret=0x0, rx_path_type = 0 [ 21.111203] hwifi_init_hw_ring_setting(2341): ret=0x0, rro_bypass_type = 2 [ 21.118811] hwifi_init_hw_ring_setting(2347): ret=0x0, txfreedone_path = 0 [ 21.125688] hwifi_init_hw_ring_setting(2354): ret=0x0, hif_txd_ver_sdo = 33 [ 21.132648] NICReadEEPROMParameters: MacAddrAdj=0x0 [ 21.137526] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.142656] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.147786] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.152916] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.158047] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.163177] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.168307] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.173436] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.178566] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.183705] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.188836] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.193966] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.199097] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.204226] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.209356] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.214486] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.219618] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.224748] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.229879] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.235008] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.240138] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.245268] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.250400] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.255530] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.260661] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.265792] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.270923] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.276053] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.281186] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.286317] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.291448] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.296579] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.314393] ---> physical_device_thread_init() [ 21.318835] ---> physical_device_thread_queue_init() [ 21.323792] <--- physical_device_thread_queue_init() [ 21.328749] physical_device_thread_init(362): task_name is DeviceTask_0 [ 21.335433] <--- physical_device_thread_init(): status=0! [ 21.340914] UniCmdMuruSetLowPwr: BandIdx=0 CmdId=0 value=1 [ 21.351518] MlmeInit(1801): task_name is RtmpMlmeTask_00 [ 21.361313] SCS_init(): SCS Default Enable, Ret=0 [ 21.368721] wlan_config_set_eht_bw: cfg bw = 1 [ 21.373161] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 21.378299] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 21.385091] mt_serv_get_chip_info: 4314 [ 21.388987] [mt_serv_init_test][515]: band_num = 2, band_idx = 0 [ 21.476506] mt7993 0000:01:00.0: connac_if_config_bss(): fw_idx 0, omac_idx 0, wmm_idx 0, band_idx 0 [ 21.485765] 7993@ERROR.CHN,apcli0,phy_freq_adjust() 322: no prim_ch value for adjust! [ 21.493622] 7993@ERROR.CHN,apcli0,operate_loader_phy() 668: phy_freq_adjust failed! [ 21.493667] mt7993 0000:01:00.0: mtk_hwctrl_sta_alloc(G): mld_sta_idx=65535, wcid=512, hw_sta=00000000deef12da [ 21.514957] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 1 [ 21.762779] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 2 [ 22.017863] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 3 [ 22.268531] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 4 [ 22.520728] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 5 [ 22.768479] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 6 [ 23.012557] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 7 [ 23.260667] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 8 [ 23.508239] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 9 [ 23.756294] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 10 [ 24.004203] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 11 [ 24.248313] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 2 [ 24.528212] UniEventEDCCAThresholdProc: fginit = 1, EDCCA Threshold=191, 194, 197, 200 [ 24.539768] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 1 [ 24.707543] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 2 [ 24.871525] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 3 [ 25.035522] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 4 [ 25.199534] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 5 [ 25.367512] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 6 [ 25.536670] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 7 [ 25.703563] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 8 [ 25.871440] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 9 [ 26.035520] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 10 [ 26.198716] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 2 [ 26.244712] UniEventEDCCAThresholdProc: fginit = 1, EDCCA Threshold=191, 194, 197, 200 [ 26.254845] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 2 [ 26.443925] UniEventEDCCAThresholdProc: fginit = 1, EDCCA Threshold=191, 194, 197, 200 [ 26.453619] mt7993 0000:01:00.0: connac_if_mld_add_link(): grp 17, mat 32, mldmat 32, remap 255 [ 26.462338] wlan_config_set_t2lm_nego_support: cfg t2lm_nego_support = 1 [ 26.469032] wlan_config_set_emlsr_mr: cfg emlsr_mr = 1 [ 26.474163] wlan_config_set_trans_to: cfg trans_to = 0 [ 26.479294] wlan_config_set_eml_omn_en: cfg EML OMN enable = 0 [ 26.500068] u1CCKTxStream = 4 [ 26.503117] set wrong parameters [ 26.565221] vow_mbss_grp_band_map not support for VOW_GEN:4 [ 26.582391] UniEventEDCCAThresholdProc: fginit = 1, EDCCA Threshold=191, 194, 197, 200 [ 26.593623] mtk_ppe_dev_register_hook : ineterface ra0 register (1) [ 26.595597] 7993@ERROR.CHN,ra0,ReleaseChannelOpChargeForCurrentOwner() 1378: caller:APOverlappingScan+0x1e0/0x278 [mt_wifi]. Try to release an empty owner_bit_mask!! done=0, ownBitMask=0x0, ChOpWaitBitMask=0x0 [ 26.595597] [ 26.946935] mtk_soc_eth 15100000.ethernet eth1: PHY [mdio-bus:0f] driver [MediaTek MT7987 2.5GbE PHY] [ 26.976351] mtk_soc_eth 15100000.ethernet eth1: configuring for phy/internal link