Eltex RG-5520G-Wax

Bismarck Preloader 3.7 II: LPLR:11261 PLR:525b23cd BD:24103107 TK:msdk-4.8.5-mips-EB-4.4-u0.9.33-m32ut-180206 II: TLB initial done: .ro section works! .text and .ro sections work! II: CPU0 1250MHz, CPU1 800MHz, DRAM 666MHz, LX 200MHz, SRAM 500MHz, SPIF 100MHz AK: ******* DRAM calibration version: v5.4 ******* AK: MEMPLL[31/63/95/127/159/191/223]=907f, c0000210, 64237c0, 320f0030, fff, a7f, 0 AK: TP=3, VD=1, CC=3, OT=2, EP=0 AK: DRAM type = DDR3, Freq. = 666 MHz ZQ: Clock: ODT/OCD=60/48, zq_zctrl_prog=0x c08033e, zq_zctrl_status=0x20a144 ZQ: Address: ODT/OCD=60/80, zq_zctrl_prog=0x1c080332, zq_zctrl_status=0x20a111 ZQ: DQ: ODT/OCD=60/60, zq_zctrl_prog=0x2c080338, zq_zctrl_status=0x20a133 ZQ: DQS: ODT/OCD=60/60, zq_zctrl_prog=0x3c080338, zq_zctrl_status=0x20a133 ZQ: INTERAL DDR3, ZQCL done, ZQCS Enable AK: MRS: mr[0]=0x101a50, mr[1]=0x110004, mr[2]=0x120010, mr[3]=0x130000 AK: Bit/max_r_s/max_r_l/max_w_s/max_w_l Bit/max_r_s/max_r_l/max_w_s/max_w_l [ 0] 0 1f 0 1d [16] 0 1f 0 1f [ 1] 0 1f 0 1d [17] 0 1f 0 1f [ 2] 0 1f 0 1f [18] 0 1f 0 1f [ 3] 0 1f 0 1d [19] 0 1f 0 1f [ 4] 0 1f 0 1b [20] 0 1f 0 1d [ 5] 0 1f 0 1f [21] 0 1f 0 1f [ 6] 0 1f 0 1d [22] 0 1f 0 1f [ 7] 0 1f 0 1d [23] 0 1f 0 1d [ 8] 0 1f 0 1b [24] 0 1f 0 1d [ 9] 0 1f 0 1d [25] 0 1f 0 1f [10] 0 1f 0 1b [26] 0 1f 0 1d [11] 0 1f 0 1b [27] 0 1f 0 1d [12] 0 1f 0 1b [28] 0 1f 0 1d [13] 0 1f 0 1b [29] 0 1f 0 1d [14] 0 1f 0 1b [30] 0 1f 0 1f [15] 0 1f 0 1d [31] 0 1f 0 1f AK: DRAM size=0x10000000, tRFC[2]=0x165(nS), tREF=1729(nS) AK: DCR=0x21321003, DTR[0:2]=0x99655828, 0x909061f, 0x6f19000 II: Change Stack from 0x9f002edc to 0x806fffe0 Set GPIO 60 as output II: U-boot Magic Number is 0x27051956 II: Inflating U-Boot (0x80700040 -> 0x83c00000)... OK II: Starting U-boot... U-Boot 2020.01 (Oct 31 2024 - 07:40:09 +0000) Board: RTL9607cv2, MIPS interAptiv:1250MHz RLX5281:800MHz LX:200MHz DDR3:666MHz SCLK:100MHz ICACHE: 64KB (32-byte/4-way/512-set) DCACHE: 32KB (32-byte/4-way/256-set) DRAM: Physical 256 MiB, uboot useable size 256 MiB SPI NAND: 0xC851, Mode(111/111) Create bbt: NAND: 128 MiB Loading Environment from NAND... OK In: serial Out: serial Err: serial II: Init Software Patch! II: Configurate otto_flash_layout Saving Environment to NAND... Erasing redundant NAND... Erasing at 0x100000 -- 100% complete. Writing to redundant NAND... OK OK NAND read: device 0 offset 0x0, size 0xc0000 786432 bytes read: OK CRC32 for 83c60000 ... 83d1ffff ==> 57561c13 Net: LUNA GMAC Warning: eth device name has a space! Type 'stop' to abort autoboot (wait 3 seconds) ubi0: attaching mtd5 ubi0: scanning is finished ubi0: attached mtd5 (name "ubi_device", size 121 MiB) ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048 ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096 ubi0: good PEBs: 970, bad PEBs: 0, corrupted PEBs: 0 ubi0: user volume: 9, internal volumes: 1, max. volumes count: 128 ubi0: max/mean erase counter: 4/1, WL threshold: 4096, image sequence number: 95652907 ubi0: available PEBs: 0, total reserved PEBs: 970, PEBs reserved for bad PEB handling: 17 No size specified -> Using max size (10539008) Read 10539008 bytes from volume ubi_k1 to 83000000 ## Booting kernel from Legacy Image at 83000000 ... Image Name: Linux-4.4.140 Image Type: MIPS Linux Kernel Image (gzip compressed) Data Size: 4092910 Bytes = 3.9 MiB Load Address: 80010000 Entry Point: 806a41f0 Verifying Checksum ... OK Uncompressing Kernel Image DEBUG_MEM_AUTO: DCR=0x21321003 DEBUG_MEM_AUTO: [bsp_prom_memmap]add_memory_region(0, 268435456, BOOT_MEM_RAM) DEBUG_MEM_AUTO: [bsp_prom_memmap]add_memory_region(0x00000000, 0x10000000, BOOT_MEM_RAM) [ 0.000000] Linux version 4.4.140 (jenkins@665cc499d49b) (gcc version 4.8.5 20150209 (prerelease) (Realtek MSDK-4.8.5p1 Build 2536) ) #2 SMP Tue Sep 30 08:03:28 UTC 2025 [ 0.000000] =============Enter: luna_uart1_pinmux============= [ 0.000000] GPIO setting/0xbb000038 0x00000010 [ 0.000000] LED setting/0xbb023010 0x00000000 [ 0.000000] IO mode setting/0xbb023014 0x00020058 [ 0.000000] IO_UART_SEL_REG/0xbb000034 0x00000404 [ 0.000000] Disabled GPIO/LED pin-mux with UART1. [ 0.000000] =============Exit: luna_uart1_pinmux============= [ 0.000000] MIPS: machine is Realtek Semiconductor RTL8198D [ 0.000000] [L2_DEBUG:(bsp_scache_config,54)] - L2_Bypass: Disable [ 0.000000] [L2_DEBUG:(bsp_setup_scache,82)]SCache LineSize= 32 (B) [ 0.000000] Disable SRAM PLL...done [ 0.000000] bootconsole [early0] enabled [ 0.000000] CPU0 revision is: 0001a120 (MIPS interAptiv (multi)) [ 0.000000] MIPS: machine is rtk,8198d [ 0.000000] Determined physical RAM map: [ 0.000000] memory: 10000000 @ 00000000 (usable) [ 0.000000] Zone ranges: [ 0.000000] Normal [mem 0x0000000000000000-0x000000000fffffff] [ 0.000000] Movable zone start for each node [ 0.000000] Early memory node ranges [ 0.000000] node 0: [mem 0x0000000000000000-0x000000000fffffff] [ 0.000000] Initmem setup node 0 [mem 0x0000000000000000-0x000000000fffffff] [ 0.000000] VPE topology {2,2} total 4 [ 0.000000] Primary instruction cache 64kB, VIPT, 4-way, linesize 32 bytes. [ 0.000000] Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes [ 0.000000] MIPS secondary cache 256kB, 8-way, linesize 32 bytes. [ 0.000000] PERCPU: Embedded 13 pages/cpu @81207000 s20928 r8192 d24128 u53248 [ 0.000000] Built 1 zonelists in Zone order, mobility grouping on. Total pages: 65024 [ 0.000000] Kernel command line: console=ttyS0,115200 ubi.mtd=4 root=31:10 rootfs=squashfs mtdparts=spinand:768K(boot),128K(factory),128K(env),128K(env2),124160K(ubi_device),2M(mtdoops) [ 0.000000] PID hash table entries: 1024 (order: 0, 4096 bytes) [ 0.000000] Dentry cache hash table entries: 32768 (order: 5, 131072 bytes) [ 0.000000] Inode-cache hash table entries: 16384 (order: 4, 65536 bytes) [ 0.000000] Writing ErrCtl register=00000000 [ 0.000000] Readback ErrCtl register=00000000 [ 0.000000] Memory: 246304K/262144K available (6769K kernel code, 4079K rwdata, 1788K rodata, 244K init, 274K bss, 15840K reserved, 0K cma-reserved) [ 0.000000] Hierarchical RCU implementation. [ 0.000000] Build-time adjustment of leaf fanout to 32. [ 0.000000] NR_IRQS:256 [ 0.000000] CPU clock is 1250 [ 0.000000] [apro_clocks_init]clk_data.clk_num=2, ocp=1250000000, lx=200000000 [ 0.000000] clocksource: GIC: mask: 0xffffffffffffffff max_cycles: 0x12049cd048c, max_idle_ns: 440795204120 ns [ 0.000000] sched_clock: 32 bits at 100 Hz, resolution 10000000ns, wraps every 21474836475000000ns [ 0.010000] Calibrating delay loop... 829.84 BogoMIPS (lpj=4149248) [ 0.050000] pid_max: default: 32768 minimum: 301 [ 0.050000] Mount-cache hash table entries: 1024 (order: 0, 4096 bytes) [ 0.060000] Mountpoint-cache hash table entries: 1024 (order: 0, 4096 bytes) [ 0.060000] Primary instruction cache 64kB, VIPT, 4-way, linesize 32 bytes. [ 0.060000] Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes [ 0.060000] MIPS secondary cache 256kB, 8-way, linesize 32 bytes. [ 0.070000] CPU1 revision is: 0001a120 (MIPS interAptiv (multi)) [ 0.130000] Synchronize counters for CPU 1: done. [ 0.130000] Primary instruction cache 64kB, VIPT, 4-way, linesize 32 bytes. [ 0.130000] Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes [ 0.130000] MIPS secondary cache 256kB, 8-way, linesize 32 bytes. [ 0.130000] CPU2 revision is: 0001a120 (MIPS interAptiv (multi)) [ 0.190000] Synchronize counters for CPU 2: done. [ 0.190000] Primary instruction cache 64kB, VIPT, 4-way, linesize 32 bytes. [ 0.190000] Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes [ 0.190000] MIPS secondary cache 256kB, 8-way, linesize 32 bytes. [ 0.190000] CPU3 revision is: 0001a120 (MIPS interAptiv (multi)) [ 0.250000] Synchronize counters for CPU 3: done. [ 0.250000] Brought up 4 CPUs [ 0.250000] devtmpfs: initialized [ 0.260000] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns [ 0.270000] futex hash table entries: 1024 (order: 3, 32768 bytes) [ 0.270000] NET: Registered protocol family 16 [ 0.280000] chipId 96070001, rev 3 [ 0.280000] Using revC phy [ 0.280000] RTK-PCI Init... [ 0.290000] PCIe Port0, PCIe PHY version: v003 (2021.12.14) [ 0.520000] Port0 Link@5.0Ghz [ 0.520000] Port0 link=1 irq=72 [ 0.520000] registering PCI controller with io_map_base unset [ 0.530000] PCIe Port1, PCIe PHY version: v003 (2021.12.14) [ 0.740000] Port1 Link@2.5GHz [ 0.740000] Port1 link=1 [ 0.750000] registering PCI controller with io_map_base unset [ 0.750000] RTK-PCI Done [ 0.830000] SCSI subsystem initialized [ 0.830000] usbcore: registered new interface driver usbfs [ 0.840000] usbcore: registered new interface driver hub [ 0.840000] usbcore: registered new device driver usb [ 0.850000] PCI host bridge to bus 0000:00 [ 0.850000] pci_bus 0000:00: root bus resource [mem 0x1a000000-0x1affffff] [ 0.860000] pci_bus 0000:00: root bus resource [io 0x18e00000-0x18e0ffff] [ 0.870000] pci_bus 0000:00: root bus resource [??? 0x00000000 flags 0x0] [ 0.880000] pci_bus 0000:00: No busn resource found for root bus, will use [bus 00-ff] [ 0.890000] pci 0000:00:00.0: bridge configuration invalid ([bus 00-00]), reconfiguring [ 0.890000] pci 0000:00:01.0: BAR 2: assigned [mem 0x1a000000-0x1a0fffff 64bit] [ 0.900000] pci 0000:00:01.0: BAR 0: assigned [io 0x18e00000-0x18e000ff] [ 0.910000] pci 0000:00:00.0: PCI bridge to [bus 01] [ 0.920000] PCI host bridge to bus 0000:02 [ 0.920000] pci_bus 0000:02: root bus resource [mem 0x19000000-0x19ffffff] [ 0.930000] pci_bus 0000:02: root bus resource [io 0x18c00000-0x18c0ffff] [ 0.940000] pci_bus 0000:02: root bus resource [??? 0x00000000 flags 0x0] [ 0.940000] pci_bus 0000:02: No busn resource found for root bus, will use [bus 02-ff] [ 0.950000] pci 0000:02:00.0: bridge configuration invalid ([bus 00-00]), reconfiguring [ 0.960000] pci 0000:02:01.0: BAR 2: assigned [mem 0x19000000-0x190fffff 64bit] [ 0.970000] pci 0000:02:01.0: BAR 0: assigned [io 0x18c00000-0x18c000ff] [ 0.980000] pci 0000:02:00.0: PCI bridge to [bus 03] [ 0.980000] clocksource: Switched to clocksource GIC [ 0.990000] NET: Registered protocol family 2 [ 0.990000] TCP established hash table entries: 2048 (order: 1, 8192 bytes) [ 0.990000] TCP bind hash table entries: 2048 (order: 2, 16384 bytes) [ 1.000000] TCP: Hash tables configured (established 2048 bind 2048) [ 1.010000] UDP hash table entries: 256 (order: 1, 8192 bytes) [ 1.020000] UDP-Lite hash table entries: 256 (order: 1, 8192 bytes) [ 1.020000] NET: Registered protocol family 1 [ 1.030000] USB: Using revC phy [ 1.040000] register USB PHY: ehci-phy, RTK USB PHY version: v3.0 (2022.01.05) [ 1.130000] [Kthread : luan_watchdog ] init complete! [ 1.140000] ************ Watchdog Setting **************** [ 1.140000] WDT_E=0, (1-enable, 0-disable) [ 1.150000] WDT_CLK_SC=3 [ 1.150000] PH1_TO=31 [ 1.150000] PH2_TO=0 [ 1.160000] WDT_RESET_MODE=0 [ 1.160000] ********************************************** [ 1.170000] ==== Luna Watchdog Regs ===== [ 1.170000] BSP_WDTCNTRR(0xb8003260): 0x00000000 [ 1.180000] BSP_WDTINTRR(0xb8003264): 0x00000000 [ 1.180000] BSP_WDTCTRLR(0xb8003268): 0xe7c00000 [ 1.190000] ================================= [ 1.190000] squashfs: version 4.0 (2009/01/31) Phillip Lougher [ 1.200000] ntfs: driver 2.1.32 [Flags: R/W]. [ 1.200000] fuse init (API version 7.23) [ 1.210000] io scheduler noop registered [ 1.210000] io scheduler deadline registered [ 1.220000] io scheduler cfq registered (default) [ 1.240000] rtk-mips-ia-gpio 1b000038.gpio-controller: resource - [mem 0x1b000038-0x1b000043 flags 0x200] mapped at 0xbb000038 [ 1.250000] rtk-mips-ia-gpio 1b000038.gpio-controller: resource - [mem 0x18003308-0x1800335b flags 0x200] mapped at 0xb8003308 [ 1.260000] rtk-mips-ia-gpio 1b000038.gpio-controller: Setting up IRQs for GPIO bank 0 [ 1.270000] rtk-mips-ia-gpio 1b000038.gpio-controller: Setting up IRQs for GPIO bank 1 [ 1.280000] rtk-mips-ia-gpio 1b000038.gpio-controller: Setting up IRQs for GPIO bank 2 [ 1.290000] devfn:0 vend:10ec dev:8196 cls:60400 pin:1 [ 1.290000] devfn:0 vend:10ec dev:8196 cls:60400 pin:1 [ 1.300000] Realtek GPIO Driver for Flash Reload Default [ 1.310000] rtk_gpio rtk_gpio: rtk_gpio_probe_item 34 is active low [ 1.310000] rtk_gpio rtk_gpio: rtk_gpio_probe_item 36 is active low [ 1.320000] rtk_gpio rtk_gpio: rtk_gpio_probe_item 5 is active low [ 1.330000] rtk_gpio rtk_gpio: rtk_gpio_probe_item 57 is active low [ 1.330000] rtk_gpio rtk_gpio: rtk_gpio_probe_item 3 is active low [ 1.340000] rtk_gpio rtk_gpio: rtk_gpio_probe_item 2 is active low [ 1.350000] rtk_gpio rtk_gpio: rtk_gpio_probe_item 25 is active low [ 1.350000] ----[ rtk gpio ]-------------------------------- [ 1.360000] [rtk_gpio_probe - 244]wps-gpio[34] [ 1.360000] [rtk_gpio_probe - 248]wifi-gpio[36] [ 1.370000] [rtk_gpio_probe - 