mode [ 26.986113] nf_unregister_hooks() [ 26.989844] br-lan: port 1(eth1) entered blocking state [ 26.995100] br-lan: port 1(eth1) entered disabled state [ 27.000531] device eth1 entered promiscuous mode [ 27.004961] mtk_soc_eth 15100000.ethernet eth1: Link is Up - 2.5Gbps/Full - flow control rx/tx [ 27.006255] br-lan: port 1(eth1) entered blocking state [ 27.019022] br-lan: port 1(eth1) entered forwarding state [ 27.024790] tertf: br-lan registered, add it [ 27.032075] br-lan: port 2(ra0) entered blocking state [ 27.037290] br-lan: port 2(ra0) entered disabled state [ 27.044364] device ra0 entered promiscuous mode [ 27.049133] br-lan: port 2(ra0) entered blocking state [ 27.054344] br-lan: port 2(ra0) entered forwarding state [ 27.198802] mtk_soc_eth 15100000.ethernet eth0: PHY [mdio-bus:07] driver [RTL8221B-VB-CG 2.5Gbps PHY (C45)] [ 27.208584] mtk_soc_eth 15100000.ethernet eth0: configuring for phy/2500base-x link mode [ 27.480776] wlan_config_set_eht_bw: cfg bw = 1 [ 27.485354] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 27.490543] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 27.513113] wlan_config_set_eht_bw: cfg bw = 1 [ 27.517774] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 27.522955] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 27.545002] wlan_config_set_eht_bw: cfg bw = 1 [ 27.549508] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 27.554714] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 27.596037] wlan_config_set_eht_bw: cfg bw = 1 [ 27.600558] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 27.605754] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 27.622785] mt7993 0000:01:00.0: connac_if_config_bss(): fw_idx 1, omac_idx 11, wmm_idx 0, band_idx 0 [ 27.633280] mt7993 0000:01:00.0: mtk_hwctrl_sta_alloc(G): mld_sta_idx=65535, wcid=513, hw_sta=000000000e5510a0 [ 27.656118] mt7993 0000:01:00.0: connac_if_mld_add_link(): grp 18, mat 33, mldmat 33, remap 255 [ 27.664912] wlan_config_set_t2lm_nego_support: cfg t2lm_nego_support = 0 [ 27.671683] wlan_config_set_emlsr_mr: cfg emlsr_mr = 0 [ 27.676856] wlan_config_set_trans_to: cfg trans_to = 0 [ 27.682056] wlan_config_set_eml_omn_en: cfg EML OMN enable = 0 [ 27.707245] u1CCKTxStream = 4 [ 27.710304] set wrong parameters [ 27.779520] vow_mbss_grp_band_map not support for VOW_GEN:4 [ 27.798567] UniEventEDCCAThresholdProc: fginit = 1, EDCCA Threshold=191, 194, 197, 200 [ 27.811452] mtk_ppe_dev_register_hook : ineterface ra15 register (2) [ 27.844597] get_dev_l2profile: Band1: profile path=/etc/wireless/mediatek/mt7993.b1.dat [ 27.860059] RtmpMgmtTaskInit(939): task_name is RtmpCmdQTask_01 [ 27.867876] WscThreadInit(11527): task_name is RtmpWscTask_01 [ 27.873795] bcn_bpcc_TaskInit(3904): task_name is BPCCCmdQTask_01 [ 27.882068] ser_init(309): task_name is ser_task_01 [ 27.887813] get_dev_l2profile: Band1: profile path=/etc/wireless/mediatek/mt7993.b1.dat [ 27.901634] : PartialScanACS=0 [ 27.905701] : ScanningDwell=200 [ 27.909788] : RestoreDwell=150 [ 27.913897] : ChUtilThr=0 [ 27.917482] : ACSIceChUtilThr=0 [ 27.921578] : ACSMaxACSTimes=0 [ 27.925568] : StaNumThr=1 [ 27.929141] : ACSSwChThr=0 [ 27.940456] configure(rai0)bVLAN_Tag=1 [ 27.975456] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 27.980620] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 27.985781] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 27.990945] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 27.996107] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.001290] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.006454] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.011596] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.016751] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.021906] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.027046] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.032201] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.037371] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.042524] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.047695] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.052865] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.058102] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.063291] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.068486] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.073645] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.078790] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.083939] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.089109] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.094262] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.099430] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.104588] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.109740] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.114897] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.120067] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.125220] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.130372] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.135553] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.180445] BSS0 mld_grp_idx=0 [ 28.183537] BSS1 mld_grp_idx=0 [ 28.186589] BSS2 mld_grp_idx=0 [ 28.189678] BSS3 mld_grp_idx=0 [ 28.192909] BSS0 TidMapping=0xff [ 28.196165] BSS1 TidMapping=0xff [ 28.199404] BSS2 TidMapping=0xff [ 28.202640] BSS3 TidMapping=0xff [ 28.206042] Line.1156 - AP Band1(MBSS0) ==> wlan_config_set_nsep_priority_access: cfg nsep_priority_access_enable = 1 [ 28.216687] Line.1156 - AP Band1(MBSS1) ==> wlan_config_set_nsep_priority_access: cfg nsep_priority_access_enable = 1 [ 28.227332] Line.1156 - AP Band1(MBSS2) ==> wlan_config_set_nsep_priority_access: cfg nsep_priority_access_enable = 1 [ 28.237977] Line.1156 - AP Band1(MBSS3) ==> wlan_config_set_nsep_priority_access: cfg nsep_priority_access_enable = 1 [ 28.248876] Line.1198 - AP Band1(MBSS0) ==> wlan_config_set_eht_om_ctrl: cfg eht_om_ctrl_enable = 1 [ 28.258095] Line.1219 - AP Band1(MBSS0) ==> wlan_config_set_eht_txop_sharing_trigger: cfg txop_sharing_trigger_enable = 0 [ 28.269100] Line.1219 - AP Band1(MBSS1) ==> wlan_config_set_eht_txop_sharing_trigger: cfg txop_sharing_trigger_enable = 0 [ 28.280095] Line.1219 - AP Band1(MBSS2) ==> wlan_config_set_eht_txop_sharing_trigger: cfg txop_sharing_trigger_enable = 0 [ 28.291071] Line.1219 - AP Band1(MBSS3) ==> wlan_config_set_eht_txop_sharing_trigger: cfg txop_sharing_trigger_enable = 0 [ 28.302316] Line.1283 - AP Band1(MBSS0) ==> wlan_config_set_eht_scs_traffic: cfg restricted_twt_support = 1 [ 28.312739] Line.1393 - AP Band1(MBSS0) ==> wlan_config_set_emlsr_mr: cfg emlsr_mr = 1 [ 28.320706] Line.1393 - AP Band1(MBSS1) ==> wlan_config_set_emlsr_mr: cfg emlsr_mr = 0 [ 28.328658] Line.1393 - AP Band1(MBSS2) ==> wlan_config_set_emlsr_mr: cfg emlsr_mr = 0 [ 28.336609] Line.1393 - AP Band1(MBSS3) ==> wlan_config_set_emlsr_mr: cfg emlsr_mr = 0 [ 28.344717] Line.1414 - AP Band1(MBSS0) ==> wlan_config_set_trans_to: cfg trans_to = 0 [ 28.352701] Line.1414 - AP Band1(MBSS1) ==> wlan_config_set_trans_to: cfg trans_to = 0 [ 28.360632] Line.1414 - AP Band1(MBSS2) ==> wlan_config_set_trans_to: cfg trans_to = 0 [ 28.368599] Line.1414 - AP Band1(MBSS3) ==> wlan_config_set_trans_to: cfg trans_to = 0 [ 28.376693] Line.1435 - AP Band1(MBSS0) ==> wlan_config_set_eml_omn_en: cfg EML OMN enable = 0 [ 28.385337] Line.1435 - AP Band1(MBSS1) ==> wlan_config_set_eml_omn_en: cfg EML OMN enable = 0 [ 28.394008] Line.1435 - AP Band1(MBSS2) ==> wlan_config_set_eml_omn_en: cfg EML OMN enable = 0 [ 28.402669] Line.1435 - AP Band1(MBSS3) ==> wlan_config_set_eml_omn_en: cfg EML OMN enable = 0 [ 28.411423] Line.1461 - AP Band1(MBSS0) ==> wlan_config_set_eht_bw: cfg bw = 2 [ 28.418676] wlan_config_set_eht_bw: cfg bw = 2 [ 28.423154] wlan_config_set_eht_bw: cfg bw = 2 [ 28.427627] wlan_config_set_eht_bw: cfg bw = 2 [ 28.432098] wlan_config_set_eht_bw: cfg bw = 2 [ 28.436569] wlan_config_set_eht_bw: cfg bw = 2 [ 28.441049] wlan_config_set_eht_bw: cfg bw = 2 [ 28.445516] wlan_config_set_eht_bw: cfg bw = 2 [ 28.449985] wlan_config_set_eht_bw: cfg bw = 2 [ 28.454466] wlan_config_set_eht_bw: cfg bw = 2 [ 28.458926] wlan_config_set_eht_bw: cfg bw = 2 [ 28.463424] wlan_config_set_eht_bw: cfg bw = 2 [ 28.467900] wlan_config_set_eht_bw: cfg bw = 2 [ 28.472366] wlan_config_set_eht_bw: cfg bw = 2 [ 28.476844] wlan_config_set_eht_bw: cfg bw = 2 [ 28.481307] wlan_config_set_eht_bw: cfg bw = 2 [ 28.485793] Line.1461 - AP Band1(MBSS1) ==> wlan_config_set_eht_bw: cfg bw = 2 [ 28.493038] Line.1461 - AP Band1(MBSS2) ==> wlan_config_set_eht_bw: cfg bw = 2 [ 28.500317] Line.1461 - AP Band1(MBSS3) ==> wlan_config_set_eht_bw: cfg bw = 2 [ 28.508205] Line.1574 - AP Band1(MBSS0) ==> wlan_config_set_t2lm_nego_support: cfg t2lm_nego_support = 1 [ 28.517717] Line.1574 - AP Band1(MBSS1) ==> wlan_config_set_t2lm_nego_support: cfg t2lm_nego_support = 0 [ 28.527212] Line.1574 - AP Band1(MBSS2) ==> wlan_config_set_t2lm_nego_support: cfg t2lm_nego_support = 0 [ 28.536727] Line.1574 - AP Band1(MBSS3) ==> wlan_config_set_t2lm_nego_support: cfg t2lm_nego_support = 0 [ 28.548649] I/F STA (ra0) ==> ApcliMloDisable = 1 [ 28.554566] bss_color_profile_enable: value = 255 [ 28.562584] mt7993 0000:01:00.0: connac_if_start() [ 28.575363] hwifi_init_sdo_override(2366): hw->override_info->enable 1 [ 28.581986] NICReadEEPROMParameters: MacAddrAdj=0x0 [ 28.586894] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.592070] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.597233] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.602407] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.607590] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.612761] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.617926] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.623076] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.628245] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.633416] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.638578] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.643746] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.648913] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.654075] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.659231] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.664390] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.669553] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.674719] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.679901] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.685063] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.690227] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.695401] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.700556] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.705710] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.710873] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.716028] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.721186] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.726341] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.731496] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.736660] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.741825] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.746969] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.752143] UniCmdMuruSetLowPwr: BandIdx=1 CmdId=0 value=1 [ 28.765957] MlmeInit(1801): task_name is RtmpMlmeTask_01 [ 28.775864] SCS_init(): SCS Default Enable, Ret=0 [ 28.784719] wlan_config_set_eht_bw: cfg bw = 2 [ 28.789407] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 28.794584] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 28.801691] mt_serv_get_chip_info: 4314 [ 28.805602] [mt_serv_init_test][515]: band_num = 2, band_idx = 1 [ 28.879143] mt7993 0000:01:00.0: connac_if_config_bss(): fw_idx 2, omac_idx 0, wmm_idx 0, band_idx 1 [ 28.888482] 7993@ERROR.CHN,apclii0,phy_freq_adjust() 322: no prim_ch value for adjust! [ 28.896451] 7993@ERROR.CHN,apclii0,operate_loader_phy() 668: phy_freq_adjust failed! [ 28.896498] mt7993 0000:01:00.0: mtk_hwctrl_sta_alloc(G): mld_sta_idx=65535, wcid=514, hw_sta=000000008c6c36e6 [ 28.918255] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 36 [ 29.165501] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 40 [ 29.412362] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 44 [ 29.660608] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 48 [ 29.908692] mt7993 0000:01:00.0: connac_if_config_phy(): update channel to 44 [ 30.464012] UniEventEDCCAThresholdProc: fginit = 1, EDCCA