252]reset-gpio[5] [ 1.380000] [rtk_gpio_probe - 256]sys-led-gpio[57] [ 1.380000] [rtk_gpio_probe - 264]usb-led-gpio[3] [ 1.390000] [rtk_gpio_probe - 272]power-g-led-gpio[2] [ 1.390000] [rtk_gpio_probe - 276]power-r-led-gpio[25] [ 1.430000] Serial: 8250/16550 driver, 2 ports, IRQ sharing disabled [ 1.430000] console [ttyS0] disabled [ 1.440000] 18002000.serial: ttyS0 at MMIO 0x18002000 (irq = 46, base_baud = 12327200) is a 16550A [ 1.450000] console [ttyS0] enabled [ 1.450000] console [ttyS0] enabled [ 1.460000] bootconsole [early0] disabled [ 1.460000] bootconsole [early0] disabled [ 1.470000] 18002100.serial: ttyS1 at MMIO 0x18002100 (irq = 47, base_baud = 12327200) is a 16550A [ 1.480000] Realtek Luna SPI NAND Flash Driver Rev:00:00:00 (ChaoYuan_Yang) [ 1.480000] [SPINAND] Blocks number under 6 are protected [ 1.490000] [SPINAND] Allow max 4 bits flip in blank page! [ 1.500000] Use RTK bb func [ 1.500000] Use RTK bb scan [ 1.500000] nand: device found, Manufacturer ID: 0xc8, Chip ID: 0x51 [ 1.510000] nand: ESMT [ 1.510000] nand: 128 MiB, SLC, erase size: 128 KiB, page size: 2048, OOB size: 64 [ 1.580000] good block number 1024 [ 1.580000] 6 cmdlinepart partitions found on MTD device spinand [ 1.590000] RTK: using dynamic nand partition [ 1.590000] Creating 6 MTD partitions on "spinand": [ 1.600000] 0x000000000000-0x0000000c0000 : "boot" [ 1.600000] 0x0000000c0000-0x0000000e0000 : "factory" [ 1.610000] 0x0000000e0000-0x000000100000 : "env" [ 1.620000] 0x000000100000-0x000000120000 : "env2" [ 1.620000] 0x000000120000-0x000007a60000 : "ubi_device" [ 1.630000] 0x000007a60000-0x000007c60000 : "mtdoops" [ 1.640000] Size of the first partition is 6 blocks. [ 1.640000] Realtek SPINAND Flash Driver is successfully installing. [ 1.650000] tun: Universal TUN/TAP device driver, 1.6 [ 1.650000] tun: (C) 1999-2004 Max Krasnyansky <maxk@qualcomm.com> [ 1.660000] Init RTK Driver Module....rtk_switch_irq_init 355 irq=38 name=apl_sw [ 1.750000] phy recovery init complete! version 1.1 [ 1.760000] OK [ 1.760000] Init RTK Core Dev Module....OK [ 1.770000] [ 1.770000] rtdrv_init !!!! for netfilter [ 1.770000] [rtdrv_init]: rtdrv_ext_igmpHook_sockopts init. [ 1.780000] [rtdrv_init]: rtdrv_ext_igmpHook_sockopts success. [ 1.790000] pkt_redirect_init complete [ 1.790000] interrupt broadcaster init ok! [ 1.800000] re8670_set_features 900: enter [ 1.800000] re8670_set_features 900: enter [ 1.810000] re8670_set_features 900: enter [ 1.810000] re8670_set_features 900: enter [ 1.810000] re8670_set_features 900: enter [ 1.820000] re8670_set_features 900: enter [ 1.820000] re8670_set_features 900: enter [ 1.830000] re8670_set_features 900: enter [ 1.830000] re8670_set_features 900: enter [ 1.840000] re8670_set_features 900: enter [ 1.840000] re8670_set_features 900: enter [ 1.860000] Disable gmac[0] padding [ 1.870000] [ 1.870000] rtk_gmac_netdev_init 9144: netdev name=eth0 exist [ 1.890000] Disable gmac[1] padding [ 1.890000] first entry: 0, portmask 2047, rx: 806ace04 [ 1.900000] [FCEXT] rtk_fc_extmodule_init [ 1.920000] [FCMGR] module init @rtk_fc_mgr_init(505) [ 2.560000] RTK FleetConntrack Driver - core module init [ 2.560000] - build ver. 0.ap_usdk_v1.4.1a.0 Sep 16 2022 15:49:00 [ 2.570000] - mem usage 4363 KB (malloc:936512 fc_db:3531056 pro_db:532) [ 2.580000] priority: 0, portmask 2047, rx: 806ace04 [ 2.580000] insert here, priority: 1, portmask 2047, rx: 806b0b08 [ 2.590000] RTK FleetConntrack Driver - manager module init [ 2.600000] - mem usage 273 KB (db:244768 nicrx_ipi:35584) [ 2.600000] rtk_common_utility_init 520 common utility init! [ 2.610000] smuxdev: loaded [ 2.610000] rtl8221b: rtk_rtl8221b_moudle_init [ 2.620000] rtl8221b: RTL8221B Device 0 (mdio set: 0, phyad: 6) [ 2.620000] RTL8221B: rtl8221b_dev0_reset pin is set to GPIO #60 [ 2.730000] rtl8221b: Enable MDIO master PAD_LED0/PAD_LED1 for 8221B device 0...... [ 2.740000] rtl8221b: Creat 5 proc entry. [ 2.740000] PPP generic driver version 2.4.2 [ 2.750000] NET: Registered protocol family 24 [ 2.750000] PPTP driver version 0.8.5 [ 2.760000] MPPE/MPPC encryption/compression module registered [ 2.770000] usbcore: registered new interface driver asix [ 2.770000] usbcore: registered new interface driver ax88179_178a [ 2.780000] usbcore: registered new interface driver cdc_ether [ 2.780000] usbcore: registered new interface driver net1080 [ 2.790000] usbcore: registered new interface driver rndis_host [ 2.800000] usbcore: registered new interface driver cdc_subset [ 2.800000] usbcore: registered new interface driver zaurus [ 2.810000] usbcore: registered new interface driver cdc_ncm [ 2.820000] usbcore: registered new interface driver qmi_wwan [ 2.820000] usbcore: registered new interface driver cdc_mbim [ 2.830000] mousedev: PS/2 mouse device common for all mice [ 2.840000] ehci_hcd: USB 2.0 'Enhanced' Host Controller (EHCI) Driver [ 2.840000] ehci-pci: EHCI PCI platform driver [ 2.850000] ehci-platform: EHCI generic platform driver [ 2.850000] ehci-platform ehci-platform.0: EHCI Host Controller [ 2.860000] ehci-platform ehci-platform.0: new USB bus registered, assigned bus number 1 [ 2.870000] ehci-platform ehci-platform.0: irq 74, io mem 0x18021000 [ 2.890000] PHY chip: RTL8221B-VB (id= 0xc849), API version: 0x20 [ 2.900000] ehci-platform ehci-platform.0: USB 2.0 started, EHCI 1.00 [ 2.900000] rtl8221b: Init Device 0 Done. [ 2.910000] usb usb1: New USB device found, idVendor=1d6b, idProduct=0002 [ 2.920000] usb usb1: New USB device strings: Mfr=3, Product=2, SerialNumber=1 [ 2.920000] usb usb1: Product: EHCI Host Controller [ 2.930000] usb usb1: Manufacturer: Linux 4.4.140 ehci_hcd [ 2.930000] usb usb1: SerialNumber: ehci-platform.0 [ 2.940000] hub 1-0:1.0: USB hub found [ 2.940000] hub 1-0:1.0: 1 port detected [ 2.950000] ohci_hcd: USB 1.1 'Open' Host Controller (OHCI) Driver [ 2.960000] ohci-pci: OHCI PCI platform driver [ 2.960000] ohci-platform: OHCI generic platform driver [ 2.970000] ohci-platform ohci-platform.0: Generic Platform OHCI controller [ 2.970000] ohci-platform ohci-platform.0: new USB bus registered, assigned bus number 2 [ 2.980000] ohci-platform ohci-platform.0: irq 74, io mem 0x18020000 [ 3.050000] usb usb2: New USB device found, idVendor=1d6b, idProduct=0001 [ 3.060000] usb usb2: New USB device strings: Mfr=3, Product=2, SerialNumber=1 [ 3.060000] usb usb2: Product: Generic Platform OHCI controller [ 3.070000] usb usb2: Manufacturer: Linux 4.4.140 ohci_hcd [ 3.080000] usb usb2: SerialNumber: ohci-platform.0 [ 3.080000] hub 2-0:1.0: USB hub found [ 3.090000] hub 2-0:1.0: 1 port detected [ 3.090000] usbcore: registered new interface driver cdc_acm [ 3.100000] cdc_acm: USB Abstract Control Model driver for USB modems and ISDN adapters [ 3.110000] usbcore: registered new interface driver cdc_wdm [ 3.110000] usbcore: registered new interface driver usb-storage [ 3.120000] usbcore: registered new interface driver usbserial [ 3.130000] usbcore: registered new interface driver usbserial_generic [ 3.130000] usbserial: USB Serial support registered for generic [ 3.140000] usbcore: registered new interface driver cp210x [ 3.150000] usbserial: USB Serial support registered for cp210x [ 3.150000] usbcore: registered new interface driver option [ 3.160000] usbserial: USB Serial support registered for GSM modem (1-port) [ 3.170000] usbcore: registered new interface driver usbhid [ 3.170000] usbhid: USB HID core driver [ 3.180000] Init Eltex board driver [ 3.180000] Init Eltex WAN/CWMP Monitoring Driver [ 3.190000] /proc/enable_dos created [ 3.190000] Mirror/redirect action on [ 3.190000] u32 classifier [ 3.200000] Actions configured [ 3.200000] nf_conntrack version 0.5.0 (3848 buckets, 15392 max) [ 3.210000] nf_conntrack_l2tp version 3.1 loaded [ 3.210000] nf_conntrack_rtsp v0.7 loading [ 3.220000] nf_conntrack_ipsec loaded [ 3.220000] nf_nat_ipsec loaded [ 3.220000] nf_nat_rtsp v0.7 loading [ 3.230000] xt_time: kernel timezone is -0000 [ 3.230000] gre: GRE over IPv4 demultiplexor driver [ 3.240000] ip_tables: (C) 2000-2006 Netfilter Core Team [ 3.240000] wireguard: WireGuard 1.0.20220627 loaded. See www.wireguard.com for information. [ 3.250000] wireguard: Copyright (C) 2015-2019 Jason A. Donenfeld <Jason@zx2c4.com>. All Rights Reserved. [ 3.260000] wireguard: Copyright (C) 2024 AmneziaVPN <admin@amnezia.org>. All Rights Reserved. [ 3.270000] NET: Registered protocol family 10 [ 3.280000] ip6_tables: (C) 2000-2006 Netfilter Core Team [ 3.290000] sit: IPv6 over IPv4 tunneling driver [ 3.290000] NET: Registered protocol family 17 [ 3.300000] bridge: automatic filtering via arp/ip/ip6tables has been deprecated. Update your scripts to load br_netfilter if you need this. [ 3.310000] Bridge firewalling registered [ 3.320000] Ebtables v2.0 registered [ 3.320000] l2tp_core: L2TP core driver, V2.0 [ 3.330000] l2tp_ppp: PPPoL2TP kernel driver, V2.0 [ 3.330000] 8021q: 802.1Q VLAN Support v1.8 [ 3.340000] [board_init - 454] [ 3.340000] board_pb_init [ 3.340000] Register system dying gasp...Done [ 3.350000] ubi0: attaching mtd4 [ 3.880000] ubi0: scanning is finished [ 3.900000] ubi0 warning: print_rsvd_warning: cannot reserve enough PEBs for bad PEB handling, reserved 17, need 20 [ 3.910000] ubi0: attached mtd4 (name "ubi_device", size 121 MiB) [ 3.910000] ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes [ 3.920000] ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048 [ 3.930000] ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096 [ 3.940000] ubi0: good PEBs: 970, bad PEBs: 0, corrupted PEBs: 0 [ 3.940000] ubi0: user volume: 9, internal volumes: 1, max. volumes count: 128 [ 3.950000] ubi0: max/mean erase counter: 4/1, WL threshold: 4096, image sequence number: 95652907 [ 3.960000] ubi0: available PEBs: 0, total reserved PEBs: 970, PEBs reserved for bad PEB handling: 17 [ 3.970000] ubi0: background thread "ubi_bgt0d" started, PID 78 [ 3.980000] gpio-keys gpio-keys: Failed to request GPIO 34, error -16 [ 3.990000] gpio-keys: probe of gpio-keys failed with error -16 [ 4.000000] wlan_event_init_main: Successfully inserted a hook into kernel [ 4.010000] VFS: Mounted root (squashfs filesystem) readonly on device 31:10. [ 4.020000] devtmpfs: mounted [ 4.020000] Freeing unused kernel memory: 244K [ 4.510000] random: init: uninitialized urandom read (4 bytes read, 41 bits of entropy available) init started: BusyBox v1.37.0 (2025-09-30 07:41:35 UTC) Bad inittab entry at line 33 starting pid 90, tty '': '/etc/init.d/rcS' [ 4.710000] random: rcS: uninitialized urandom read (4 bytes read, 46 bits of entropy available) === Start to run rc0 / rc63 === ----- do_rc [/e[ 4.770000] random: sh: uninitialized urandom read (4 bytes read, 47 bits of entropy available) tc/init.d/rc2] ----- [ 4.790000] random: sh: uninitialized urandom read (4 bytes read, 47 bits of entropy available) [ 4.830000] random: mount: uninitialized urandom read (4 bytes read, 47 bits of entropy available) [ 4.860000] random: grep: uninitialized urandom read (4 bytes read, 47 bits of entropy available) [ 4.880000] random: mount: uninitialized urandom read (4 bytes read, 48 bits of entropy available) [ 4.910000] random: mount: uninitialized urandom read (4 bytes read, 48 bits of entropy available) [ 4.940000] random: sh: uninitialized urandom read (4 bytes read, 49 bits of entropy available) [ 4.970000] random: grep: uninitialized urandom read (4 bytes read, 49 bits of entropy available) /etc/scripts/checkroot.sh: line 22: can't open /etc/fstab: no such file [ 5.480000] UBIFS (ubi0:0): background thread "ubifs_bgt0_0" started, PID 115 [ 5.500000] UBIFS (ubi0:0): recovery needed [ 5.600000] UBIFS (ubi0:0): recovery completed [ 5.610000] UBIFS (ubi0:0): UBIFS: mounted UBI device 0, volume 0, name "ubi_Config" [ 5.620000] UBIFS (ubi0:0): LEB size: 126976 bytes (124 KiB), min./max. I/O unit sizes: 2048 bytes/2048 bytes [ 5.630000] UBIFS (ubi0:0): FS size: 9777152 bytes (9 MiB, 77 LEBs), journal size 1015809 bytes (0 MiB, 6 LEBs) [ 5.640000] UBIFS (ubi0:0): reserved for root: 461798 bytes (450 KiB) [ 5.650000] UBIFS (ubi0:0): media format: w4/r0 (latest is w4/r0), UUID 24256AC2-2593-4145-8A1E-7462C36AE499, small LPT model [ 5.710000] UBIFS (ubi0:7): background thread "ubifs_bgt0_7" started, PID 119 [ 5.730000] UBIFS (ubi0:7): recovery needed [ 5.820000] UBIFS (ubi0:7): recovery completed [ 5.830000] UBIFS (ubi0:7): UBIFS: mounted UBI device 0, volume 7, name "ubi_app" [ 5.840000] UBIFS (ubi0:7): LEB size: 126976 bytes (124 KiB), min./max. I/O unit sizes: 2048 bytes/2048 bytes [ 5.850000] UBIFS (ubi0:7): FS size: 9269248 bytes (8 MiB, 73 LEBs), journal size 1015809 bytes (0 MiB, 6 LEBs) [ 5.860000] UBIFS (ubi0:7): reserved for root: 437809 bytes (427 KiB) [ 