Threshold=187, 190, 193, 200 [ 30.475639] mt7993 0000:01:00.0: connac_if_mld_add_link(): grp 19, mat 34, mldmat 34, remap 255 [ 30.484358] wlan_config_set_t2lm_nego_support: cfg t2lm_nego_support = 1 [ 30.491053] wlan_config_set_emlsr_mr: cfg emlsr_mr = 1 [ 30.496185] wlan_config_set_trans_to: cfg trans_to = 0 [ 30.501315] wlan_config_set_eml_omn_en: cfg EML OMN enable = 0 [ 30.524258] u1CCKTxStream = 4 [ 30.527310] set wrong parameters [ 30.586639] vow_mbss_grp_band_map not support for VOW_GEN:4 [ 30.604401] UniEventEDCCAThresholdProc: fginit = 1, EDCCA Threshold=187, 190, 193, 200 [ 30.615946] mtk_ppe_dev_register_hook : ineterface rai0 register (3) [ 30.644307] br-lan: port 3(rai0) entered blocking state [ 30.649589] br-lan: port 3(rai0) entered disabled state [ 30.655119] device rai0 entered promiscuous mode [ 30.659949] br-lan: port 3(rai0) entered blocking state [ 30.665238] br-lan: port 3(rai0) entered forwarding state [ 30.708544] wlan_config_set_eht_bw: cfg bw = 2 [ 30.713151] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 30.718309] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 30.929696] wlan_config_set_eht_bw: cfg bw = 2 [ 30.934216] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 30.939386] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 30.957203] wlan_config_set_eht_bw: cfg bw = 2 [ 30.961868] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 30.967029] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 30.983998] wlan_config_set_eht_bw: cfg bw = 2 [ 30.988535] wlan_config_set_eht_tx_nss: cfg tx_nss = 2 [ 30.993712] wlan_config_set_eht_rx_nss: cfg rx_nss = 2 [ 31.004658] mt7993 0000:01:00.0: connac_if_config_bss(): fw_idx 3, omac_idx 11, wmm_idx 0, band_idx 1 [ 31.018091] mt7993 0000:01:00.0: mtk_hwctrl_sta_alloc(G): mld_sta_idx=65535, wcid=515, hw_sta=00000000c87b3faa [ 31.036095] mt7993 0000:01:00.0: connac_if_mld_add_link(): grp 20, mat 35, mldmat 35, remap 255 [ 31.045271] wlan_config_set_t2lm_nego_support: cfg t2lm_nego_support = 0 [ 31.052084] wlan_config_set_emlsr_mr: cfg emlsr_mr = 0 [ 31.057266] wlan_config_set_trans_to: cfg trans_to = 0 [ 31.062426] wlan_config_set_eml_omn_en: cfg EML OMN enable = 0 [ 31.088110] u1CCKTxStream = 4 [ 31.091188] set wrong parameters [ 31.159342] vow_mbss_grp_band_map not support for VOW_GEN:4 [ 31.179888] UniEventEDCCAThresholdProc: fginit = 1, EDCCA Threshold=187, 190, 193, 200 [ 31.193298] mtk_ppe_dev_register_hook : ineterface rai15 register (4) [ 35.180406] -->update_qos_map(), update qos map config. [ 35.814999] sh (12226): drop_caches: 3 [ 37.109501] no net device found for lan0 or apclii0 [ 37.114473] no net device found for lan1 or apclii0 [ 37.119519] no net device found for lan2 or apclii0 [ 37.124488] no net device found for lan3 or apclii0 root@GL-MT3600BE:~#

[ 0.000000] Booting Linux on physical CPU 0x0000000000 [0x410fd034] [ 0.000000] Linux version 6.18.28 (builder@buildhost) (aarch64-openwrt-linux-musl-gcc (OpenWrt GCC 14.3.0 r34414-348303a9e2) 14.3.0, GNU ld (GNU Binutils) 2.44) #0 SMP Tue May 12 07:34:32 2026 [ 0.000000] KASLR disabled due to lack of seed [ 0.000000] Machine model: GL.iNet GL-MT3600BE [ 0.000000] earlycon: uart8250 at MMIO32 0x0000000011000000 (options '') [ 0.000000] printk: legacy bootconsole [uart8250] enabled [ 0.000000] OF: reserved mem: 0x000000005ffc0000..0x000000005fffffff (256 KiB) nomap non-reusable secmon@5ffc0000 [ 0.000000] OF: reserved mem: 0x000000005ffb0000..0x000000005ffbffff (64 KiB) map non-reusable ramoops@5ffb0000 [ 0.000000] OF: reserved mem: 0x0000000050000000..0x00000000500fffff (1024 KiB) nomap non-reusable wmcpu-reserved@50000000 [ 0.000000] Zone ranges: [ 0.000000] DMA [mem 0x0000000040000000-0x000000005fffffff] [ 0.000000] DMA32 empty [ 0.000000] Normal empty [ 0.000000] Movable zone start for each node [ 0.000000] Early memory node ranges [ 0.000000] node 0: [mem 0x0000000040000000-0x000000004fffffff] [ 0.000000] node 0: [mem 0x0000000050000000-0x00000000500fffff] [ 0.000000] node 0: [mem 0x0000000050100000-0x000000005ffbffff] [ 0.000000] node 0: [mem 0x000000005ffc0000-0x000000005fffffff] [ 0.000000] Initmem setup node 0 [mem 0x0000000040000000-0x000000005fffffff] [ 0.000000] psci: probing for conduit method from DT. [ 0.000000] psci: PSCIv1.1 detected in firmware. [ 0.000000] psci: Using standard PSCI v0.2 function IDs [ 0.000000] psci: MIGRATE_INFO_TYPE not supported. [ 0.000000] psci: SMC Calling Convention v1.5 [ 0.000000] percpu: Embedded 20 pages/cpu s43544 r8192 d30184 u81920 [ 0.000000] pcpu-alloc: s43544 r8192 d30184 u81920 alloc=20*4096 [ 0.000000] pcpu-alloc: [0] 0 [0] 1 [0] 2 [0] 3 [ 0.000000] Detected VIPT I-cache on CPU0 [ 0.000000] CPU features: detected: GICv3 CPU interface [ 0.000000] CPU features: kernel page table isolation disabled by kernel configuration [ 0.000000] alternatives: applying boot alternatives [ 0.000000] Kernel command line: console=ttyS0,115200n1 earlycon=uart8250,mmio32,0x11000000 pci=pcie_bus_perf [ 0.000000] printk: log buffer data + meta data: 131072 + 458752 = 589824 bytes [ 0.000000] Dentry cache hash table entries: 65536 (order: 7, 524288 bytes, linear) [ 0.000000] Inode-cache hash table entries: 32768 (order: 6, 262144 bytes, linear) [ 0.000000] software IO TLB: SWIOTLB bounce buffer size adjusted to 0MB [ 0.000000] software IO TLB: area num 4. [ 0.000000] software IO TLB: SWIOTLB bounce buffer size roundup to 1MB [ 0.000000] software IO TLB: mapped [mem 0x000000005f440000-0x000000005f540000] (1MB) [ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 131072 [ 0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off [ 0.000000] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=4, Nodes=1 [ 0.000000] rcu: Hierarchical RCU implementation. [ 0.000000] Tracing variant of Tasks RCU enabled. [ 0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 10 jiffies. [ 0.000000] RCU Tasks Trace: Setting shift to 2 and lim to 1 rcu_task_cb_adjust=1 rcu_task_cpu_ids=4. [ 0.000000] NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0 [ 0.000000] GICv3: GIC: Using split EOI/Deactivate mode [ 0.000000] GICv3: 640 SPIs implemented [ 0.000000] GICv3: 0 Extended SPIs implemented [ 0.000000] Root IRQ handler: gic_handle_irq [ 0.000000] GICv3: GICv3 features: 16 PPIs [ 0.000000] GICv3: GICD_CTLR.DS=0, SCR_EL3.FIQ=0 [ 0.000000] GICv3: CPU0: found redistributor 0 region 0:0x000000000c080000 [ 0.000000] rcu: srcu_init: Setting srcu_struct sizes based on contention. [ 0.000000] arch_timer: cp15 timer running at 13.00MHz (phys). [ 0.000000] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x2ff89eacb, max_idle_ns: 440795202429 ns [ 0.000000] sched_clock: 56 bits at 13MHz, resolution 76ns, wraps every 4398046511101ns [ 0.008229] Calibrating delay loop (skipped), value calculated using timer frequency.. 26.00 BogoMIPS (lpj=130000) [ 0.018651] pid_max: default: 32768 minimum: 301 [ 0.025000] Mount-cache hash table entries: 1024 (order: 1, 8192 bytes, linear) [ 0.032361] Mountpoint-cache hash table entries: 1024 (order: 1, 8192 bytes, linear) [ 0.043743] cacheinfo: Unable to detect cache hierarchy for CPU 0 [ 0.050467] rcu: Hierarchical SRCU implementation. [ 0.055296] rcu: Max phase no-delay instances is 1000. [ 0.060680] Timer migration: 1 hierarchy levels; 8 children per group; 1 crossnode level [ 0.069027] smp: Bringing up secondary CPUs ... [ 0.073862] Detected VIPT I-cache on CPU1 [ 0.073892] GICv3: CPU1: found redistributor 1 region 0:0x000000000c0a0000 [ 0.073920] CPU1: Booted secondary processor 0x0000000001 [0x410fd034] [ 0.074257] Detected VIPT I-cache on CPU2 [ 0.074276] GICv3: CPU2: found redistributor 2 region 0:0x000000000c0c0000 [ 0.074290] CPU2: Booted secondary processor 0x0000000002 [0x410fd034] [ 0.074613] Detected VIPT I-cache on CPU3 [ 0.074628] GICv3: CPU3: found redistributor 3 region 0:0x000000000c0e0000 [ 0.074639] CPU3: Booted secondary processor 0x0000000003 [0x410fd034] [ 0.074673] smp: Brought up 1 node, 4 CPUs [ 0.131301] SMP: Total of 4 processors activated. [ 0.136027] CPU: All CPU(s) started at EL2 [ 0.140141] CPU features: detected: 32-bit EL0 Support [ 0.145309] CPU features: detected: CRC32 instructions [ 0.150495] alternatives: applying system-wide alternatives [ 0.156211] CPU features: emulated: Privileged Access Never (PAN) using TTBR0_EL1 switching [ 0.164737] Memory: 492796K/524288K available (9984K kernel code, 1020K rwdata, 3040K rodata, 960K init, 310K bss, 28424K reserved, 0K cma-reserved) [ 0.181228] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns [ 0.191171] posixtimers hash table entries: 2048 (order: 3, 32768 bytes, linear) [ 0.198669] futex hash table entries: 1024 (65536 bytes on 1 NUMA nodes, total 64 KiB, linear). [ 0.207476] 28896 pages in range for non-PLT usage [ 0.207480] 520416 pages in range for PLT usage [ 0.213373] pinctrl core: initialized pinctrl subsystem [ 0.224973] NET: Registered PF_NETLINK/PF_ROUTE protocol family [ 0.231219] DMA: preallocated 128 KiB GFP_KERNEL pool for atomic allocations [ 0.238325] DMA: preallocated 128 KiB GFP_KERNEL|GFP_DMA pool for atomic allocations [ 0.246135] DMA: preallocated 128 KiB GFP_KERNEL|GFP_DMA32 pool for atomic allocations [ 0.254471] thermal_sys: Registered thermal governor 'fair_share' [ 0.254475] thermal_sys: Registered thermal governor 'bang_bang' [ 0.260607] thermal_sys: Registered thermal governor 'step_wise' [ 0.266647] thermal_sys: Registered thermal governor 'user_space' [ 0.272747] ASID allocator initialised with 65536 entries [ 0.285050] pstore: Using crash dump compression: deflate [ 0.290482] printk: legacy console [ramoops-1] enabled [ 0.295907] pstore: Registered ramoops as persistent store backend [ 0.302123] ramoops: using 0x10000@0x5ffb0000, ecc: 0 [ 0.309469] /soc/interrupt-controller@c000000: Fixed dependency cycle(s) with /soc/interrupt-controller@c000000 [ 0.322794] /soc/pcie@11280000: Fixed dependency cycle(s) with /soc/pcie@11280000/interrupt-controller [ 0.341554] SCSI subsystem initialized [ 0.345442] libata version 3.00 loaded. [ 0.350631] clocksource: Switched to clocksource arch_sys_counter [ 0.358609] NET: Registered PF_INET protocol family [ 0.363625] IP idents hash table entries: 8192 (order: 4, 65536 bytes, linear) [ 0.371948] tcp_listen_portaddr_hash hash table entries: 256 (order: 0, 4096 bytes, linear) [ 0.380361] Table-perturb hash table entries: 65536 (order: 6, 262144 bytes, linear) [ 0.388169] TCP established hash table entries: 4096 (order: 3, 32768 bytes, linear) [ 0.395988] TCP bind hash table entries: 4096 (order: 5, 131072 bytes, linear) [ 0.403352] TCP: Hash tables configured (established 4096 bind 4096) [ 0.409912] MPTCP token hash table entries: 512 (order: 2, 12288 bytes, linear) [ 0.417346] UDP hash table entries: 256 (order: 2, 16384 bytes, linear) [ 0.424018] UDP-Lite hash table entries: 256 (order: 2, 16384 bytes, linear) [ 0.431269] NET: Registered PF_UNIX/PF_LOCAL protocol family [ 0.436979] PCI: CLS 0 bytes, default 64 [ 0.441939] workingset: timestamp_bits=46 max_order=17 bucket_order=0 [ 0.452017] squashfs: version 4.0 (2009/01/31) Phillip Lougher [ 0.457890] jffs2: version 2.2 (NAND) (SUMMARY) (LZMA) (RTIME) (CMODE_PRIORITY) (c) 2001-2006 Red Hat, Inc. [ 0.469900] cryptd: max_cpu_qlen set to 1000 [ 0.507693] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 249) [ 0.516851] mtk-pcie-gen3 11280000.pcie: host bridge /soc/pcie@11280000 ranges: [ 0.519869] Serial: 8250/16550 driver, 16 ports, IRQ sharing enabled [ 0.524282] mtk-pcie-gen3 11280000.pcie: Parsing ranges property... [ 0.533543] printk: legacy console [ttyS0] disabled [ 0.536986] mtk-pcie-gen3 11280000.pcie: IO 0x0020000000..0x00201fffff -> 0x0020000000 [ 0.550408] mtk-pcie-gen3 11280000.pcie: MEM 0x0020200000..0x002fffffff -> 0x0020200000 [ 0.579192] 11000000.serial: ttyS0 at MMIO 0x11000000 (irq = 65, base_baud = 2500000) is a ST16650V2 [ 0.588436] printk: legacy console [ttyS0] enabled [ 0.598030] printk: legacy bootconsole [uart8250] disabled [ 0.609782] mtk_rng soc:trng@1020f000: registered RNG driver [ 0.609824] random: crng init done [ 0.621078] loop: module loaded [ 0.627079] spi-nand spi0.0: calibration result: 0x2 [ 0.632169] spi-nand spi0.0: Macronix SPI NAND was found. [ 0.637558] spi-nand spi0.0: 512 MiB, block size: 256 KiB, page size: 4096, OOB size: 128 [ 0.646398] Signature found at block 2047 [0x1ffc0000] [ 0.651531] NMBM management region starts at block 1920 [0x1e000000] [ 0.659199] First info table with writecount 0 found in block 1920 [ 0.663712] mtk-pcie-gen3 11280000.pcie: set IO trans window[0]: cpu_addr = 0x20000000, pci_addr = 0x20000000, size = 0x200000 [ 0.676757] mtk-pcie-gen3 