5.870000] UBIFS (ubi0:7): media format: w4/r0 (latest is w4/r0), UUID 30BC174B-2149-4E80-87FE-89BB1065EE97, small LPT model Name: ubi_syslog Name: ubi_syslog Partition ubi_syslog found, mount it [ 6.000000] UBIFS (ubi0:8): background thread "ubifs_bgt0_8" started, PID 128 [ 6.020000] UBIFS (ubi0:8): recovery needed [ 6.150000] UBIFS (ubi0:8): recovery completed [ 6.150000] UBIFS (ubi0:8): UBIFS: mounted UBI device 0, volume 8, name "ubi_syslog" [ 6.160000] UBIFS (ubi0:8): LEB size: 126976 bytes (124 KiB), min./max. I/O unit sizes: 2048 bytes/2048 bytes [ 6.170000] UBIFS (ubi0:8): FS size: 1142784 bytes (1 MiB, 9 LEBs), journal size 888833 bytes (0 MiB, 5 LEBs) [ 6.180000] UBIFS (ubi0:8): reserved for root: 53976 bytes (52 KiB) [ 6.190000] UBIFS (ubi0:8): media format: w4/r0 (latest is w4/r0), UUID 42C5A17E-BFB1-44A4-9728-7EBF48C8534E, small LPT model ----- do_rc [/etc/init.d/rc3] ----- Loading Realtek IGMP/ MLD Snooping Module... [ 6.510000] rtk_igmp_hook: loading out-of-tree module taints kernel. [ 6.520000] multicast_moudle_init ----- do_rc [/etc/init.d/rc4] ----- ----- do_rc [/etc/init.d/rc6] ----- ----- do_rc [/etc/init.d/rc10] ----- rtl8221b: (Build: Sep 30 2025 - 07:56:19) rtl8221b: phy is not initialized yet ----- do_rc [/etc/init.d/rc14] ----- ----- do_rc [/etc/init.d/rc18] ----- no need to do reset to default cat: can't open '/var/config/config.xml': No such file or directory ----- do_rc [/etc/init.d/rc19] ----- ----- do_rc [/etc/init.d/rc20] ----- <main:5573> Systemd usock fd =3 Start WPS handler set_msgqueue_max_size:231> set msgqidds.msg_qbytes=20600 OK set_msgqueue_max_size:231> set msgqidds.msg_qbytes=20600 OK [ 7.100000] udevd[165]: starting version 3.2 ------ [-b]Bootup_config ------ [ 7.140000] udevd[165]: starting eudev-3.2 Checking input file [/var/config/hidden_hs.xml]. [OK] Valid config file! [ 7.520000] random: nonblocking pool is initialized ***** config_parser(): fname=[/var/config/hidden_hs.xml](0) loaded ***** [xml_INFO]: Load Hidden HS configuration success. Checking input file [/var/config/hidden.xml]. rtl8221b: phy is not initialized yet [OK] Valid config file! ***** config_parser(): fname=[/var/config/hidden.xml](0) loaded ***** [xml_INFO]: Load Hidden configuration success. Checking input file [/var/config/lastgood_hs.xml]. [OK] Valid config file! Checking input file [/var/config/lastgood.xml]. rtl8221b: phy is not initialized yet [OK] Valid config file! Checking input file [/var/config/lastgood_hs.xml]. [OK] Valid config file! ***** config_parser(): fname=[/var/config/lastgood_hs.xml](0) loaded ***** [xml_INFO]: Load HS configuration success. Checking input file [/var/config/lastgood.xml]. [OK] Valid config file! rtl8221b: phy is not initialized yet ***** config_parser(): fname=[/var/config/lastgood.xml](0) loaded ***** [xml_INFO]: Load CS configuration success. ----- do_rc [/etc/init.d/rc21] ----- diable printk= 0 parameter is 1 RTL Chip............ Loading modules: ca-ne ca-plat-kernel ca-sdk-cb libscfg rtl8221b: phy is not initialized yet [ 11.120000] Loading modules backported from Linux version v5.2.8-0-gd36a8d2fb62c [ 11.130000] Backport generated by backports.git v5.2.8-1-0-ga33d4e95 rtl8221b: phy is not initialized yet [ 12.100000] cfg80211: Loading compiled-in X.509 certificates for regulatory database [ 12.110000] cfg80211: Loaded X.509 cert 'sforshee: 00b28ddf47aef9cea7' [ 12.120000] platform regulatory.0: Direct firmware load for regulatory.db failed with error -2 [ 12.130000] cfg80211: failed to load regulatory.db Parsing parameters... rtl8221b: phy is not initialized yet [ 12.990000] tv_sec:12 tv_usec:995928 [ 12.990000] CPU0 kick watchdog! [ 13.730000] RTW: module init start [ 13.730000] RTW: rtk_wifi6 v2.0.0.1 2021/09/22 [ 13.740000] RTW: build time: Sep 30 2025 07:32:23 [ 13.750000] RTW: rtk_wifi6 probing pci device "0000:00:01.0"... [ 13.750000] PCI: Enabling device 0000:00:01.0 (0000 -> 0003) [ 13.760000] devfn:8 vend:10ec dev:b832 cls:28000 pin:1 [ 13.770000] PHL: [MAC] MAC_AX_MAJOR_VER = 0 [ 13.770000] MAC_AX_PROTOTYPE_VER = 27 [ 13.770000] MAC_AX_SUB_VER = 48 [ 13.770000] MAC_AX_SUB_INDEX = 0 rtl8221b: phy is[ 13.790000] dbg [rtw_hal_mac_init][1087]chip_cut = 0 initialized, start daemon rtl8[ 13.800000] PHL: ERROR phl_mr_ctrl_init mcc init fail 221b: Disable GPIO #6 for MDIO [ 13.810000] RTW: CONFIG_WLAN0_RFE_TYPE_50 [ 13.810000] RTW: CONFIG_WLAN0_RFE_TYPE_50 [ 13.820000] RTW: rtw_load_phy_file_path(0) Parameter path: "/etc/conf/rtl8832br/RFE50/" [ 13.820000] RTW: 0000:00:01.0: initialize #5 handler "core RX" W@1/4 [ 13.830000] RTW: 0000:00:01.0: initialize #6 handler "NO NAME" T@4/4 [ 13.840000] RTW: 0000:00:01.0: initialize #7 handler "NO NAME" T@4/4 rtl8221b: Config[ 13.850000] RTW: 0000:00:01.0: initialize #3 handler "PHL TX" W@3/4 IO MUX (Enable [ 13.850000] RTW: 0000:00:01.0: initialize #4 handler "PHL RX" T@4/4 MDIO_MASTER_EN) for MDIO rtl822[ 13.860000] [phl_trx_init_pcie:2872] init lock rx_buf_info_lock 1b: IO_MODE(befo[ 13.870000] RTW: [RXBUF][dev_id:0][ch:0] rxbd_num:512 buf_len:4096 re) = 0x00020458[ 13.880000] RTW: [RXBUF][dev_id:0][ch:1] rxbd_num:64 buf_len:512 rtl8221b: IO_M[ 13.890000] RTW: [RXBUF][dev_id:0][ch:0] rx_buf: num=768 size=8032 ODE(after) = 0x00020458 [ 13.900000] PHL: CH[0] Alloc 8032B RX buffer, got available size 8096B [ 13.910000] RTW: [RXBUF][dev_id:0][ch:1] rx_buf: num=128 size=352 [ 13.910000] PHL: CH[1] Alloc 352B RX buffer, got available size 416B [ 13.920000] RTW: [RXBUF][_phl_update_default_rx_bd][ch:0] rxbd_num:512 [ 13.930000] RTW: [RXBUF][_phl_update_default_rx_bd][ch:1] rxbd_num:64 [ 13.940000] RTW: [HW-CAP] ic_name:rtl8832br [ 13.940000] RTW: [HW-CAP] macid_num:128 [ 13.940000] RTW: [HW-CAP] sec_cap:0x01 [ 13.950000] RTW: [HW-CAP] sec_cam_ent_num:0 [ 13.950000] RTW: [HW-CAP] rfpath_num_2g:2 [ 13.960000] RTW: [HW-CAP] rfpath_num_5g:2 [ 13.960000] RTW: [HW-CAP] rf_reg_path_num:2 [ 13.970000] RTW: [HW-CAP] max_tx_cnt:2 [ 13.970000] RTW: [HW-CAP] tx_nss_num:2 [ 13.970000] RTW: [HW-CAP] rx_nss_num:2 [ 13.980000] RTW: [HW-CAP] band_cap:5G [ 13.980000] RTW: [HW-CAP] bw_cap:20M 40M 80M [ 13.990000] RTW: [HW-CAP] proto_cap:b g n ac [ 13.990000] RTW: [HW-CAP] wl_func:P2P MIRACAST TDLS [ 14.000000] RTW: 0000:00:01.0: initialize #1 handler "netif RX" T@3/4 [ 14.010000] RTW: init_mlme_ext_timer [ 14.050000] swq tasklet init padapter=c1cb4000 dvobj=8df30000 [ 14.050000] padapter=c1cb4000 dvobj=8df30000 [ 14.060000] RTW: ERROR rtw_hw_get_mac_addr failed [ 14.060000] RTW: ERROR invalid mac addr:00:00:00:00:00:00, assign random MAC [ 14.070000] RTW: [1]padapter=0xc1cb4000 dev_id=0 [ 14.080000] RTW: Creating #5 virtual interface(s). [ 14.080000] padapter=c20e5000 dvobj=8df30000 [ 14.090000] padapter=c211f000 dvobj=8df30000 [ 14.090000] padapter=c2159000 dvobj=8df30000 [ 14.100000] padapter=c2193000 dvobj=8df30000 [ 14.110000] padapter=c21cd000 dvobj=8df30000 [ 14.110000] RTW: rtw_cfg80211_init_ht_capab: band_type=0x2 dev_id=0x0 ht_cap->cap=1862 [ 14.120000] dbg [rtw_build_he_phy_caps][789]force enable RX ldpc [ 14.130000] dbg [rtw_build_he_phy_caps][801]no RX stbc [ 14.130000] RTW: [rtw_build_he_supp_mcs] bw_cap:0 [ 14.140000] dbg [rtw_build_he_phy_caps][789]force enable RX ldpc [ 14.140000] dbg [rtw_build_he_phy_caps][801]no RX stbc [ 14.150000] RTW: [rtw_build_he_supp_mcs] bw_cap:0 [ 14.160000] dbg [rtw_cfg80211_init_wiphy][10848]enable A4 [ 14.160000] RTW: rtw_ndev_init(wlan0) if1 mac_addr=00:00:00:00:00:00 [ 14.180000] RTW: rtk_wifi6 probing pci device "0000:02:01.0"... <read_event:3422>[ 14.190000] PCI: Enabling device 0000:02:01.0 (0000 -> 0003) [RTM_NEWLINK] w[ 14.190000] devfn:8 vend:10ec dev:192 cls:28000 pin:1 lan0 down not running [ 14.210000] PHL: [MAC] MAC_AX_MAJOR_VER = 0 [ 14.210000] MAC_AX_PROTOTYPE_VER = 27 [ 14.210000] MAC_AX_SUB_VER = 48 [ 14.210000] MAC_AX_SUB_INDEX = 0 [ 14.230000] dbg [rtw_hal_mac_init][1087]chip_cut = 0 [ 14.230000] PHL: ERROR phl_mr_ctrl_init mcc init fail [ 14.240000] RTW: CONFIG_WLAN1_RFE_TYPE_50 [ 14.250000] RTW: CONFIG_WLAN1_RFE_TYPE_50 [ 14.250000] RTW: rtw_load_phy_file_path(0) Parameter path: "/etc/conf/rtl8192xb/RFE50/" [ 14.260000] RTW: 0000:02:01.0: initialize #5 handler "core RX" W@0/4 [ 14.270000] RTW: 0000:02:01.0: initialize #6 handler "NO NAME" T@4/4 [ 14.280000] RTW: 0000:02:01.0: initialize #7 handler "NO NAME" T@4/4 [ 14.280000] RTW: 0000:02:01.0: initialize #3 handler "PHL TX" W@2/4 [ 14.290000] RTW: 0000:02:01.0: initialize #4 handler "PHL RX" T@4/4 [ 14.300000] [phl_trx_init_pcie:2872] init lock rx_buf_info_lock [ 14.310000] RTW: [RXBUF][dev_id:1][ch:0] rxbd_num:192 buf_len:1536 [ 14.310000] RTW: [RXBUF][dev_id:1][ch:1] rxbd_num:64 buf_len:512 [ 14.320000] RTW: [RXBUF][dev_id:1][ch:0] rx_buf: num=576 size=3936 [ 14.330000] PHL: CH[0] Alloc 3936B RX buffer, got available size 4000B [ 14.330000] RTW: [RXBUF][dev_id:1][ch:1] rx_buf: num=128 size=352 [ 14.340000] PHL: CH[1] Alloc 352B RX buffer, got available size 416B [ 14.350000] RTW: [RXBUF][_phl_update_default_rx_bd][ch:0] rxbd_num:192 [ 14.360000] RTW: [RXBUF][_phl_update_default_rx_bd][ch:1] rxbd_num:64 [ 14.360000] RTW: [HW-CAP] ic_name:rtl8192xb [ 14.370000] RTW: [HW-CAP] macid_num:128 [ 14.370000] RTW: [HW-CAP] sec_cap:0x01 [ 14.380000] RTW: [HW-CAP] sec_cam_ent_num:0 [ 14.380000] RTW: [HW-CAP] rfpath_num_2g:2 [ 14.390000] RTW: [HW-CAP] rfpath_num_5g:2 [ 14.390000] RTW: [HW-CAP] rf_reg_path_num:2 [ 14.390000] RTW: [HW-CAP] max_tx_cnt:2 [ 14.400000] RTW: [HW-CAP] tx_nss_num:2 [ 14.400000] RTW: [HW-CAP] rx_nss_num:2 [ 14.410000] RTW: [HW-CAP] band_cap:2G [ 14.410000] RTW: [HW-CAP] bw_cap:20M 40M [ 14.420000] RTW: [HW-CAP] proto_cap:b g n ac [ 14.420000] RTW: [HW-CAP] wl_func:P2P MIRACAST TDLS [ 14.430000] RTW: 0000:02:01.0: initialize #1 handler "netif RX" T@3/4 [ 14.430000] RTW: init_mlme_ext_timer [ 14.470000] swq tasklet init padapter=c25fc000 dvobj=8b070000 [ 14.480000] padapter=c25fc000 dvobj=8b070000 [ 14.480000] RTW: ERROR rtw_hw_get_mac_addr failed [ 14.490000] RTW: ERROR invalid mac addr:00:00:00:00:00:00, assign random MAC [ 14.500000] RTW: [2]padapter=0xc25fc000 dev_id=1 [ 14.500000] RTW: Creating #5 virtual interface(s). [ 14.510000] padapter=c2a1b000 dvobj=8b070000 [ 14.510000] padapter=c2a55000 dvobj=8b070000 [ 14.520000] padapter=c2a8f000 dvobj=8b070000 [ 14.530000] padapter=c2ac9000 dvobj=8b070000 [ 14.530000] padapter=c2b03000 dvobj=8b070000 [ 14.540000] RTW: rtw_cfg80211_init_ht_capab: band_type=0x1 dev_id=0x1 ht_cap->cap=1062 [ 14.550000] dbg [rtw_build_he_phy_caps][789]force enable RX ldpc [ 14.550000] dbg [rtw_build_he_phy_caps][801]no RX stbc [ 14.560000] RTW: [rtw_build_he_supp_mcs] bw_cap:0 [ 14.560000] dbg [rtw_build_he_phy_caps][789]force enable RX ldpc [ 14.570000] dbg [rtw_build_he_phy_caps][801]no RX stbc [ 14.580000] RTW: [rtw_build_he_supp_mcs] bw_cap:0 [ 14.580000] dbg [rtw_cfg80211_init_wiphy][10848]enable A4 [ 14.590000] RTW: rtw_ndev_init(wlan1) if1 mac_addr=00:00:00:00:00:00 <read_event:3422>[ 14.600000] RTW: module init ret=0 [RTM_NEWLINK] wlan1 down not running Getting Realtek Wifi6 driver's configuration... Realtek Wifi6 driver supports 5 virtual interfaces... Primary interface(s) of RTK wifi6 driver: wlan0 wlan1 Creating [ 15.050000] RTW: Finding existing adapter of name "wlan0-vap0"... 