11280000.pcie: set MEM trans window[1]: cpu_addr = 0x20200000, pci_addr = 0x20200000, size = 0x200000 [ 0.688228] mtk-pcie-gen3 11280000.pcie: set MEM trans window[2]: cpu_addr = 0x20400000, pci_addr = 0x20400000, size = 0x400000 [ 0.699697] mtk-pcie-gen3 11280000.pcie: set MEM trans window[3]: cpu_addr = 0x20800000, pci_addr = 0x20800000, size = 0x800000 [ 0.711171] mtk-pcie-gen3 11280000.pcie: set MEM trans window[4]: cpu_addr = 0x21000000, pci_addr = 0x21000000, size = 0x1000000 [ 0.722732] mtk-pcie-gen3 11280000.pcie: set MEM trans window[5]: cpu_addr = 0x22000000, pci_addr = 0x22000000, size = 0x2000000 [ 0.734287] mtk-pcie-gen3 11280000.pcie: set MEM trans window[6]: cpu_addr = 0x24000000, pci_addr = 0x24000000, size = 0x4000000 [ 0.745842] mtk-pcie-gen3 11280000.pcie: set MEM trans window[7]: cpu_addr = 0x28000000, pci_addr = 0x28000000, size = 0x8000000 [ 0.757755] mtk-pcie-gen3 11280000.pcie: PCI host bridge to bus 0000:00 [ 0.764381] pci_bus 0000:00: root bus resource [bus 00-ff] [ 0.769864] pci_bus 0000:00: root bus resource [io 0x0000-0x1fffff] (bus address [0x20000000-0x201fffff]) [ 0.779510] pci_bus 0000:00: root bus resource [mem 0x20200000-0x2fffffff] [ 0.786382] pci_bus 0000:00: scanning bus [ 0.790457] pci 0000:00:00.0: [14c3:7987] type 01 class 0x060400 PCIe Root Port [ 0.797782] pci 0000:00:00.0: BAR 0 [mem 0x00000000-0x00007fff 64bit] [ 0.804224] pci 0000:00:00.0: PCI bridge to [bus 00] [ 0.809186] pci 0000:00:00.0: bridge window [io 0x0000-0x0fff] [ 0.815276] pci 0000:00:00.0: bridge window [mem 0x00000000-0x000fffff] [ 0.822070] pci 0000:00:00.0: bridge window [mem 0x00000000-0x000fffff 64bit pref] [ 0.829872] pci 0000:00:00.0: PME# supported from D0 D3hot D3cold [ 0.835965] pci 0000:00:00.0: PME# disabled [ 0.841183] pci_bus 0000:00: fixups for bus [ 0.845368] pci 0000:00:00.0: scanning [bus 00-00] behind bridge, pass 0 [ 0.852065] pci 0000:00:00.0: bridge configuration invalid ([bus 00-00]), reconfiguring [ 0.860063] pci 0000:00:00.0: scanning [bus 00-00] behind bridge, pass 1 [ 0.866848] pci_bus 0000:01: scanning bus [ 0.870921] pci 0000:01:00.0: [14c3:7993] type 00 class 0x028000 PCIe Endpoint [ 0.878224] pci 0000:01:00.0: BAR 0 [mem 0x00000000-0x001fffff 64bit] [ 0.884669] pci 0000:01:00.0: BAR 2 [mem 0x00000000-0x00007fff 64bit] [ 0.891270] pci 0000:01:00.0: PME# supported from D0 D3hot D3cold [ 0.897361] pci 0000:01:00.0: PME# disabled [ 0.897377] Second info table with writecount 0 found in block 1923 [ 0.907804] NMBM has been successfully attached [ 0.912483] 7 fixed-partitions partitions found on MTD device spi0.0 [ 0.919039] Creating 7 MTD partitions on "spi0.0": [ 0.920674] pci 0000:01:00.0: ASPM: default states L1 [ 0.923829] 0x000000000000-0x000000100000 : "BL2" [ 0.928876] pci_bus 0000:01: fixups for bus [ 0.937737] pci_bus 0000:01: bus scan returning with max=01 [ 0.943314] pci_bus 0000:01: busn_res: [bus 01-ff] end is updated to 01 [ 0.949927] pci_bus 0000:00: bus scan returning with max=01 [ 0.955517] pci 0000:00:00.0: bridge window [mem 0x20200000-0x204fffff]: assigned [ 0.962997] pci 0000:00:00.0: BAR 0 [mem 0x20500000-0x20507fff 64bit]: assigned [ 0.970307] pci 0000:01:00.0: BAR 0 [mem 0x20200000-0x203fffff 64bit]: assigned [ 0.977630] pci 0000:01:00.0: BAR 2 [mem 0x20400000-0x20407fff 64bit]: assigned [ 0.984952] pci 0000:00:00.0: PCI bridge to [bus 01] [ 0.989914] pci 0000:00:00.0: bridge window [mem 0x20200000-0x204fffff] [ 0.996703] pci_bus 0000:00: resource 4 [io 0x0000-0x1fffff] [ 1.002447] pci_bus 0000:00: resource 5 [mem 0x20200000-0x2fffffff] [ 1.008706] pci_bus 0000:01: resource 1 [mem 0x20200000-0x204fffff] [ 1.009063] 0x000000100000-0x000000180000 : "u-boot-env" [ 1.014979] pci 0000:00:00.0: Max Payload Size set to 256/ 256 (was 128), Max Read Rq 256 [ 1.028726] pci 0000:01:00.0: Max Payload Size set to 256/ 256 (was 128), Max Read Rq 256 [ 1.037177] pci 0000:00:00.0: save config 0x00: 0x798714c3 [ 1.042666] pci 0000:00:00.0: save config 0x04: 0x00100000 [ 1.048145] pci 0000:00:00.0: save config 0x08: 0x06040001 [ 1.053627] pci 0000:00:00.0: save config 0x0c: 0x00010000 [ 1.053914] 0x000000180000-0x000000580000 : "Factory" [ 1.059101] pci 0000:00:00.0: save config 0x10: 0x20500004 [ 1.069624] pci 0000:00:00.0: save config 0x14: 0x00000000 [ 1.075106] pci 0000:00:00.0: save config 0x18: 0x00010100 [ 1.080584] pci 0000:00:00.0: save config 0x1c: 0x000001f1 [ 1.086065] pci 0000:00:00.0: save config 0x20: 0x20402020 [ 1.091548] pci 0000:00:00.0: save config 0x24: 0x0001fff1 [ 1.097025] pci 0000:00:00.0: save config 0x28: 0x00000000 [ 1.102506] pci 0000:00:00.0: save config 0x2c: 0x00000000 [ 1.107984] pci 0000:00:00.0: save config 0x30: 0x00000000 [ 1.113467] pci 0000:00:00.0: save config 0x34: 0x00000080 [ 1.118944] pci 0000:00:00.0: save config 0x38: 0x00000000 [ 1.124425] pci 0000:00:00.0: save config 0x3c: 0x00020100 [ 1.130079] pcieport 0000:00:00.0: assign IRQ: got 68 [ 1.135136] pcieport 0000:00:00.0: enabling device (0000 -> 0002) [ 1.141240] pcieport 0000:00:00.0: enabling bus mastering [ 1.147183] mtk-pcie-gen3 11280000.pcie: msi#0x0 address_hi 0x0 address_lo 0x11280c00 data 0 [ 1.155633] mtk-pcie-gen3 11280000.pcie: msi#0x1 address_hi 0x0 address_lo 0x11280c00 data 1 [ 1.164072] mtk-pcie-gen3 11280000.pcie: msi#0x2 address_hi 0x0 address_lo 0x11280c00 data 2 [ 1.172507] mtk-pcie-gen3 11280000.pcie: msi#0x3 address_hi 0x0 address_lo 0x11280c00 data 3 [ 1.180939] mtk-pcie-gen3 11280000.pcie: msi#0x4 address_hi 0x0 address_lo 0x11280c00 data 4 [ 1.189367] mtk-pcie-gen3 11280000.pcie: msi#0x5 address_hi 0x0 address_lo 0x11280c00 data 5 [ 1.197799] mtk-pcie-gen3 11280000.pcie: msi#0x6 address_hi 0x0 address_lo 0x11280c00 data 6 [ 1.206237] mtk-pcie-gen3 11280000.pcie: msi#0x7 address_hi 0x0 address_lo 0x11280c00 data 7 [ 1.214669] mtk-pcie-gen3 11280000.pcie: msi#0x8 address_hi 0x0 address_lo 0x11280c00 data 8 [ 1.223100] mtk-pcie-gen3 11280000.pcie: msi#0x9 address_hi 0x0 address_lo 0x11280c00 data 9 [ 1.231532] mtk-pcie-gen3 11280000.pcie: msi#0xa address_hi 0x0 address_lo 0x11280c00 data 10 [ 1.240047] mtk-pcie-gen3 11280000.pcie: msi#0xb address_hi 0x0 address_lo 0x11280c00 data 11 [ 1.248565] mtk-pcie-gen3 11280000.pcie: msi#0xc address_hi 0x0 address_lo 0x11280c00 data 12 [ 1.257085] mtk-pcie-gen3 11280000.pcie: msi#0xd address_hi 0x0 address_lo 