5 virtual interf[ 15.050000] RTW: Creating new interface "wlan0-vap0"... ace(s) for wlan0[ 15.060000] RTW: rtw_ndev_init(wlan0-vap0) if2 mac_addr=02:00:00:00:00:00 ... Client interface is wlan0-vxd Creating VIFs wlan0-vap0 wlan0-vap1 wlan0-vap2 wlan0-vap3 wlan0-vxd ... <read_event:3422> [RTM_NEWLINK] wlan0-vap0 down not running Interface wlan0-vap0 is created. [ 15.090000] RTW: Finding existing adapter of name "wlan0-vap1"... [ 15.100000] RTW: Creating new interface "wlan0-vap1"... [ 15.110000] RTW: rtw_ndev_init(wlan0-vap1) if3 mac_addr=0a:00:00:00:00:00 <read_event:3422> [RTM_NEWLINK] wlan0-vap1 down not running Interface wlan0-vap1 is created. [ 15.150000] RTW: Finding existing adapter of name "wlan0-vap2"... [ 15.160000] RTW: Creating new interface "wlan0-vap2"... [ 15.160000] RTW: rtw_ndev_init(wlan0-vap2) if4 mac_addr=0e:00:00:00:00:00 <read_event:3422> [RTM_NEWLINK] wlan0-vap2 down not running Interface wlan0-vap2 is created. [ 15.200000] RTW: Finding existing adapter of name "wlan0-vap3"... [ 15.200000] RTW: Creating new interface "wlan0-vap3"... [ 15.210000] RTW: rtw_ndev_init(wlan0-vap3) if5 mac_addr=12:00:00:00:00:00 <read_event:3422> [RTM_NEWLINK] wlan0-vap3 down not running Interface wlan0-vap3 is created. [ 15.270000] RTW: Finding existing adapter of name "wlan0-vxd"... [ 15.280000] RTW: Creating new interface "wlan0-vxd"... [ 15.290000] RTW: rtw_ndev_init(wlan0-vxd) if6 mac_addr=16:00:00:00:00:00 <read_event:3422> [RTM_NEWLINK] wlan0-vxd down not running Interface wlan0-vxd is created. Creating 5 virtual interface(s) for wlan1 ... Client interface is wlan1-vxd [ 15.320000] RTW: Finding existing adapter of name "wlan1-vap0"... Creating VIFs wl[ 15.330000] RTW: Creating new interface "wlan1-vap0"... an1-vap0 wlan1-v[ 15.330000] RTW: rtw_ndev_init(wlan1-vap0) if2 mac_addr=02:00:00:00:00:00 ap1 wlan1-vap2 wlan1-vap3 wlan1-vxd ... <read_event:3422> [RTM_NEWLINK] wlan1-vap0 down not running Interface wlan1-vap0 is created. [ 15.460000] RTW: Finding existing adapter of name "wlan1-vap1"... [ 15.470000] RTW: Creating new interface "wlan1-vap1"... [ 15.470000] RTW: rtw_ndev_init(wlan1-vap1) if3 mac_addr=0a:00:00:00:00:00 <read_event:3422> [RTM_NEWLINK] wlan1-vap1 down not running Interface wlan1-vap1 is created. [ 15.570000] RTW: Finding existing adapter of name "wlan1-vap2"... [ 15.580000] RTW: Creating new interface "wlan1-vap2"... [ 15.590000] RTW: rtw_ndev_init(wlan1-vap2) if4 mac_addr=0e:00:00:00:00:00 <read_event:3422> [RTM_NEWLINK] wlan1-vap2 down not running Interface wlan1-vap2 is created. [ 15.620000] RTW: Finding existing adapter of name "wlan1-vap3"... [ 15.630000] RTW: Creating new interface "wlan1-vap3"... [ 15.630000] RTW: rtw_ndev_init(wlan1-vap3) if5 mac_addr=12:00:00:00:00:00 <read_event:3422> [RTM_NEWLINK] wlan1-vap3 down not running Interface wlan1-vap3 is created. [ 15.690000] RTW: Finding existing adapter of name "wlan1-vxd"... [ 15.700000] RTW: Creating new interface "wlan1-vxd"... [ 15.700000] RTW: rtw_ndev_init(wlan1-vxd) if6 mac_addr=16:00:00:00:00:00 <read_event:3422> [RTM_NEWLINK] wlan1-vxd down not running Interface wlan1-vxd is created. ----- do_rc [/etc/init.d/rc22] ----- ----- do_rc [/etc/init.d/rc30] ----- [ 15.920000] Reset value to -1 ----- do_rc [/etc/init.d/rc32] ----- [ 16.040000] Reset value to -1 [ 16.050000] lan_sds_mode_set fail 0 ret 13 sh: write error: Bad address /etc/runlansds.sh: line 5: can't create proc/lan_sds/sfp_app: nonexistent directory ----- do_rc [/etc/init.d/rc34] ----- /etc/runlansds.sh: line 6: sfpapp: not found [ 16.070000] write watchdog_flag to 0x00000001 [ 16.070000] REG32(BSP_WDTCTRLR) = 0xe7c00000 ----- do_rc [/etc/init.d/rc35] ----- [ 16.170000] Reset value to -1 set bank1_bootcount 0 Turn on phy power... [ 16.300000] Reset value to -1 diable printk= 0 parameter is 0 /bin/sh: can't open '/etc/scripts/board_init.sh': No such file or directory [ 16.430000] Reset value to -1 starting pid 437, tty '': '/usr/bin/lighttpd -f /etc/lighttpd/lighttpd.conf -D > /dev/null 2>&1' starting pid 438, tty '': 'lua /usr/local/share/lua/5.1/server/service_daemon/sessions_server.lua' [ 16.570000] Reset value to -1 [ 16.690000] Reset value to -1 [ 16.830000] Reset value to -1 /bin/sh: can't create /proc/fc/ctrl/dot1p_base_bit_of_mark: nonexistent directory /bin/sh: can't create /proc/fc/ctrl/dot1p_enable_bit_of_mark: nonexistent directory /bin/sh: can't create /proc/fc/ctrl/dot1p_enable_bit_of_mark: nonexistent directory /bin/sh: can't create /proc/fc/ctrl/dot1p_base_bit_of_mark: nonexistent directory MIB chain descriptors checking (total 60) ok ! >>> Disable /dev/console XON XOFF !!! CMD: /bin/ifconfig eth0.2 hw ether ecb1e038f4b8 <read_event:3422> [RTM_NEWLINK] eth0.2 down not running CMD: /bin/ifconfig eth0.3 hw ether ecb1e038f4b8 <read_event:3422> [RTM_NEWLINK] eth0.3 down not running CMD: /bin/ifconfig eth0.4 hw ether ecb1e038f4b8 <read_event:3422> [RTM_NEWLINK] eth0.4 down not running CMD: /bin/ifconfig eth0.5 hw ether ecb1e038f4b8 <read_event:3422> [RTM_NEWLINK] eth0.5 down not running CMD: /bin/ifconfig wlan0-vap0 hw ether eeb1e038f4b8 <read_event:3422> [RTM_NEWLINK] wlan0-vap0 down not running <utility.c 701 setup_mac_addr> macAddr[5]+8 = c0 CMD: /bin/ifconfig wlan0 hw ether ecb1e038f4c0 <read_event:3422> [RTM_NEWLINK] wlan0 down not running <utility.c 701 setup_mac_addr> macAddr[5]+1 = b9 CMD: /bin/ifconfig wlan0-vap1 hw ether eeb1e038f4b9 <read_event:3422> [RTM_NEWLINK] wlan0-vap1 down not running <utility.c 701 setup_mac_addr> macAddr[5]+1 = ba CMD: /bin/ifconfig wlan0-vap2 hw ether eeb1e038f4ba <read_event:3422> [RTM_NEWLINK] wlan0-vap2 down not running <utility.c 701 setup_mac_addr> macAddr[5]+1 = bb CMD: /bin/ifconfig wlan0-vap3 hw ether eeb1e038f4bb <read_event:3422> [RTM_NEWLINK] wlan0-vap3 down not running <utility.c 701 setup_mac_addr> macAddr[5]+1 = bc CMD: /bin/ifconfig wlan1-vap0 hw ether eeb1e038f4bc <read_event:3422> [RTM_NEWLINK] wlan1-vap0 down not running <utility.c 701 setup_mac_addr> macAddr[5]+1 = c1 CMD: /bin/ifconfig wlan1 hw ether ecb1e038f4c1 <read_event:3422> [RTM_NEWLINK] wlan1 down not running <utility.c 701 setup_mac_addr> macAddr[5]+1 = bd CMD: /bin/ifconfig wlan1-vap1 hw ether eeb1e038f4bd <read_event:3422> [RTM_NEWLINK] wlan1-vap1 down not running <utility.c 701 setup_mac_addr> macAddr[5]+1 = be CMD: /bin/ifconfig wlan1-vap2 hw ether eeb1e038f4be <read_event:3422> [RTM_NEWLINK] wlan1-vap2 down not running <utility.c 701 setup_mac_addr> macAddr[5]+1 = bf CMD: /bin/ifconfig wlan1-vap3 hw ether eeb1e038f4bf <read_event:3422> [RTM_NEWLINK] wlan1-vap3 down not running CMD: /bin/brctl addbr br0 <read_event:3422> [RTM_NEWLINK] br0 down not running CMD: /bin/ifconfig br0 hw ether ecb1e038f4b8 <read_event:3422> [RTM_NEWLINK] br0 down not running CMD: /bin/ifconfig eth0 hw ether ecb1e038f4b8 <read_event:3422> [RTM_NEWLINK] eth0 down not running CMD: /bin/brctl stp br0 off CMD: /bin/brctl setfd [ 18.380000] device eth0.2 entered promiscuous mode br0 1 CMD: /bin/brctl setageing br0 7200 CMD: /bin/brctl addif br0 eth0.2 <read_event:3422> [RTM_NEWLINK] eth0.2 down not running system(): /bin/echo 3 eth0.2 > /proc/rtl8686gmac/dev_port_mapping <read_event:3422> [RTM_NEWLINK] eth0.2 down not running <read_event:3422> [RTM_NEWLINK] eth0.2 down not running <read_event:3422> [RTM_NEWLI[ 18.420000] port 3 NK] br0 down notassign to eth0.2 running CMD: /bin/smuxctl --if-create-name eth0.2 eth0.2 --set-if-rsmux smuxctl failed(ret=-1) return errno(17) File exists CMD: /b[ 18.480000] device eth0.3 entered promiscuous mode in/smuxctl --if eth0.2 --rx --tags 0 --set-rxif eth0.2 --rule-alias eth0.2-rx-default --rule-append smuxctl failed(ret=-1) return errno(19) No such device CMD: /bin/brctl addif br0 eth0.3 <read_event:3422> [RTM_NEWLINK] eth0.3 down not running system(): /bin/echo 2 eth0.3 > /proc/rtl8686gmac/dev_port_mapping <read_event:3422> [RTM_NEWLINK][ 18.510000] port 2 eth0.3 down notassign to eth0.3 running <read_event:3422> [RTM_NEWLINK] eth0.3 down not running <read_event:3422> [RTM_NEWLINK] br0 down not running CMD: /bin/smuxctl --if-create-name eth0.3 eth0.3 --set-if-rsmux smuxctl fai[ 18.560000] device eth0.4 entered promiscuous mode led(ret=-1) return errno(17) File exists CMD: /bin/smuxctl --if eth0.3 --rx --tags 0 --set-rxif eth0.3 --rule-alias eth0.3-rx-default --rule-append smuxctl failed(ret=-1) return errno(19) No such device CMD: /bin/brctl addif br0 eth0.4 <read_event:3422> [RTM_NEWLINK] eth0.4 down not running <read_event:3422> [RTM_NEWLINK] eth0.4 down not running system(): /bin/echo 1 eth0.4 > /proc/rtl8686gmac/dev_port_mapping <read_event:3422> [RTM_NEWLINK] eth0.4 down not running <read_event:3422> [RTM_N[ 18.610000] port 1 EWLINK] br0 downassign to eth0.4 not running CMD: /bin/smuxctl --if-create-name eth0.4 eth0.4 --set-if-rsmux smuxctl fai[ 18.650000] device eth0.5 entered promiscuous mode led(ret=-1) return errno(17) File exists CMD: /bin/smuxctl --if eth0.4 --rx --tags 0 --set-rxif eth0.4 --rule-alias eth0.4-rx-default --rule-append smuxctl failed(ret=-1) return errno(19) No such device CMD: /bin/brctl addif br0 eth0.5 <read_event:3422> [RTM_NEWLINK] eth0.5 down not running system(): /bin/echo 0 eth0.5 > /proc/rtl8686gmac/dev_port_mapping <read_event:3422> [RTM_NEWLINK] eth0.5 down not running <read_event:3422> [RTM_NEWLINK] eth0.5 down not running <read_event:3422> [RTM_N[ 18.700000] port 0 EWLINK] br0 downassign to eth0.5 not running CMD: /bin/smuxctl --if-create-name eth0.5 eth0.5 --set-if-rsmux smuxctl failed(ret=-1) return errno(17) File exists CMD: /bin/smuxctl --if eth0.5 --rx --tags 0 --set-rxif eth0.5 --rule-alias eth0.5-rx-default --rule-append smuxctl failed(ret=-1) return errno(19) No such device system(): /bin/echo 4 eth0.6 > /proc/rtl8686gmac/dev_port_mapping [ 18.770000] port 4 assign to eth0.6 system(): /bin/echo 5 eth0.6 > /proc/rtl8686gmac/dev_port_mapping [ 18.800000] port 5 assign to eth0.6 CMD: /bin/ifconfig br0 192.168.1.1 netmask 255.255.255.0 mtu 1500 <read_event:3631> [RTM_NEWADDR] ifname=br0, address=192.168.1.1 ifa_local=192.168.1.1 [ 18.910000] IPv6: ADDRCONF(NETDEV_UP): br0: link is not ready iptables: Bad rule (does a matching rule exist in that chain?). CMD: /bin/ifconfig br0 add fe80::1/64 CMD: /bin/ifconfig eth0.2 mtu 1500 CMD: /bin/ifconfig eth0.3 mtu 1500 CMD: /bin/ifconfig eth0.4 mtu 1500 CMD: /bin/ifconfig eth0.5 mtu 1500 CMD: /bin/ifconfig wlan0 mtu 1500 CMD: /bin/ifconfig wlan0-vap0 mtu 1500 CMD: /bin/ifconfig wlan0-vap1 mtu 1500 CMD: /bin/ifconfig wlan0-vap2 mtu 1500 CMD: /bin/ifconfig wlan0-vap3 mtu 1500 CMD: /bin/ifconfig wlan1 mtu 1500 CMD: /bin/ifconfig wlan1-vap0 mtu 1500 CMD: /bin/ifconfig wlan1-vap1 mtu 1500 CMD: /bin/ifconfig wlan1-vap2 mtu 1500 CMD: /bin/ifconfig wlan1-vap3 mtu 1500 CMD: /bin/ifconfig eth0 mtu 1500 CMD: /bin/ifconfig nas0 mtu 1500 CMD: /bin/ifconfig br0 mtu 1500 CMD: /bin/llmnrd -H eltex -s -d -i br0 CMD: /bin/syslogd CMD: /bin/klogd -n CMD: killall telnetd exec killall failed CMD: killall ftpd exec killall failed CMD: /bin/inetd CMD: /bin/ifconfig eth0 up [ 19.680000] re8670_open 4978 [ 19.690000] re8670_open 4978 timelycheck> timelycheck was started [ 19.710000] re8670_open 4978 CMD: /bin/ifconfig eth0.2 up CMD: /bin/ifconfig eth0.3 up CMD: /bin/ifconfig eth0.4 up CMD: /bin/ifconfig eth0.5 up CMD: /bin/ifconfig nas0 down CMD: /bin/ifconfig nas0 hw ether ecb1e038f4b8 CMD: /bin/brctl addif br0 nas0 [ 19.850000] device nas0 entered promiscuous mode CMD: /bin/ifconfig nas0 up [ 19.870000] br0: port 5(nas0) entered forwarding state [ 19.880000] br0: port 5(nas0) entered forwarding state [ 19.880000] IPv6: ADDRCONF(NETDEV_CHANGE): br0: link becomes ready (wlan0)[hs]wlan0_5g:1, [cs]select 5g on wlan0, read hwmib from HW_WLAN0 CMD: /bin/iwpriv wlan0 flash_set xcap=108 wlan0 flash_set:xcap=108 CMD: /bin/iwpriv wlan0 flash_set rfe=255 wlan0 flash_set:rfe=255 CMD: /bin/iwpriv wlan0 flash_set thermalA=33 wlan0 flash_set:thermalA=33 CMD: /bin/iwpriv wlan0 flash_set [ 19.980000] RTW: rtw_load_phy_file_path(0) Parameter path: "/etc/conf/rtl8832br/RFE50/" thermalB=33 wlan0 flash_set:thermalB=33 CMD: /bin/iwpriv wlan0 flash_set thermalC=255 wlan0 flash_set:thermalC=255 CMD: /bin/iwpriv wlan0 flash_set thermalD=255 wlan0 flash_set:thermalD=255 CMD: /bin/iwpriv wlan0 flash_set para_path=/etc/conf/ wlan0 flash_set:para_path=/etc/conf/ CMD: /bin/iwpriv wlan0 flash_set 2G_cck_tssi_A=ececececeaea wlan0 flash_set:2G_cck_tssi_A=ececececeaea CMD: /bin/iwpriv wlan0 flash_set 2G_cck_tssi_B=e8e8e7e7e6e6 wlan0 flash_set:2G_cck_tssi_B=e8e8e7e7e6e6 CMD: /bin/iwpriv wlan0 flash_set 2G_cck_tssi_C=000000000000 wlan0 flash_set:2G_cck_tssi_C=000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_cck_tssi_D=000000000000 wlan0 flash_set:2G_cck_tssi_D=000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_bw40_1s_tssi_A=f3f3f2f2f1 wlan0 flash_set:2G_bw40_1s_tssi_A=f3f3f2f2f1 CMD: /bin/iwpriv wlan0 flash_set 2G_bw40_1s_tssi_B=eaeaeaebe9 wlan0 flash_set:2G_bw40_1s_tssi_B=eaeaeaebe9 CMD: /bin/iwpriv wlan0 flash_set 2G_bw40_1s_tssi_C=0000000000 wlan0 flash_set:2G_bw40_1s_tssi_C=0000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_bw40_1s_tssi_D=0000000000 wlan0 flash_set:2G_bw40_1s_tssi_D=0000000000 CMD: /bin/iwpriv wlan0 flash_set 5G_bw40_1s_tssi_A=fdfcf9f800fffcfd0000fffdfcfc wlan0 flash_set:5G_bw40_1s_tssi_A=fdfcf9f800fffcfd0000fffdfcfc CMD: /bin/iwpriv wlan0 flash_set 5G_bw40_1s_tssi_B=faf8f7f5fbf9f8fafafafdfcfaf7 wlan0 flash_set:5G_bw40_1s_tssi_B=faf8f7f5fbf9f8fafafafdfcfaf7 CMD: /bin/iwpriv wlan0 flash_set 5G_bw40_1s_tssi_C=0000000000000000000000000000 wlan0 flash_set:5G_bw40_1s_tssi_C=0000000000000000000000000000 CMD: /bin/iwpriv wlan0 flash_set 5G_bw40_1s_tssi_D=0000000000000000000000000000 wlan0 flash_set:5G_bw40_1s_tssi_D=0000000000000000000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_CCK_GAIN_DIFF_A=000000000000 wlan0 flash_set:2G_CCK_GAIN_DIFF_A=000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_CCK_GAIN_DIFF_B=000000000000 wlan0 flash_set:2G_CCK_GAIN_DIFF_B=000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_CCK_GAIN_DIFF_C=000000000000 wlan0 flash_set:2G_CCK_GAIN_DIFF_C=000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_CCK_GAIN_DIFF_D=000000000000 wlan0 flash_set:2G_CCK_GAIN_DIFF_D=000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_GAIN_DIFF_A=0000000000 wlan0 flash_set:2G_GAIN_DIFF_A=0000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_GAIN_DIFF_B=0000000000 wlan0 flash_set:2G_GAIN_DIFF_B=0000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_GAIN_DIFF_C=0000000000 wlan0 flash_set:2G_GAIN_DIFF_C=0000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_GAIN_DIFF_D=0000000000 wlan0 flash_set:2G_GAIN_DIFF_D=0000000000 CMD: /bin/iwpriv wlan0 flash_set 5G_GAIN_DIFF_A=0000000000000000000000000000 wlan0 flash_set:5G_GAIN_DIFF_A=0000000000000000000000000000 CMD: /bin/iwpriv wlan0 flash_set 5G_GAIN_DIFF_B=0000000000000000000000000000 wlan0 flash_set:5G_GAIN_DIFF_B=0000000000000000000000000000 CMD: /bin/iwpriv wlan0 flash_set 5G_GAIN_DIFF_C=0000000000000000000000000000 wlan0 flash_set:5G_GAIN_DIFF_C=0000000000000000000000000000 CMD: /bin/iwpriv wlan0 flash_set 5G_GAIN_DIFF_D=0000000000000000000000000000 wlan0 flash_set:5G_GAIN_DIFF_D=0000000000000000000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_CCK_CW_DIFF_A=000000000000 wlan0 flash_set:2G_CCK_CW_DIFF_A=000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_CCK_CW_DIFF_B=000000000000 wlan0 flash_set:2G_CCK_CW_DIFF_B=000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_CCK_CW_DIFF_C=000000000000 wlan0 flash_set:2G_CCK_CW_DIFF_C=000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_CCK_CW_DIFF_D=000000000000 wlan0 flash_set:2G_CCK_CW_DIFF_D=000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_CW_DIFF_A=0000000000 wlan0 flash_set:2G_CW_DIFF_A=0000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_CW_DIFF_B=0000000000 wlan0 flash_set:2G_CW_DIFF_B=0000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_CW_DIFF_C=0000000000 wlan0 flash_set:2G_CW_DIFF_C=0000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_CW_DIFF_D=0000000000 wlan0 flash_set:2G_CW_DIFF_D=0000000000 CMD: /bin/iwpriv wlan0 flash_set 5G_CW_DIFF_A=0000000000000000000000000000 wlan0 flash_set:5G_CW_DIFF_A=0000000000000000000000000000 CMD: /bin/iwpriv wlan0 flash_set 5G_CW_DIFF_B=0000000000000000000000000000 wlan0 flash_set:5G_CW_DIFF_B=0000000000000000000000000000 CMD: /bin/iwpriv wlan0 flash_set 5G_CW_DIFF_C=0000000000000000000000000000 wlan0 flash_set:5G_CW_DIFF_C=0000000000000000000000000000 CMD: /bin/iwpriv wlan0 flash_set 5G_CW_DIFF_D=0000000000000000000000000000 wlan0 flash_set:5G_CW_DIFF_D=0000000000000000000000000000 CMD: /bin/iwpriv wlan0 flash_set 2G_rx_gain_cck=0 wlan0 flash_set:2G_rx_gain_cck=0 CMD: /bin/iwpriv wlan0 flash_set 2G_rx_gain_ofdm=0 wlan0 flash_set:2G_rx_gain_ofdm=0 CMD: /bin/iwpriv wlan0 flash_set 5G_rx_gain_low=0 wlan0 flash_set:5G_rx_gain_low=0 CMD: /bin/iwpriv wlan0 flash_set 5G_rx_gain_mid=0 wlan0 flash_set:5G_rx_gain_mid=0 CMD: /bin/iwpriv wlan0 flash_set 5G_rx_gain_high=0 wlan0 flash_set:5G_rx_gain_high=0 CMD: /bin/iwpriv wlan0 flash_set chan_plan=127 wlan0 flash_set:chan_plan=127 (wlan1)[hs]wlan0_5g:1, [cs]select 5g on wlan0, rea[ 20.460000] RTW: rtw_load_phy_file_path(1) Parameter path: "/etc/conf/rtl8192xb/RFE50/" d hwmib from HW_WLAN1 CMD: /bin/iwpriv wlan1 flash_set xcap=24 wlan1 flash_set:xcap=24 CMD: /bin/iwpriv wlan1 flash_set rfe=255 wlan1 flash_set:rfe=255 CMD: /bin/iwpriv wlan1 flash_set thermalA=29 wlan1 flash_set:thermalA=29 CMD: /bin/iwpriv wlan1 flash_set thermalB=29 wlan1 flash_set:thermalB=29 CMD: /bin/iwpriv wlan1 flash_set thermalC=255 wlan1 flash_set:thermalC=255 CMD: /bin/iwpriv wlan1 flash_set thermalD=255 wlan1 flash_set:thermalD=255 CMD: /bin/iwpriv wlan1 flash_set para_path=/etc/conf/ wlan1 flash_set:para_path=/etc/conf/ CMD: /bin/iwpriv wlan1 flash_set 2G_cck_tssi_A=ececececeaea wlan1 flash_set:2G_cck_tssi_A=ececececeaea CMD: /bin/iwpriv wlan1 flash_set 2G_cck_tssi_B=e8e8e7e7e6e6 wlan1 flash_set:2G_cck_tssi_B=e8e8e7e7e6e6 CMD: /bin/iwpriv wlan1 flash_set 2G_cck_tssi_C=000000000000 wlan1 flash_set:2G_cck_tssi_C=000000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_cck_tssi_D=000000000000 wlan1 flash_set:2G_cck_tssi_D=000000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_bw40_1s_tssi_A=f3f3f2f2f1 wlan1 flash_set:2G_bw40_1s_tssi_A=f3f3f2f2f1 CMD: /bin/iwpriv wlan1 flash_set 2G_bw40_1s_tssi_B=eaeaeaebe9 wlan1 flash_set:2G_bw40_1s_tssi_B=eaeaeaebe9 CMD: /bin/iwpriv wlan1 flash_set 2G_bw40_1s_tssi_C=0000000000 wlan1 flash_set:2G_bw40_1s_tssi_C=0000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_bw40_1s_tssi_D=0000000000 wlan1 flash_set:2G_bw40_1s_tssi_D=0000000000 CMD: /bin/iwpriv wlan1 flash_set 5G_bw40_1s_tssi_A=fdfcf9f800fffcfd0000fffdfcfc wlan1 flash_set:5G_bw40_1s_tssi_A=fdfcf9f800fffcfd0000fffdfcfc CMD: /bin/iwpriv wlan1 flash_set 5G_bw40_1s_tssi_B=faf8f7f5fbf9f8fafafafdfcfaf7 wlan1 flash_set:5G_bw40_1s_tssi_B=faf8f7f5fbf9f8fafafafdfcfaf7 CMD: /bin/iwpriv wlan1 flash_set 5G_bw40_1s_tssi_C=0000000000000000000000000000 wlan1 flash_set:5G_bw40_1s_tssi_C=0000000000000000000000000000 CMD: /bin/iwpriv wlan1 flash_set 5G_bw40_1s_tssi_D=0000000000000000000000000000 wlan1 flash_set:5G_bw40_1s_tssi_D=0000000000000000000000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_CCK_GAIN_DIFF_A=000000000000 wlan1 flash_set:2G_CCK_GAIN_DIFF_A=000000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_CCK_GAIN_DIFF_B=000000000000 wlan1 flash_set:2G_CCK_GAIN_DIFF_B=000000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_CCK_GAIN_DIFF_C=000000000000 wlan1 flash_set:2G_CCK_GAIN_DIFF_C=000000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_CCK_GAIN_DIFF_D=000000000000 wlan1 flash_set:2G_CCK_GAIN_DIFF_D=000000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_GAIN_DIFF_A=0000000000 wlan1 flash_set:2G_GAIN_DIFF_A=0000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_GAIN_DIFF_B=0000000000 wlan1 flash_set:2G_GAIN_DIFF_B=0000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_GAIN_DIFF_C=0000000000 wlan1 flash_set:2G_GAIN_DIFF_C=0000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_GAIN_DIFF_D=0000000000 wlan1 flash_set:2G_GAIN_DIFF_D=0000000000 CMD: /bin/iwpriv wlan1 flash_set 5G_GAIN_DIFF_A=0000000000000000000000000000 wlan1 flash_set:5G_GAIN_DIFF_A=0000000000000000000000000000 CMD: /bin/iwpriv wlan1 flash_set 5G_GAIN_DIFF_B=0000000000000000000000000000 wlan1 flash_set:5G_GAIN_DIFF_B=0000000000000000000000000000 CMD: /bin/iwpriv wlan1 flash_set 5G_GAIN_DIFF_C=0000000000000000000000000000 wlan1 flash_set:5G_GAIN_DIFF_C=0000000000000000000000000000 CMD: /bin/iwpriv wlan1 flash_set 5G_GAIN_DIFF_D=0000000000000000000000000000 wlan1 flash_set:5G_GAIN_DIFF_D=0000000000000000000000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_CCK_CW_DIFF_A=000000000000 wlan1 flash_set:2G_CCK_CW_DIFF_A=000000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_CCK_CW_DIFF_B=000000000000 wlan1 flash_set:2G_CCK_CW_DIFF_B=000000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_CCK_CW_DIFF_C=000000000000 wlan1 flash_set:2G_CCK_CW_DIFF_C=000000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_CCK_CW_DIFF_D=000000000000 wlan1 flash_set:2G_CCK_CW_DIFF_D=000000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_CW_DIFF_A=0000000000 wlan1 flash_set:2G_CW_DIFF_A=0000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_CW_DIFF_B=0000000000 wlan1 flash_set:2G_CW_DIFF_B=0000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_CW_DIFF_C=0000000000 wlan1 flash_set:2G_CW_DIFF_C=0000000000 CMD: /bin/iwpriv wlan1 flash_set 2G_CW_DIFF_D=0000000000 wlan1 flash_set:2G_CW_DIFF_D=0000000000 CMD: /bin/iwpriv wlan1 flash_set 5G_CW_DIFF_A=0000000000000000000000000000 wlan1 flash_set:5G_CW_DIFF_A=00000[ 20.880000] br0: port 5(nas0) entered forwarding state 00000000000000000000000 CMD: /bin/iwpriv wlan1 flash_set 5G_CW_DIFF_B=0000000000000000000000000000 wlan1 flash_set:5G_CW_DIFF_B=0000000000000000000000000000 CMD: /bin/iwpriv wlan1 flash_set 5G_CW_DIFF_C=0000000000000000000000000000 wlan1 flash_set:5G_CW_DIFF_C=0000000000000000000000000000 CMD: /bin/iwpriv wlan1 flash_set 5G_CW_DIFF_D=00000000[ 20.910000] dbg [core_mib_a4_enable][414]oper=1 value=0 0000000000000000[ 20.920000] dbg [core_mib_multiap_monitor_mode_disable][469]oper=1 value=0 0000 wlan1 [ 20.930000] dbg [core_mib_multiap_bss_type][558]32 1 flash_set:5G_CW[ 20.940000] dbg [core_mib_multiap_change_channel][483]oper=1 value=0 _DIFF_D=00000000[ 20.940000] dbg [core_mib_multiap_change_channel][492]ch=0 bw=0 offset=0 0000000000000000[ 20.950000] dbg [core_mib_multiap_change_channel][496]not change channel due to set channel to 0 0000 CMD: /b[ 20.960000] dbg [core_mib_multiap_ext_cmd][529]oper=1 value=0 in/iwpriv wlan1 [ 20.970000] dbg [core_mib_multiap_ext_cmd][532]set rtw_map_user_pid from 0 to 0 flash_set 2G_rx_[ 20.980000] RTW: [core_mib_txforce][txforce] macid:0, fix_rate = 0xffff gain_cck=0 wla[ 20.990000] rtw_phl_mac_set_ru_fwc2h_en: en:0 (intvl:0 ms) n1 flash_set[ 21.000000] rtw_hal_mac_fwc2h_en: en:0, intvl_ms:0 :2G_rx_gain_cck=[ 21.000000] RTW: core_mib_power_percent(1236), interface is not running 0 CMD: /bin/[ 21.010000] RTW: core_mib_power_ref(1260), interface is not running iwpriv wlan1 flash_set 2G_rx_gain_ofdm=0 wlan1 flash_set:2G_rx_gain_ofdm=0[ 21.030000] dbg [core_mib_a4_enable][414]oper=1 value=1 CMD: /bin/i[ 21.030000] dbg [core_mib_multiap_monitor_mode_disable][469]oper=1 value=0 wpriv wlan1 flas[ 21.040000] dbg [core_mib_multiap_bss_type][558]64 2 h_set 5G_rx_gain[ 21.050000] dbg [core_mib_multiap_change_channel][483]oper=1 value=0 _low=0 wlan1 [ 21.060000] dbg [core_mib_multiap_change_channel][492]ch=0 bw=0 offset=0 flash_set:5G_[ 21.070000] dbg [core_mib_multiap_change_channel][496]not change channel due to set channel to 0 rx_gain_low=0 [ 21.080000] dbg [core_mib_multiap_ext_cmd][529]oper=1 value=0 CMD: /bin/iwpr[ 21.080000] dbg [core_mib_multiap_ext_cmd][532]set rtw_map_user_pid from 0 to 0 iv wlan1 flash_s[ 21.090000] RTW: [core_mib_txforce][txforce] macid:0, fix_rate = 0xffff et 5G_rx_gain_mi[ 21.100000] rtw_phl_mac_set_ru_fwc2h_en: en:0 (intvl:0 ms) d=0 wlan1 [ 21.110000] rtw_hal_mac_fwc2h_en: en:0, intvl_ms:0 flash_set:5G_rx_[ 21.120000] RTW: core_mib_power_percent(1236), interface is not running gain_mid=0 C[ 21.130000] RTW: core_mib_power_ref(1260), interface is not running MD: /bin/iwpriv wlan1 flash_set 5G_rx_gain_high=0 wlan1 flash_set:5G_rx_ga[ 21.140000] dbg [core_mib_a4_enable][414]oper=1 value=0 in_high=0 CM[ 21.150000] dbg [core_mib_multiap_monitor_mode_disable][469]oper=1 value=0 D: /bin/iwpriv w[ 21.160000] dbg [core_mib_multiap_bss_type][558]32 1 lan1 flash_set c[ 21.160000] dbg [core_mib_multiap_change_channel][483]oper=1 value=0 han_plan=127 w[ 21.170000] dbg [core_mib_multiap_change_channel][492]ch=0 bw=0 offset=0 lan1 flash_s[ 21.180000] dbg [core_mib_multiap_change_channel][496]not change channel due to set channel to 0 et:chan_plan=127[ 21.190000] dbg [core_mib_multiap_ext_cmd][529]oper=1 value=0 [start_wifi_pr[ 21.200000] dbg [core_mib_multiap_ext_cmd][532]set rtw_map_user_pid from 0 to 0 iv_cfg 746] 0 wl[ 21.210000] RTW: [core_mib_txforce][txforce] macid:0, fix_rate = 0xffff anDisabled=0 [[ 21.220000] rtw_phl_mac_set_ru_fwc2h_en: en:0 (intvl:0 ms) start_wifi_priv_[ 21.220000] rtw_hal_mac_fwc2h_en: en:0, intvl_ms:0 cfg 758]& launch[ 21.230000] RTW: core_mib_power_percent(1236), interface is not running [ 21.240000] RTW: core_mib_power_ref(1260), interface is not running [start_wifi_priv_cfg 746] 0 wlanDisabled=0 [start_wifi_priv_cfg 758]& launch: wlan_idx = 0 [start_wifi_priv_cfg 746] 0 wlanDisabled=1 [start_wifi_priv_cfg 746] 0 wlanDisabled=1 [start_wifi_priv_cfg 746] 0 wlanDisabled=1 [start_wifi_priv_cfg 746] 1 wlanDisabled=0 [start_wifi_priv_cfg 758]& launch: wlan_idx = 1 [start_wifi_priv_cfg 746] 1 wlanDisabled=1 [start_wifi_priv_cfg 746] 1 wlanDisabled=1 [start_wifi_priv_cfg 746] 1 wlanDisabled=1 [start_wifi_priv_cfg 746] 1 wlanDisabled=1 hapd_process_auto_ch(4662) echo 1 into wlan0 coex_2g_40m [ 21.590000] RTW: proc_set_coex_2g_40m(wlan0): coex_2g_40m = 1 gen_hapd_cfg [get_wifi_conf][427][if_idx = 0] ++ psk_enable=2 authtype=2 encmode=2 psk_format=0 gk_rekey=86400 mymytest wpa_cipher=0x0 wpa2_cipher=0x2 enable_1x=0 dot11IEEE80211W=1 enableSHA256=0 <utility.c 701 setup_mac_addr> macAddr[5]+8 = c0 [get_wifi_vif_conf][41][0] ++ V[ 21.620000] dbg [rtw_mib_set][2446]acs=1 AP0: psk_enable=2 authtype=2 encmode=2 psk_format=0 gk_rekey=86400 VAP0: ~s&BgBv0AfQj43Lb1ng1)99&lIc(xO VAP0: wpa_cipher=0x0 wpa2_cipher=0x2 enable_1x=0 VAP0: dot11IEEE80211W=1 enableSHA256=0 <utility.c 701 setup_mac_addr> macAddr[5]+0 = b8 [get_wifi_vif_conf][41][1] ++ [get_wifi_vif_conf][41][2] ++ [get_wifi_vif_conf][41][3] ++ [get_wifi_conf][1078] -- !! Error, [hapd_get_wpa_pairwise][1492] unknown