0x11280c00 data 13 [ 1.265606] mtk-pcie-gen3 11280000.pcie: msi#0xe address_hi 0x0 address_lo 0x11280c00 data 14 [ 1.266158] 0x000000580000-0x000000780000 : "FIP" [ 1.274126] mtk-pcie-gen3 11280000.pcie: msi#0xf address_hi 0x0 address_lo 0x11280c00 data 15 [ 1.287346] mtk-pcie-gen3 11280000.pcie: msi#0x10 address_hi 0x0 address_lo 0x11280c00 data 16 [ 1.295954] mtk-pcie-gen3 11280000.pcie: msi#0x11 address_hi 0x0 address_lo 0x11280c00 data 17 [ 1.304561] mtk-pcie-gen3 11280000.pcie: msi#0x12 address_hi 0x0 address_lo 0x11280c00 data 18 [ 1.313167] mtk-pcie-gen3 11280000.pcie: msi#0x13 address_hi 0x0 address_lo 0x11280c00 data 19 [ 1.321773] mtk-pcie-gen3 11280000.pcie: msi#0x14 address_hi 0x0 address_lo 0x11280c00 data 20 [ 1.330376] mtk-pcie-gen3 11280000.pcie: msi#0x15 address_hi 0x0 address_lo 0x11280c00 data 21 [ 1.338982] mtk-pcie-gen3 11280000.pcie: msi#0x16 address_hi 0x0 address_lo 0x11280c00 data 22 [ 1.347588] mtk-pcie-gen3 11280000.pcie: msi#0x17 address_hi 0x0 address_lo 0x11280c00 data 23 [ 1.356195] mtk-pcie-gen3 11280000.pcie: msi#0x18 address_hi 0x0 address_lo 0x11280c00 data 24 [ 1.364805] mtk-pcie-gen3 11280000.pcie: msi#0x19 address_hi 0x0 address_lo 0x11280c00 data 25 [ 1.373414] mtk-pcie-gen3 11280000.pcie: msi#0x1a address_hi 0x0 address_lo 0x11280c00 data 26 [ 1.382020] mtk-pcie-gen3 11280000.pcie: msi#0x1b address_hi 0x0 address_lo 0x11280c00 data 27 [ 1.390630] mtk-pcie-gen3 11280000.pcie: msi#0x1c address_hi 0x0 address_lo 0x11280c00 data 28 [ 1.399232] mtk-pcie-gen3 11280000.pcie: msi#0x1d address_hi 0x0 address_lo 0x11280c00 data 29 [ 1.407841] mtk-pcie-gen3 11280000.pcie: msi#0x1e address_hi 0x0 address_lo 0x11280c00 data 30 [ 1.416452] mtk-pcie-gen3 11280000.pcie: msi#0x1f address_hi 0x0 address_lo 0x11280c00 data 31 [ 1.425819] 0x000000780000-0x0000007c0000 : "log" [ 1.425877] mtk-pcie-gen3 11280000.pcie: msi#0x0 address_hi 0x0 address_lo 0x11280c00 data 0 [ 1.430924] 0x0000007c0000-0x000000800000 : "CFG" [ 1.439087] pcieport 0000:00:00.0: PME: Signaling with IRQ 69 [ 1.444080] 0x000000800000-0x00001e000000 : "ubi" [ 1.449545] pcieport 0000:00:00.0: AER: enabled with IRQ 69 [ 1.459746] pcieport 0000:00:00.0: bwctrl: enabled with IRQ 69 [ 1.465597] pcieport 0000:00:00.0: save config 0x00: 0x798714c3 [ 1.471516] pcieport 0000:00:00.0: save config 0x04: 0x00100406 [ 1.477427] pcieport 0000:00:00.0: save config 0x08: 0x06040001 [ 1.483340] pcieport 0000:00:00.0: save config 0x0c: 0x00010000 [ 1.489250] pcieport 0000:00:00.0: save config 0x10: 0x20500004 [ 1.495161] pcieport 0000:00:00.0: save config 0x14: 0x00000000 [ 1.501074] pcieport 0000:00:00.0: save config 0x18: 0x00010100 [ 1.506983] pcieport 0000:00:00.0: save config 0x1c: 0x000001f1 [ 1.512895] pcieport 0000:00:00.0: save config 0x20: 0x20402020 [ 1.518805] pcieport 0000:00:00.0: save config 0x24: 0x0001fff1 [ 1.524717] pcieport 0000:00:00.0: save config 0x28: 0x00000000 [ 1.530628] pcieport 0000:00:00.0: save config 0x2c: 0x00000000 [ 1.536537] pcieport 0000:00:00.0: save config 0x30: 0x00000000 [ 1.542449] pcieport 0000:00:00.0: save config 0x34: 0x00000080 [ 1.548358] pcieport 0000:00:00.0: save config 0x38: 0x00000000 [ 1.554271] pcieport 0000:00:00.0: save config 0x3c: 0x00020144 [ 1.560267] pci 0000:01:00.0: save config 0x00: 0x799314c3 [ 1.565750] pci 0000:01:00.0: save config 0x04: 0x00100000 [ 1.571231] pci 0000:01:00.0: save config 0x08: 0x02800000 [ 1.576708] pci 0000:01:00.0: save config 0x0c: 0x00000000 [ 1.582189] pci 0000:01:00.0: save config 0x10: 0x20200004 [ 1.587666] pci 0000:01:00.0: save config 0x14: 0x00000000 [ 1.593150] pci 0000:01:00.0: save config 0x18: 0x20400004 [ 1.598626] pci 0000:01:00.0: save config 0x1c: 0x00000000 [ 1.604106] pci 0000:01:00.0: save config 0x20: 0x00000000 [ 1.609582] pci 0000:01:00.0: save config 0x24: 0x00000000 [ 1.615062] pci 0000:01:00.0: save config 0x28: 0x00000000 [ 1.620538] pci 0000:01:00.0: save config 0x2c: 0x799314c3 [ 1.626018] pci 0000:01:00.0: save config 0x30: 0x00000000 [ 1.631497] pci 0000:01:00.0: save config 0x34: 0x00000080 [ 1.636974] pci 0000:01:00.0: save config 0x38: 0x00000000 [ 1.642454] pci 0000:01:00.0: save config 0x3c: 0x00000100 [ 1.717052] ubi0: default fastmap pool size: 90 [ 1.721608] ubi0: default fastmap WL pool size: 45 [ 1.726389] ubi0: attaching mtd6 [ 2.948392] ubi0: scanning is finished [ 2.956524] ubi0 warning: ubi_eba_init: cannot reserve enough PEBs for bad PEB handling, reserved 36, need 38 [ 2.966986] ubi0: attached mtd6 (name "ubi", size 472 MiB) [ 2.972487] ubi0: PEB size: 262144 bytes (256 KiB), LEB size: 253952 bytes [ 2.979351] ubi0: min./max. I/O unit sizes: 4096/4096, sub-page size 4096 [ 2.986130] ubi0: VID header offset: 4096 (aligned 4096), data offset: 8192 [ 2.993085] ubi0: good PEBs: 1888, bad PEBs: 0, corrupted PEBs: 0 [ 2.999166] ubi0: user volume: 3, internal volumes: 1, max. volumes count: 128 [ 3.006379] ubi0: max/mean erase counter: 6/3, WL threshold: 4096, image sequence number: 1755502931 [ 3.015502] ubi0: available PEBs: 0, total reserved PEBs: 1888, PEBs reserved for bad PEB handling: 36 [ 3.024803] ubi0: background thread "ubi_bgt0d" started, PID 330 [ 3.025546] block ubiblock0_1: created from ubi0:1(rootfs) [ 3.036286] ubiblock: device ubiblock0_1 (rootfs) set to be root filesystem [ 3.047165] mtk_soc_eth 15100000.ethernet: legacy DT: missing interrupt-names. [ 3.172146] i2c_dev: i2c /dev entries driver [ 3.176878] mtk-lvts-thermal 1100a000.lvts: golden temp=60 [ 3.183665] mtk-wdt 1001c000.watchdog: Watchdog enabled (timeout=31 sec, nowayout=0) [ 3.192884] NET: Registered PF_INET6 protocol family [ 3.198389] Segment Routing with IPv6 [ 3.202086] In-situ OAM (IOAM) with IPv6 [ 3.206041] NET: Registered PF_PACKET protocol family [ 3.211111] bridge: filtering via arp/ip/ip6tables is no longer available by default. Update your scripts to load br_netfilter if you need this. [ 3.224176] 8021q: 802.1Q VLAN Support v1.8 [ 3.242021] phy phy-soc:usb-phy@11c50000.1: type_sw - reg 0x218, index 0 [ 3.250136] mtk_soc_eth 15100000.ethernet: legacy DT: missing interrupt-names. [ 3.615847] mtk_soc_eth 15100000.ethernet eth0: mediatek frame engine at 0xffffffc082280000, irq 71 [ 3.626071] mtk_soc_eth 15100000.ethernet eth1: mediatek frame engine at 0xffffffc082280000, irq 71 [ 3.635666] clk: Disabling unused clocks [ 3.639941] PM: genpd: Disabling unused power domains [ 3.645150] check access for rdinit=/init failed: -2, ignoring [ 3.656225] VFS: Mounted root (squashfs filesystem) readonly on device 254:0. [ 3.663739] Freeing unused kernel memory: 960K [ 3.668227] Run /sbin/init as init process [ 3.672349] with arguments: [ 3.675306] /sbin/init [ 3.678002] with environment: [ 3.681136] HOME=/ [ 3.683485] TERM=linux [ 3.895316] init: Console is alive [ 3.898847] init: - watchdog - [ 4.184113] kmodloader: loading kernel modules from /etc/modules-boot.d/* [ 4.245010] MediaTek MT7987 2.5GbE PHY mdio-bus:0f: Firmware date code: 2025/8/22, version: 7.10 [ 4.265566] MediaTek MT7987 2.5GbE PHY mdio-bus:0f: Firmware loading/trigger ok. [ 4.278515] usbcore: registered new interface driver usbfs [ 4.284068] usbcore: registered new interface driver hub [ 4.289401] usbcore: registered new device driver usb [ 4.295099] gpio_button_hotplug: loading out-of-tree module taints kernel. [ 4.306536] xhci-mtk 11200000.usb: supply vusb33 not found, using dummy regulator [ 4.314754] xhci-mtk 11200000.usb: xHCI Host Controller [ 4.319992] xhci-mtk 11200000.usb: new USB bus registered, assigned bus number 1 [ 4.330489] xhci-mtk 11200000.usb: hcc params 0x01443f99 hci version 0x120 quirks 0x0000000020200010 [ 4.339655] xhci-mtk 11200000.usb: irq 74, io mem 0x11200000 [ 4.345428] xhci-mtk 11200000.usb: xHCI Host Controller [ 4.350655] xhci-mtk 11200000.usb: new USB bus registered, assigned bus number 2 [ 4.358043] xhci-mtk 11200000.usb: Host supports USB 3.2 Enhanced SuperSpeed [ 4.365418] hub 1-0:1.0: USB hub found [ 4.369175] hub 1-0:1.0: 1 port detected [ 4.373470] usb usb2: We don't know the algorithms for LPM for this host, disabling LPM. [ 4.381812] hub 2-0:1.0: USB hub found [ 4.385569] hub 2-0:1.0: 1 port detected [ 4.393444] kmodloader: done loading kernel modules from /etc/modules-boot.d/* [ 4.406080] init: - preinit - [ 4.640681] mtk_soc_eth 15100000.ethernet eth0: PHY [mdio-bus:07] driver [RTL8221B-VB-CG 2.5Gbps PHY] (irq=56) [ 4.657914] mtk_soc_eth 15100000.ethernet eth0: configuring for phy/2500base-x link mode [ 8.895291] UBIFS (ubi0:2): default file-system created [ 8.900826] UBIFS (ubi0:2): Mounting in unauthenticated mode [ 8.906555] UBIFS (ubi0:2): background thread "ubifs_bgt0_2" started, PID 879 [ 8.966364] UBIFS (ubi0:2): UBIFS: mounted UBI device 0, volume 2, name "rootfs_data" [ 8.974231] UBIFS (ubi0:2): LEB size: 253952 bytes (248 KiB), min./max. I/O unit sizes: 4096 bytes/4096 bytes [ 8.984144] UBIFS (ubi0:2): FS size: 455081984 bytes (434 MiB, 1792 LEBs), max 1804 LEBs, journal size 22855680 bytes (21 MiB, 90 LEBs) [ 8.996306] UBIFS (ubi0:2): reserved for root: 4952683 bytes (4836 KiB) [ 9.002915] UBIFS (ubi0:2): media format: w5/r0 (latest is w5/r0), UUID 5CD7F201-64C9-43BD-84F6-0132D4C68861, small LPT model [ 9.015929] mount_root: overlay filesystem has not been fully initialized yet [ 9.023269] mount_root: switching to ubifs overlay [ 9.030120] overlayfs: null uuid detected in lower fs '/', falling back to xino=off,index=off,nfs_export=off. [ 9.041776] urandom-seed: Seed file not found (/etc/urandom.seed) [ 9.082696] procd: - early - [ 9.085634] procd: - watchdog - [ 9.616635] procd: - watchdog - [ 9.620142] procd: - ubus - [ 9.673992] procd: - init - [ 9.890869] kmodloader: loading kernel modules from /etc/modules.d/* [ 9.921958] crypto-safexcel 15600000.crypto: EIP196:121(0,1,4,4)-HIA:282(0,6,6),PE:152/480(alg:7fc1ff00)/0/0/0 [ 9.936246] Loading modules backported from Linux version v6.18.26-0-g1fe060681 [ 9.943595] Backport generated by backports.git 6ecbb44 [ 10.011468] mt7996e 0000:01:00.0: assign IRQ: got 68 [ 10.016463] mt7996e 0000:01:00.0: enabling device (0000 -> 0002) [ 10.022115] urngd: v1.0.2 started. [ 10.022676] mt7996e 0000:01:00.0: enabling bus mastering [ 10.031359] mtk-pcie-gen3 11280000.pcie: msi#0x1 address_hi 0x0 address_lo 0x11280c00 data 1 [ 10.061264] mt7996e 0000:01:00.0: HW/SW Version: 0x8a108a10, Build Time: 20251226114358a [ 10.061264] [ 10.187757] mt7996e 0000:01:00.0: WM Firmware Version: ____000000, Build Time: 20251226114509 [ 13.544134] PPP generic driver version 2.4.2 [ 13.549381] NET: Registered PF_PPPOX protocol family [ 13.557520] kmodloader: done loading kernel modules from /etc/modules.d/* [ 18.792894] mtk_soc_eth 15100000.ethernet eth1: PHY [mdio-bus:0f] driver [MediaTek MT7987 2.5GbE PHY] (irq=POLL) [ 18.811326] mtk_soc_eth 15100000.ethernet eth1: configuring for phy/internal link mode [ 18.822106] br-lan: port 1(eth1) entered blocking state [ 18.827347] br-lan: port 1(eth1) entered disabled state [ 18.832629] mtk_soc_eth 15100000.ethernet eth1: entered allmulticast mode [ 18.839579] mtk_soc_eth 15100000.ethernet eth1: entered promiscuous mode [ 19.010681] mtk_soc_eth 15100000.ethernet eth0: PHY [mdio-bus:07] driver [RTL8221B-VB-CG 2.5Gbps PHY] (irq=56) [ 19.020976] mtk_soc_eth 15100000.ethernet eth0: configuring for phy/2500base-x link mode [ 24.020825] mtk_soc_eth 15100000.ethernet eth1: Link is Up - 2.5Gbps/Full - flow control rx/tx [ 24.029468] br-lan: port 1(eth1) entered blocking state [ 24.034692] br-lan: port 1(eth1) entered forwarding state [ 35.440684] mtk_soc_eth 15100000.ethernet eth1: Link is Down [ 35.447919] br-lan: port 1(eth1) entered disabled state [ 61.460816] mtk_soc_eth 15100000.ethernet eth1: Link is Up - 2.5Gbps/Full - flow control rx/tx [ 61.469453] br-lan: port 1(eth1) entered blocking state [ 61.474679] br-lan: port 1(eth1) entered forwarding state root@OpenWrt:~#

GL.iNET product page: https://www.gl-inet.com/products/gl-mt3600be
OEM stable firmware: https://dl.gl-inet.com/router/mt3600be/stable
FCCID page: https://fccid.io/2AFIW-MT3600BE

OpenWrt Forum thread: https://forum.openwrt.org/t/gl-inet-beryl-7-gl-mt3600be/241924

See also AsiaRF AW7990-NPD PCIe module - with the same MT7990 WLAN chipset inside GL-MT3600BE
- mt7990 WLAN performance problem in the same AW7990-NPD PCIe module:
  - mt76 Issue #1065 & mt76 Issue #1043
  - OpenWrt Forum thread: Beryl7: fixed the broken TX path on the MT7990

mediatek mt7987 4core 512nand 512ram 2port 2.5gigabitethernet mt7990 2wnic 2x2 802.11bgn 802.11anac 802.11ax 802.11be wifi7 2ant nondetachableantenna 1usb usb3.0 hwvlan filogic armv8 cortexa53 u-boot serial crypto portable router 5v powered usb powered