wpa_cipher Generating VAP1 "wlan0-vap0" configuration !! Error, [hapd_get_wpa_pairwise][1492] unknown wpa_cipher wlan0 VAP2 disabled wlan0 VAP3 disabled wlan0 VAP4 disabled C[ 21.680000] dbg [cfg80211_rtw_change_iface][2746]NOT call netdev_open in cfg80211_rtw_change_iface MD: /bin/wpa_cli[ 21.690000] RTW: change mode, old_mode=2, new_mode=4, fw_state=0x8 -g /var/run/hos[ 21.700000] RTW: rtw_set_802_11_infrastructure_mode(wlan0)Start AP mode! (1) tapd/global raw [ 21.710000] RTW: [rtw_hw_start 918] Start flash process !! ADD bss_config=p[ 21.710000] PHL: RP agg is 98 for 416. hy0:/var/run/hap[ 21.720000] PHL: hal_cfg_fw_8192xb : fw_en 1. d_conf_wlan0 [ 21.730000] Clear all bd index done. [ 21.740000] [TRACE]Set R_AX_PLE_DBG_FUN_INTF_CTL to 0x80070000[TRACE]R_AX_PLE_DBG_FUN_INTF_DATA = 0xffffffff [ 21.790000] PHL: hal_mac_print_fw_version: FW version V0.27.50.8, Ready [ 21.790000] PHL: ERROR _hal_mac_get_ofld_cap : disable fw ofld cmd! [ 21.800000] PHL: Set RX packet size filter to 8192B [ 21.830000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/PHY_REG.txt" (2835/27250) OK. [ 21.850000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/PHY_REG_GAIN.txt" (257/3551) OK. [ 21.880000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/RadioA.txt" (1613/20233) OK. [ 21.900000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/RadioB.txt" (1585/20061) OK. [ 21.920000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/TXPWR_ByRate.txt" (94/2327) OK. [ 21.940000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/TXPWR_TrackTSSI.txt" (671/2403) OK. [ 21.970000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/TXPWR_LMT.txt" (4452/24723) OK. /bin/bash: can't open '/var/flush_tr069_static_rule': No such file or directory [ 22.020000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/TXPWR_LMT_RU.txt" (3024/16193) OK. getInAddr(nas0_0): get interface IP address/subnet mask fail, skip record Open file /var/tmp/hosts failed ! [ 22.110000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/AP_5G/PHY_REG.txt" (1/33) OK. [ 22.120000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/AP_5G/PHY_REG_GAIN.txt" (1/34) OK. [ 22.130000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/AP_5G/RadioA.txt" (1/37) OK. [ 22.150000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/AP_5G/RadioB.txt" (1/37) OK. [ 22.160000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/AP_5G/TXPWR_ByRate.txt" (94/2327) OK. [ 22.180000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/AP_5G/TXPWR_TrackTSSI.txt" (671/2396) OK. [ 22.210000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/AP_5G/TXPWR_LMT.txt" (4452/24723) OK. [ 22.230000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8832bre/RFE50/AP_5G/TXPWR_LMT_RU.txt" (3024/16215) OK. [ 22.430000] PHL: rtw_hal_mac_fw_log_cfg: level 4, output 0x00000000, comp 0x00000000, comp ext 0x00000000. [ 22.440000] PHL: rtw_hal_mac_fw_log_cfg: level 4, output 0x00000002, comp 0x00000000, comp ext 0x00000000. [ 22.450000] PHL: rtw_hal_mac_fw_log_cfg: level 4, output 0x00000002, comp 0x00000004, comp ext 0x00000000. [ 22.460000] PHL: rtw_hal_start: Get MAC(0xd200) ok!!! 0x00000000 [ 22.470000] PHL: power limit switching is available [ 22.470000] PHL: Set regular_idx:1 (REGULATION_ETSI) [ 22.480000] PHL: Set MAC(0xd200) ok!!! 0x00000000 [ 22.490000] PHL: phl_rx_start_pcie [ 22.490000] RTW: rtw_update_sw_cap : sw_role_cap->bf_cap 1020 [ 22.500000] PHL: Config role #0 of type 2. MBSSID: 0. [ 22.500000] PHL: Initializing port 0 with 0 M-BSSID. [ 22.510000] RTW: [rtw_hw_iface_init] enable interrupt in the END of init [ 22.520000] RTW: rtw_phl_enable_sounding, MU 1, SND_FLAG 0 [ 22.520000] RTW: rtw_phl_enable_sounding, sounding_flag 2a [ 22.530000] dbg [netdev_br_init][2276]CONFIG_BR_EXT_BRNAME=br0 [ 22.530000] dbg [netdev_br_init][2281]br_netdev->dev_addr=ec:b1:e0:38:f4:b8 [ 22.540000] [_netdev_open] change tx_mode form 0 to 0 [ 22.550000] RTW: _netdev_open, set manual edca para <read_event:3422> [RTM_NEWLINK] b[ 22.560000] device wlan0 entered promiscuous mode r0 down not runn[ 22.560000] RTW: rtw_set_country_cmd country_code:"RU" mapping to chplan:0x09 ing [ 22.570000] RTW: rtw_set_country_cmd country_code:"RU" mapping to chplan:0x09 <read_event:3422> [RTM_NEWLINK] br0 up not running <read_event:3422> [RTM_NEWLIN[ 22.590000] [WARNING][BB][halbb_pmac_statistics_io_en] phy=0, fc=0 K] br0 up not running <read_event:3422> [RTM_NEWLINK] eth0 up running OK <read_event:3422> [RTM_NEWLINK] eth0.2 up not running <read_event:3422> [RTM_NEWLINK] eth0.3 up not running <read_event:3422> [RTM_NEWLINK] eth0.4 up not running <read_event:3422> [RTM_NEWLINK] eth0.5 up not running <read_event:3422> [RTM_NEWLINK] nas0 dow[ 22.620000] PHL: Set RX packet size filter to 8192B n not running <read_event:3422> [RTM_NEWLINK] nas0 down not running <read_event:3422> [RTM_NEWLINK] nas0 down not running <read_event:3422> [RTM_NEWLINK] nas0 down not running <read_event:3422> [RTM_NEWLINK] br0 up not running <read_event:3422> [RTM_NEWLINK] nas0 up running <read_event:3422> [RTM_NEWLINK] br0 up running <read_event:3422> [RTM_NEWLINK] wlan0 down not running <read_event:3422> [RTM_NEWLINK] wlan0 up not running <read_event:3422> [RTM_NEWLINK] wlan0 up not running <read_event:3422> [RTM_NEWLINK] wlan0 up not running <read_event:3422> [RTM_NEWLINK] wlan0 up not running <read_event:3422> [RTM_NEWLINK] br0 up running <read_event:3735> [RTM_NEWADDR] ifname=br0, new ipv6 Addr=fe80::1, prefix_len=64 <read_event:3735> [RTM_NEWADDR] ifname=br0, new ipv6 Addr=fe80::eeb1:e0ff:fe38:f4b8, prefix_len=64 [ 25.030000] RTW: wlan0 has no STA. Not issue BC deauth. [ 25.120000] RTW: Beacon BSS MAC: ec:b1:e0:38:f4:c0 [ 25.130000] dbg [rtw_build_he_phy_caps][789]force enable RX ldpc [ 25.140000] dbg [rtw_build_he_phy_caps][801]no RX stbc [ 25.140000] RTW: [rtw_build_he_supp_mcs] bw_cap:0 [ 25.150000] RTW: rtw_set_country_cmd country_code:"RU" mapping to chplan:0x09 [ 25.160000] RTW: IE CH(48) BW(2) OF(1) [ 25.160000] RTW: start_bss_network(wlan0) C(0) B(-1) O(-1) [ 25.170000] RTW: rtw_ap_chbw_decision(wlan0) IE ch (0)=48 bw=2 off=1 [ 25.170000] RTW: rtw_ap_chbw_decision(wlan0) ifbmp=0x0001 cur: ch=48 bw=2 off=1, dec: ch=48 bw=2 off=1 [ 25.180000] dbg [rtw_ap_chbw_decision][7088]3: ifbmp=0x0001 cur: ch=48 bw=2 off=1, dec: ch=48 bw=2 off=1 [ 25.190000] dbg [rtw_ap_chbw_decision][7127]4: ifbmp=0x0001 cur: ch=48 bw=2 off=1, dec: ch=48 bw=2 off=1 [ 25.200000] dbg [rtw_ap_chbw_decision][7228]8: ifbmp=0x0001 cur: ch=48 bw=2 off=1, dec: ch=48 bw=2 off=3 [ 25.220000] RTW: wlan0 cur: ch=48 bw=2 off=3 [ 25.220000] RTW: rtw_ap_chbw_decision(wlan0) Final: S1 C48 B2 O3 I0001 [ 25.230000] RTW: update_wireless_mode(wlan0) chan=48, network_type=22, wireless_mode=22(3f) [ 25.290000] rtw_phl_ru_set_ch_bw: [ 25.290000] RTW: assoc success [ 25.290000] br0: port 6(wlan0) entered forwarding state [ 25.300000] br0: port 6(wlan0) entered forwarding state <read_event:3422> [RTM_NEWLINK] w[ 25.310000] RTW: setkey_hdl: set group key for ec:b1:e0:38:f4:c0, kid:1 type:1 algo:AES [ 25.320000] RTW: setkey_hdl: set group key for ec:b1:e0:38:f4:c0, kid:4 type:2 algo:BIP_CMAC_128 [ 25.330000] RTW: Finding existing adapter of name "wlan0-vap0"... [ 25.340000] RTW: cfg80211_rtw_add_virtual_intf(wlan0-vap0) got existing adapter [ 25.340000] dbg [cfg80211_rtw_change_iface][2746]NOT call netdev_open in cfg80211_rtw_change_iface [ 25.350000] RTW: change mode, old_mode=2, new_mode=4, fw_state=0x8 [ 25.360000] RTW: rtw_set_802_11_infrastructure_mode(wlan0-vap0)Start AP mode! (1) [ 25.370000] RTW: ERROR wlan0-vap0 cmd 3 to PHL failed. (1)<read_event:3422> [RTM_NEWLINK] w[ 25.370000] device wlan0-vap0 entered promiscuous mode lan0-vap0 down n[ 25.380000] RTW: rtw_update_sw_cap : sw_role_cap->bf_cap 1020 ot running <rea[ 25.390000] PHL: Creating VAP with M-BSSID 1. d_event:3422> [R[ 25.400000] PHL: Config role #1 of type 3. MBSSID: 1. TM_NEWLINK] wlan[ 25.400000] dbg [netdev_br_init][2276]CONFIG_BR_EXT_BRNAME=br0 0-vap0 down not [ 25.410000] dbg [netdev_br_init][2281]br_netdev->dev_addr=ec:b1:e0:38:f4:b8 running <read_e[ 25.420000] RTW: _netdev_open, set manual edca para vent:3422> [RTM_NEWLINK] wlan0-v[ 25.430000] RTW: wlan0-vap0 has no STA. Not issue BC deauth. ap0 down not running <read_event:3422> [RTM_NEWLINK] wlan0-vap0 down not running <read_event:3422> [RTM_NEWLINK] br0 up running <read_event:3422> [RTM_NEWLINK] wlan0-vap0 up not running [ 25.510000] RTW: Beacon BSS MAC: ee:b1:e0:38:f4:b8 [ 25.510000] dbg [rtw_build_he_phy_caps][789]force enable RX ldpc [ 25.520000] dbg [rtw_build_he_phy_caps][801]no RX stbc [ 25.530000] RTW: [rtw_build_he_supp_mcs] bw_cap:0 [ 25.530000] RTW: rtw_set_country_cmd country_code:"RU" mapping to chplan:0x09 [ 25.540000] RTW: IE CH(52) BW(2) OF(1) [ 25.540000] RTW: start_bss_network(wlan0-vap0) C(0) B(-1) O(-1) [ 25.550000] RTW: rtw_ap_chbw_decision(wlan0-vap0) IE ch (0)=52 bw=2 off=1 [ 25.560000] RTW: rtw_ap_chbw_decision(wlan0-vap0) ifbmp=0x0002 cur: ch=52 bw=2 off=1, dec: ch=52 bw=2 off=1 [ 25.570000] RTW: Others(0001) union:48,2,3 [ 25.570000] dbg [rtw_ap_chbw_decision][7023]2: ifbmp=0x0002 cur: ch=52 bw=2 off=1, dec: ch=52 bw=2 off=1 [ 25.580000] dbg [rtw_ap_chbw_decision][7228]8: ifbmp=0x0002 cur: ch=52 bw=2 off=1, dec: ch=48 bw=2 off=3 [ 25.590000] RTW: wlan0-vap0 cur: ch=48 bw=2 off=3 [ 25.600000] RTW: rtw_ap_chbw_decision(wlan0-vap0) Final: S1 C48 B2 O3 I0002 [ 25.610000] RTW: update_wireless_mode(wlan0-vap0) chan=48, network_type=22, wireless_mode=22(3f) [ 25.620000] RTW: assoc success [ 25.620000] br0: port 7(wlan0-vap0) entered forwarding state [ 25.630000] br0: port 7(wlan0-vap0) entered forwarding state <read_event:3422> [RTM_NEWLINK] w[ 25.630000] RTW: setkey_hdl: set group key for ee:b1:e0:38:f4:b8, kid:1 type:1 algo:AES lan0-vap0 up run[ 25.650000] RTW: setkey_hdl: set group key for ee:b1:e0:38:f4:b8, kid:4 type:2 algo:BIP_CMAC_128 ning hapd_process_auto_ch(4662) echo 1 into wlan1 coex_2g_40m [ 25.700000] RTW: proc_set_coex_2g_40m(wlan1): coex_2g_40m = 1 gen_hapd_cfg [get_wifi_conf][427][if_idx = 1] ++ mib_info_id: get mib info id failed! (id=1353) psk_enable=2 authtype=2 encmode=2 psk_format=0 gk_rekey=86400 mymytest wpa_cipher=0x0 wpa2_cipher=0x2 enable_1x=0 dot11IEEE80211W=1 enableSHA256=0 <utility.c 701 setup_mac_addr> macAddr[5]+9 = c1 [get_wifi_vif_conf][41][0] ++ [get_wifi_vif_conf][41][1] ++ [get_wifi_vif_conf][41][2] ++ [ge[ 25.740000] dbg [rtw_mib_set][2446]acs=1 t_wifi_vif_conf][41][3] ++ [get_wifi_conf][1078] -- !! Error[ 25.750000] dbg [cfg80211_rtw_change_iface][2746]NOT call netdev_open in cfg80211_rtw_change_iface , [hapd_get_wpa[ 25.760000] RTW: change mode, old_mode=2, new_mode=4, fw_state=0x8 _pairwise][1492][ 25.770000] RTW: rtw_set_802_11_infrastructure_mode(wlan1)Start AP mode! (1) unknown wpa_cipher wlan1 VAP[ 25.780000] RTW: [rtw_hw_start 918] Start flash process !! 1 disabled wl[ 25.790000] PHL: RP agg is 98 for 416. an1 VAP2 disable[ 25.790000] PHL: hal_cfg_fw_8192xb : fw_en 1. d wlan1 VAP3 disabled wlan1 VAP4 disabled CMD: /bin/wpa_cli -g /var/run/hostapd/global raw ADD bss_con[ 25.810000] Clear all bd index done. fig=phy1:/var/ru[ 25.810000] [TRACE]Set R_AX_PLE_DBG_FUN_INTF_CTL to 0x80070000n/hapd_conf_wlan1 <read_event:[TRACE]R_AX_PLE_DBG_FUN_INTF_DATA = 0xffffffff 3422> [RTM_NEWLINK] wlan1 down not running [ 25.870000] PHL: hal_mac_print_fw_version: FW version V0.27.50.8, Ready [ 25.880000] PHL: ERROR _hal_mac_get_ofld_cap : disable fw ofld cmd! [ 25.880000] PHL: Set RX packet size filter to 4096B [ 25.910000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/PHY_REG.txt" (2835/27250) OK. [ 25.930000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/PHY_REG_GAIN.txt" (257/3551) OK. [ 25.960000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/RadioA.txt" (995/11338) OK. [ 25.980000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/RadioB.txt" (813/9050) OK. [ 26.000000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/TXPWR_ByRate.txt" (94/2327) OK. [ 26.020000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/TXPWR_TrackTSSI.txt" (671/2485) OK. [ 26.060000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/TXPWR_LMT.txt" (4452/24952) OK. [ 26.090000] PHL: _hal_dl_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/TXPWR_LMT_RU.txt" (3024/16193) OK. [ 26.170000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/AP_2G/PHY_REG.txt" (21/298) OK. [ 26.180000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/AP_2G/PHY_REG_GAIN.txt" (1/54) OK. [ 26.200000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/AP_2G/RadioA.txt" (3/72) OK. [ 26.210000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/AP_2G/RadioB.txt" (3/72) OK. [ 26.220000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/AP_2G/TXPWR_ByRate.txt" (94/2329) OK. [ 26.240000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/AP_2G/TXPWR_TrackTSSI.txt" (671/2468) OK. [ 26.260000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/AP_2G/TXPWR_LMT.txt" (4452/24952) OK. [ 26.280000] PHL: _hal_dl_ext_para_file:: Download file "/etc/conf/rtl8192xbe/RFE50/AP_2G/TXPWR_LMT_RU.txt" (3024/16205) OK. [ 26.300000] br0: port 6(wlan0) entered forwarding state [ 26.480000] PHL: rtw_hal_mac_fw_log_cfg: level 4, output 0x00000002, comp 0x00000004, comp ext 0x00000000. [ 26.490000] PHL: rtw_hal_mac_fw_log_cfg: level 4, output 0x00000002, comp 0x00000004, comp ext 0x00000000. [ 26.500000] PHL: rtw_hal_mac_fw_log_cfg: level 4, output 0x00000002, comp 0x00000004, comp ext 0x00000000. [ 26.510000] PHL: rtw_hal_start: Get MAC(0xd200) ok!!! 0x00000000 [ 26.510000] PHL: power limit switching is available [ 26.520000] PHL: Set regular_idx:1 (REGULATION_ETSI) [ 26.530000] PHL: Set MAC(0xd200) ok!!! 0x00000000 [ 26.540000] PHL: phl_rx_start_pcie [ 26.540000] RTW: rtw_update_sw_cap : sw_role_cap->bf_cap 1020 [ 26.550000] PHL: Config role #0 of type 2. MBSSID: 0. [ 26.550000] PHL: Initializing port 0 with 0 M-BSSID. [ 26.560000] RTW: [rtw_hw_iface_init] enable interrupt in the END of init [ 26.570000] RTW: rtw_phl_enable_sounding, MU 1, SND_FLAG 0 [ 26.570000] RTW: rtw_phl_enable_sounding, sounding_flag 2a [ 26.580000] dbg [netdev_br_init][2276]CONFIG_BR_EXT_BRNAME=br0 [ 26.580000] dbg [netdev_br_init][2281]br_netdev->dev_addr=ec:b1:e0:38:f4:b8 [ 26.590000] [_netdev_open] change tx_mode form 0 to 0 [ 26.600000] RTW: _netdev_open, set manual edca para <read_event:3422> [RTM_NEWLINK] w[ 26.610000] device wlan1 entered promiscuous mode lan1 up not runn[ 26.610000] RTW: rtw_set_country_cmd country_code:"RU" mapping to chplan:0x09 ing <read_event[ 26.620000] RTW: rtw_set_country_cmd country_code:"RU" mapping to chplan:0x09 :3422> [RTM_NEWL[ 26.630000] br0: port 7(wlan0-vap0) entered forwarding state INK] wlan1 up no[ 26.630000] PHL: Set RX packet size filter to 4096B t running <read_event:3422> [RTM_NEWLINK] wlan1 up not running <OK read_event:3422> [RTM_NEWLINK] wlan1 up not running <read_event:3422> [RTM_NEWLINK] br0 up running [ 29.940000] RTW: wlan1 has no STA. Not issue BC deauth. [ 30.030000] RTW: Beacon BSS MAC: ec:b1:e0:38:f4:c1 [ 30.030000] dbg [rtw_build_he_phy_caps][789]force enable RX ldpc [ 30.040000] dbg [rtw_build_he_phy_caps][801]no RX stbc [ 30.050000] RTW: [rtw_build_he_supp_mcs] bw_cap:0 [ 30.050000] RTW: rtw_set_country_cmd country_code:"RU" mapping to chplan:0x09 [ 30.060000] RTW: IE CH(3) BW(1) OF(3) [ 30.060000] RTW: start_bss_network(wlan1) C(0) B(-1) O(-1) [ 30.070000] RTW: rtw_ap_chbw_decision(wlan1) IE ch (0)=3 bw=1 off=3 [ 30.080000] RTW: rtw_ap_chbw_decision(wlan1) ifbmp=0x0001 cur: ch=3 bw=1 off=3, dec: ch=3 bw=1 off=3 [ 30.090000] dbg [rtw_ap_chbw_decision][7088]3: ifbmp=0x0001 cur: ch=3 bw=1 off=3, dec: ch=3 bw=1 off=3 [ 30.100000] dbg [rtw_ap_chbw_decision][7127]4: ifbmp=0x0001 cur: ch=3 bw=1 off=3, dec: ch=3 bw=1 off=3 [ 30.110000] dbg [rtw_ap_chbw_decision][7228]8: ifbmp=0x0001 cur: ch=3 bw=1 off=3, dec: ch=3 bw=1 off=1 [ 30.120000] RTW: wlan1 cur: ch=3 bw=1 off=1 [ 30.120000] RTW: rtw_ap_chbw_decision(wlan1) Final: S1 C3 B1 O1 I0001 [ 30.130000] RTW: update_wireless_mode(wlan1) chan=3, network_type=25, wireless_mode=25(3d) [ 30.190000] rtw_phl_ru_set_ch_bw: [ 30.200000] RTW: assoc success [ 30.200000] br0: port 8(wlan1) entered forwarding state [ 30.210000] br0: port 8(wlan1) entered forwarding state <read_event:3422>[ 30.210000] RTW: setkey_hdl: set group key for ec:b1:e0:38:f4:c1, kid:1 type:1 algo:AES [RTM_NEWLINK] w[ 30.220000] RTW: setkey_hdl: set group key for ec:b1:e0:38:f4:c1, kid:4 type:2 algo:BIP_CMAC_128 lan1 up running CMD: /bin/iwpriv wlan0 set_mi[ 30.690000] dbg [rtw_mib_set][2446]powerpercent=100 b powerpercent=1[ 30.700000] RTW: core_mib_power_percent(1231)set ref power, percent: 100, diff: 0 00 CMD: /bin/iwpriv wlan0 set_mi[ 30.710000] dbg [rtw_mib_set][2446]twt_enable=0 [ 30.710000] dbg [rtw_build_he_phy_caps][789]force enable RX ldpc [ 30.720000] dbg [rtw_build_he_phy_caps][801]no RX stbc [ 30.730000] RTW: [rtw_build_he_supp_mcs] bw_cap:0 File: /var/wlan0-vap0 has no linked, link now... [ 30.780000] dbg [rtw_mib_set][2446]band=204 [ 30.790000] RTW: update_wireless_mode(wlan0-vap0) chan=48, network_type=22, wireless_mode=22(3f) CMD: /bin/iwpriv wlan1 set_mi[ 30.800000] dbg [rtw_mib_set][2446]powerpercent=100 b powerpercent=1[ 30.810000] RTW: core_mib_power_percent(1231)set ref power, percent: 100, diff: 0 00 CMD: /bin/iwpriv wlan1 set_mi[ 30.820000] dbg [rtw_mib_set][2446]twt_enable=0 [ 30.830000] dbg [rtw_build_he_phy_caps][789]force enable RX ldpc [ 30.840000] dbg [rtw_build_he_phy_caps][801]no RX stbc [ 30.840000] RTW: [rtw_build_he_supp_mcs] bw_cap:0 CMD: /bin/config_reinit -m [ 30.890000] dbg [rtw_mib_set][2446]multiap_ext_cmd=1 [ 30.900000] dbg [core_mib_multiap_ext_cmd][529]oper=1 value=0 [ 30.900000] dbg [core_mib_multiap_ext_cmd][532]set rtw_map_user_pid from 0 to 0 [ 30.930000] dbg [rtw_mib_set][2446]multiap_ext_cmd=1 [ 30.940000] dbg [core_mib_multiap_ext_cmd][529]oper=1 value=0 [ 30.940000] dbg [core_mib_multiap_ext_cmd][532]set rtw_map_user_pid from 0 to 0 [ 31.210000] br0: port 8(wlan1) entered forwarding state Sorry, rule does not exist. Sorry, rule does not exist. [CONFIG] map_supported_service is 1 max_log_size is: 100 kB Multi AP controller daemon is running with 0 ERROR [main 1185] Can't load configuration file!! [CONFIG] map[ 31.750000] dbg [rtw_mib_set][2446]multiap_dfs_ap_mib_channel=44 _supported_service is 1 Multi AP checker is running with 0 [main 1286]:map_checker_debug on : 0, bridge name : br0 [ 31.790000] dbg [rtw_mib_set][2446]multiap_profile=1 [ 31.790000] dbg [rtw_mib_set][2446]multiap_profile=1 [ 31.800000] dbg [rtw_mib_set][2446]multiap_profile=1 ps for map_controller found, pid is 847 xml_mib_update():... [parser_read_topology_json:256] open '/tmp/topology_json' failed CMD: /bin/ethctl conntrack killall [ 31.880000] eth_ctl(78): gen_wlan_mgr_cfg ------ [-u cs]Update cs setting ------ [ 32.280000] dbg [rtw_mib_set][2446]multiap_vlan_id=0 [xml_INFO]: Update cs configuration success. Wlan Manager Daemon start... CMD: /bin/ebtables -F wlan_block Chain 'wlan_block' doesn't exist. CMD: /bin/ebtables -D FORWARD -j wlan_block Illegal target name 'wlan_block'. CMD: /bin/ebtables -X wlan_block Chain 'wlan_block' doesn't exist. CMD: /bin/ebtables -N wlan_block -P RETURN CMD: /bin/ebtables -I FORWARD -j wlan_block CMD: /bin/ifconfig br0 up [WLAN_MANAGER] config: /var/run/wlan_manager_conf. [WLAN_MANAGER] v2.0. CMD: /bin/udhcpc -i br0 -p CMD: /var/run/udhcpc.pid.br0 -s /etc/scripts/udhcpc.sh -t 0 main 937 wan_ifIndex=-1 client_config.interface=br0 udhcp client (v0.9.8) started initialDhcpcOptionTbl: existing rule num:44 initialDhcpcOptionTbl: add 0 rule to interface 0xffffffff 00:00:34 WARN : DE - MAP_OPERATING_CHANNEL_REPORT_ELEMENT : Device not found! Skip data element update... CMD: /bin/boa CMD: /bin/iptables -F CMD: /bin/iptables -P INPUT ACCEPT CMD: /bin/ebtables -F CMD: /bin/iptables -t nat -F CMD: /bin/ip6tables -F CMD: /bin/ip6tables -P INPUT ACCEPT CMD: /bin/iptables -X aclblock iptables: No chain/target/match by that name. CMD: /bin/iptables -t nat -X aclblock iptables: No chain/target/match by that name. CMD: /bin/iptables -t mangle -F aclblock iptables: No chain/target/match by that name. CMD: /bin/iptables -t mangle -D PREROUTING -j aclblock iptables v1.4.18: Couldn't find target `aclblock' Try `iptables -h' or 'iptables --help' for more information. CMD: /bin/ip6tables -X aclblock ip6tables: No chain/target/match by that name. CMD: /bin/ip6tables -t nat -X aclblock ip6tables: No chain/target/match by that name. CMD: /bin/ip6tables -t mangle -F aclblock ip6tables: No chain/target/match by that name. CMD: /bin/ip6tables -t mangle -D PREROUTING -j aclblock ip6tables v1.4.18: Couldn't find target `aclblock' Try `ip6tables -h' or 'ip6tables --help' for more information. CMD: /bin/iptables -X cwmp_aclblock iptables: No chain/target/match by that name. CMD: /bin/iptables -t mangle -F cwmp_aclblock iptables: No chain/target/match by that name. CMD: /bin/iptables -t mangle -D PREROUTING -j cwmp_aclblock iptables v1.4.18: Couldn't find target `cwmp_aclblock' Try `iptables -h' or 'iptables --help' for more information. CMD: /bin/eb[ 34.390000] ubi0 error: ubi_open_volume: cannot open device 0, volume 0, error -16 tables -X br_lan_out Chain 'br_lan_out' doesn't exist. CMD: /bin/iptables -X domainblk iptables: No chain/target/match by that name. CMD: /bin/ip6tables -X domainblk ip6tables: No chain/target/match by that name. CMD: /bin/iptables -t mangle -F mark_for_dns_filter iptables: No chain/target/match by that name. CMD: /bin/iptables -t mangle -D PREROUTING -j mark_for_dns_filter iptables v1.4.18: Couldn't find target `mark_for_dns_filter' Try `iptables -h' or 'iptables --help' for more information. CMD: /bin/iptables -t mangle -X mark_for_dns_filter iptables: No chain/target/match by that name. CMD: /bin/iptables -X portfw iptables: No chain/target/match by that name. CMD: /bin/iptables -t nat -X portfw iptables: No chain/target/match by that name. CMD: /bin/iptables -t nat -X portfwPreNatLB iptables: No chain/target/match by that name. CMD: /bin/iptables -t nat -X portfwPostNatLB iptables: No chain/target/match by that name. CMD: /bin/iptables -X dmz Original [] is missing!! Switch to new default [en]. iptables: No chain/target/match by that name. CMD: /bin/iptables -t nat -X dmz iptables: No chain/target/match by that name. CMD: /bin/iptables -t nat -X dmzPreNatLB iptables: No chain/target/match by that name. CMD: /bin/iptables -t nat -X dmzPostNatLB iptables: No chain/target/match by that name. CMD: /bin/iptables -X portmapping_dhcp iptables: No chain/target/match by that name. CMD: /bin/ip6tables -X portmapping_dhcp ip6tables: No chain/target/match by that name. CMD: /bin/ebtables -X portmapping_igmp Chain 'portmapping_igmp' doesn't exist. CMD: /bin/iptables -X dhcp_port_filter iptables: No chain/target/match by that name. CMD: /bin/iptables -X ipfilter iptables: No chain/target/match by that name. CMD: /bin/iptables -X parental_ctrl iptables: No chain/target/match by that name. CMD: /bin/ip6tables -X parental_ctrl ip6tables: No chain/target/match by that name. CMD: /bin/iptables -X protocol_filter iptables: No chain/target/match by that name. CMD: /bin/ip6tables -X ipv6filter ip6tables: No chain/target/match by that name. CMD: /bin/ebtables -D FORWARD -j macfilter /bin/sh: can't create /proc/dos_syslog: nonexistent directory Illegal target name 'macfilter'. CMD: /bin/ebtables -X macfilter Chain 'macfilter' doesn't exist. CMD: /bin/iptables -t mangle -D PREROUTING -j usb_modem_ttl_pre iptables v1.4.18: Couldn't find target `usb_modem_ttl_pre' Try `iptables -h' or 'iptables --help' for more information. CMD: /bin/iptables -t mangle -D POSTROUTING -j usb_modem_ttl_post iptables v1.4.18: Couldn't find target `usb_modem_ttl_post' Try `iptables -h' or 'iptables --help' for more information. CMD: /bin/iptables -X urlblock iptables: No chain/target/match by that name. CMD: /bin/ip6tables -X urlblock ip6tables: No chain/target/match by that name. CMD: /bin/iptables -t mangle -F mark_for_url_filter iptables: No chain/target/match by that name. CMD: /bin/iptables -t mangle -D PREROUTING -j mark_for_url_filter iptables v1.4.18: Couldn't find target `mark_for_url_filter' Try `iptables -h' or 'iptables --help' for more information. CMD: /bin/iptables -t mangle -X mark_for_url_filter iptables: No chain/target/match by that name. CMD: /bin/iptables -X tr069 iptables: No chain/target/match by that name. CMD: /bin/ip6tables -X ipv6_tr069 ip6tables: No chain/target/match by that name. CMD: /bin/iptables -t raw -D PREROUTING -j vpnPassThrough iptables v1.4.18: Couldn't find target `vpnPassThrough' Try `iptables -h' or 'iptables --help' for more information. CMD: /bin/iptables -t raw -F vpnPassThrough iptables: No chain/target/match by that name. CMD: /bin/iptables -t raw -X vpnPassThrough iptables: No chain/target/match by that name. CMD: /bin/iptables -t raw -D OUTPUT -j vpnPassThroughOutput iptables v1.4.18: Couldn't find target `vpnPassThroughOutput' Try `iptables -h' or 'iptables --help' for more information. CMD: /bin/iptables -t raw -F vpnPassThroughOutput iptables: No chain/target/match by that name. CMD: /bin/iptables -t raw -X vpnPassThroughOutput iptables: No chain/target/match by that name. CMD: /bin/ebtables -N macfilter CMD: /bin/ebtables -F macfilter /bin/ebtables -P macfilter RETURN CMD: /bin/echo 2 > /proc/fastbridge /bin/sh: can't create /proc/fastbridge: nonexistent directory getVCIndexByName(br0) failed CMD: /bin/ebtables -A FORWARD -j macfilter CMD: /bin/ebtables -A INPUT -j macfilter CMD: /bin/ebtables -N wlan_map_block -P RETURN Chain wlan_map_block already exists. CMD: /bin/ebtables -D FORWARD -j wlan_map_block Sorry, rule does not exist. CMD: /bin/ebtables -I FORWARD -j wlan_map_block CMD: /bin/ebtables -N map_portmapping -P RETURN Chain map_portmapping already exists. CMD: /bin/ebtables -D FORWARD -j map_portmapping Sorry, rule does not exist. CMD: /bin/ebtables -A FORWARD -j map_portmapping CMD: /bin/ebtables -F wlan_map_block CMD: /bin/ebtables -A wlan_map_block -d 01:80:c2:00:00:13 -j DROP CMD: /bin/brctl stp br0 on CMD: /bin/brctl setbridgeprio br0 0 HAPD EVENT: wlan0-vap0 INTERFACE-ENABLED [ 34.950000] port 6 assign to nas0 system(): echo 0x40 > /proc/fc/ctrl/wan_port_mask Dump WAN port mask:0x40 [ 35.020000] mode=1 , rtk_op_mode = 0 CMD: /bin/smuxctl --if nas0 --set-if-rsmux --set-if-rx-policy ACCEPT --set-if-tx-policy CONTINUE --set-if-rxmc-policy DROP --set-if-rx-multi 1 CMD: /bin/sh -c echo wlan 0 mode 1 cpu 0 > /proc/fc/ctrl/[ 35.220000] WLAN0 Dispatch mode: 1, cpu: 0 smp_dispatch_wifi_tx CMD: /bin/sh -c echo wlan 1 mode 1 cpu 2 > /proc/fc/ctrl/smp_dispatch_wifi_rx [ 35.240000] WLAN1 Dispatch mode: 1, cpu: 2 CMD: /bin/sh -c echo 1 > /proc/irq/61/smp_affinity CMD: /bin/sh -c echo 8 > /proc/irq/73/smp_affinity startMiniDLNA: is disabled, line=16268 killall: haproxy: no process killed CMD: /bin/iptables -F INPUT_HAPROXY iptables: No chain/target/match by that name. CMD: /bin/iptables -D INPUT -j INPUT_HAPROXY iptables v1.4.18: Couldn't find target `INPUT_HAPROXY' Try `iptables -h' or 'iptables --help' for more information. HA-Proxy version 1.7.12 2019/10/25 Copyright 2000-2019 Willy Tarreau <willy@haproxy.org> CMD: /bin/iptables -D INPUT -j INPUT_HAPROXY CMD: /bin/iptables -A INPUT -j INPUT_HAPROXY iptables v1.4.18: Couldn't find target `INPUT_HAPROXY' Try `iptables -h' or 'iptables --help' for more information. CMD: /bin/iptables -F INPUT_HAPROXY iptables v1.4.18: Couldn't find target `INPUT_HAPROXY' Try `iptables -h' or 'iptables --help' for more information. CMD: /bin/iptables -A INPUT_HAPROXY -p tcp --dport 7475 -j ACCEPT iptables: No chain/target/match by that name. iptables: No chain/target/match by that name. getVCIndexByName(br0) failed getVCIndexByName(br0) failed getVCIndexByName(br0) failed getVCIndexByName(br0) failed getVCIndexByName(br0) failed getVCIndexByName(br0) failed getVCIndexByName(br0) failed starting pid 436, tty '/dev/ttyS0': '-/bin/sh' BusyBox v1.37.0 (2025-09-30 07:41:35 UTC) built-in shell (ash) Enter 'help' for a list of built-in commands. # getVCIndexByName(br0) failed #

## Booting kernel from Legacy Image at 83000000 ... Image Name: MIPS OpenWrt Linux-6.18.21 Image Type: MIPS Linux Kernel Image (lzma compressed) Data Size: 8039143 Bytes = 7.7 MiB Load Address: 80100000 Entry Point: 80100000 Verifying Checksum ... OK Uncompressing Kernel Image [ 0.000000] Linux version 6.18.21 (misha@gamepc) (mips-openwrt-linux-musl-gcc (OpenWrt GCC 14.3.0 r33686+166-aa06d26879) 14.3.0, GNU ld (GNU Binutils) 2.44) #0 SMP Tue Apr 28 15:56:31 2026 [ 0.000000] Realtek RTL9607C subtype 0B rev B (6831) SoC with 256 MB [ 0.000000] printk: legacy bootconsole [early0] enabled [ 0.000000] CPU0 revision is: 0001a120 (MIPS interAptiv (multi)) [ 0.000000] MIPS: machine is BT-PON BT-G711AX [ 0.000000] earlycon: ns16550a0 at MMIO 0x18002000 (options '115200n8') [ 0.000000] printk: legacy bootconsole [ns16550a0] enabled [ 0.000000] Initrd not found or empty - disabling initrd [ 0.000000] Using appended Device Tree. [ 0.000000] OF: reserved mem: Reserved memory: No reserved-memory node in the DT [ 0.000000] VPE topology {2,2} total 4 [ 0.000000] Primary instruction cache 64kB, VIPT, 4-way, linesize 32 bytes. [ 0.000000] Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes [ 0.000000] MIPS secondary cache 256kB, 8-way, linesize 32 bytes. [ 0.000000] Zone ranges: [ 0.000000] Normal [mem 0x0000000000000000-0x000000000fffffff] [ 0.000000] HighMem empty [ 0.000000] Movable zone start for each node [ 0.000000] Early memory node ranges [ 0.000000] node 0: [mem 0x0000000000000000-0x000000000fffffff] [ 0.000000] Initmem setup node 0 [mem 0x0000000000000000-0x000000000fffffff] [ 0.000000] percpu: Embedded 12 pages/cpu s18768 r8192 d22192 u49152 [ 0.000000] pcpu-alloc: s18768 r8192 d22192 u49152 alloc=12*4096 [ 0.000000] pcpu-alloc: [0] 0 [0] 1 [0] 2 [0] 3 [ 0.000000] Kernel command line: earlycon [ 0.000000] printk: log buffer data + meta data: 131072 + 409600 = 540672 bytes [ 0.000000] Dentry cache hash table entries: 32768 (order: 5, 131072 bytes, linear) [ 0.000000] Inode-cache hash table entries: 16384 (order: 4, 65536 bytes, linear) [ 0.000000] Writing ErrCtl register=00000000 [ 0.000000] Readback ErrCtl register=00000000 [ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 65536 [ 0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off [ 0.000000] SLUB: HWalign=32, Order=0-3, MinObjects=0, CPUs=4, Nodes=1 [ 0.000000] rcu: Hierarchical RCU implementation. [ 0.000000] Tracing variant of Tasks RCU enabled. [ 0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 10 jiffies. [ 0.000000] RCU Tasks Trace: Setting shift to 2 and lim to 1 rcu_task_cb_adjust=1 rcu_task_cpu_ids=4. [ 0.000000] NR_IRQS: 256 [ 0.000000] rcu: srcu_init: Setting srcu_struct sizes based on contention. [ 0.000000] rtl83xx-clk: initialized, CPU 1250 MHz, MEM 666 MHz (16 Bit DDR3), LXB 200 MHz [ 0.000000] clocksource: GIC: mask: 0xffffffffffffffff max_cycles: 0x12049cd048c, max_idle_ns: 440795204120 ns [ 0.000002] sched_clock: 64 bits at 1250MHz, resolution 0ns, wraps every 4398046511103ns [ 0.009201] clocksource: realtek_otto_timer: mask: 0xfffffff max_cycles: 0xfffffff, max_idle_ns: 38225208801 ns [ 0.020667] Calibrating delay loop... 829.84 BogoMIPS (lpj=4149248) [ 0.117504] pid_max: default: 32768 minimum: 301 [ 0.130145] Mount-cache hash table entries: 1024 (order: 0, 4096 bytes, linear) [ 0.138350] Mountpoint-cache hash table entries: 1024 (order: 0, 4096 bytes, linear) [ 0.160298] rcu: Hierarchical SRCU implementation. [ 0.165719] rcu: Max phase no-delay instances is 1000. [ 0.173020] smp: Bringing up secondary CPUs ... [ 0.179271] Primary instruction cache 64kB, VIPT, 4-way, linesize 32 bytes. [ 0.179303] Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes [ 0.179314] MIPS secondary cache 256kB, 8-way, linesize 32 bytes. [ 0.179392] CPU1 revision is: 0001a120 (MIPS interAptiv (multi)) [ 0.219508] Counter synchronization [CPU#0 -> CPU#1]: passed [ 0.257482] Primary instruction cache 64kB, VIPT, 4-way, linesize 32 bytes. [ 0.257520] Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes [ 0.257530] MIPS secondary cache 256kB, 8-way, linesize 32 bytes. [ 0.257575] CPU2 revision is: 0001a120 (MIPS interAptiv (multi)) [ 0.306558] Counter synchronization [CPU#0 -> CPU#2]: passed [ 0.343722] Primary instruction cache 64kB, VIPT, 4-way, linesize 32 bytes. [ 0.343749] Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes [ 0.343759] MIPS secondary cache 256kB, 8-way, linesize 32 bytes. [ 0.343812] CPU3 revision is: 0001a120 (MIPS interAptiv (multi)) [ 0.383932] Counter synchronization [CPU#0 -> CPU#3]: passed [ 0.419811] smp: Brought up 1 node, 4 CPUs [ 0.426288] Memory: 226208K/262144K available (8456K kernel code, 652K rwdata, 1740K rodata, 20696K init, 244K bss, 34560K reserved, 0K cma-reserved, 0K highmem) [ 0.446504] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns [ 0.457819] posixtimers hash table entries: 2048 (order: 2, 16384 bytes, linear) [ 0.466305] futex hash table entries: 1024 (32768 bytes on 1 NUMA nodes, total 32 KiB, linear). [ 0.480570] pinctrl core: initialized pinctrl subsystem [ 0.488826] NET: Registered PF_NETLINK/PF_ROUTE protocol family [ 0.496094] thermal_sys: Registered thermal governor 'step_wise' [ 0.496324] FPU Affinity set after 16580 emulations [ 0.522215] clocksource: Switched to clocksource realtek_otto_timer [ 0.536687] NET: Registered PF_INET protocol family [ 0.542478] IP idents hash table entries: 4096 (order: 3, 32768 bytes, linear) [ 0.551489] tcp_listen_portaddr_hash hash table entries: 512 (order: 0, 4096 bytes, linear) [ 0.560891] Table-perturb hash table entries: 65536 (order: 6, 262144 bytes, linear) [ 0.569575] TCP established hash table entries: 2048 (order: 1, 8192 bytes, linear) [ 0.578187] TCP bind hash table entries: 2048 (order: 3, 32768 bytes, linear) [ 0.586323] TCP: Hash tables configured (established 2048 bind 2048) [ 0.594346] MPTCP token hash table entries: 256 (order: 0, 4096 bytes, linear) [ 0.602802] UDP hash table entries: 256 (order: 2, 14336 bytes, linear) [ 0.610237] UDP-Lite hash table entries: 256 (order: 2, 14336 bytes, linear) [ 0.619087] NET: Registered PF_UNIX/PF_LOCAL protocol family [ 0.627486] workingset: timestamp_bits=14 max_order=16 bucket_order=2 [ 0.637863] squashfs: version 4.0 (2009/01/31) Phillip Lougher [ 0.644692] jffs2: version 2.2 (NAND) (SUMMARY) (ZLIB) (LZMA) (RTIME) (CMODE_PRIORITY) (c) 2001-2006 Red Hat, Inc. [ 0.665887] pinctrl-single 1b000038.pinmux: 96 pins, size 12 [ 0.995110] Serial: 8250/16550 driver, 2 ports, IRQ sharing disabled [ 1.004908] printk: legacy console [ttyS0] disabled [ 1.010920] 18002000.uart: ttyS0 at MMIO 0x18002000 (irq = 24, base_baud = 12500000) is a 16550A [ 1.020888] printk: legacy console [ttyS0] enabled [ 1.020888] printk: legacy console [ttyS0] enabled [ 1.031596] printk: legacy bootconsole [early0] disabled [ 1.031596] printk: legacy bootconsole [early0] disabled [ 1.043640] printk: legacy bootconsole [ns16550a0] disabled [ 1.043640] printk: legacy bootconsole [ns16550a0] disabled [ 1.083583] brd: module loaded [ 1.089000] spi-nand spi0.0: GigaDevice SPI NAND was found. [ 1.095543] spi-nand spi0.0: 128 MiB, block size: 128 KiB, page size: 2048, OOB size: 128 [ 1.105026] 5 fixed-partitions partitions found on MTD device spi0.0 [ 1.112137] Creating 5 MTD partitions on "spi0.0": [ 1.117514] 0x000000000000-0x0000000e0000 : "u-boot" [ 1.124724] 0x0000000e0000-0x000000100000 : "u-boot-env" [ 1.132848] 0x000000100000-0x000000120000 : "u-boot-env2" [ 1.141163] 0x000000120000-0x000000140000 : "static_conf" [ 1.149011] 0x000000140000-0x000007d80000 : "ubi" [ 1.257026] i2c_dev: i2c /dev entries driver [ 1.269982] NET: Registered PF_INET6 protocol family [ 1.278722] Segment Routing with IPv6 [ 1.283023] In-situ OAM (IOAM) with IPv6 [ 1.287536] NET: Registered PF_PACKET protocol family [ 1.293286] 8021q: 802.1Q VLAN Support v1.8 [ 1.326912] UBI: auto-attach mtd4 [ 1.330645] ubi0: attaching mtd4 [ 2.072260] random: crng init done [ 2.238229] ubi0: scanning is finished [ 2.293987] ubi0: attached mtd4 (name "ubi", size 124 MiB) [ 2.300166] ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes [ 2.307938] ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048 [ 2.315554] ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096 [ 2.323355] ubi0: good PEBs: 994, bad PEBs: 0, corrupted PEBs: 0 [ 2.330060] ubi0: user volume: 9, internal volumes: 1, max. volumes count: 128 [ 2.338123] ubi0: max/mean erase counter: 4/1, WL threshold: 4096, image sequence number: 95652907 [ 2.348152] ubi0: available PEBs: 21, total reserved PEBs: 973, PEBs reserved for bad PEB handling: 20 [ 2.358610] ubi0: background thread "ubi_bgt0d" started, PID 377 [ 2.358816] clk: Disabling unused clocks [ 2.463360] Freeing unused kernel image (initmem) memory: 20696K [ 2.470090] This architecture does not have kernel memory protection. [ 2.477292] Run /init as init process [ 2.481367] with arguments: [ 2.484675] /init [ 2.487202] with environment: [ 2.490686] HOME=/ [ 2.493313] TERM=linux [ 3.268133] init: Console is alive [ 3.272954] init: - watchdog - [ 3.289983] kmodloader: loading kernel modules from /etc/modules-boot.d/* [ 3.333879] gpio_button_hotplug: loading out-of-tree module taints kernel. [ 3.352960] SCSI subsystem initialized [ 3.364666] Error: Driver 'gpio-keys' is already registered, aborting... [ 3.463365] Error: Driver 'gpio-keys' is already registered, aborting... [ 3.542555] kmodloader: 1 module could not be probed [ 3.548347] kmodloader: - gpio_keys - 0 [ 3.560798] init: - preinit - ls: /sys/class/net/lan*: No such file or directory BusyBox v1.37.0 (2026-01-02 17:07:02 UTC) multi-call binary. Usage: basename FILE [SUFFIX] | -a FILE... | -s SUFFIX FILE... Strip directory path and SUFFIX from FILE -a All arguments are FILEs -s SUFFIX Remove SUFFIX (implies -a) Cannot parse config file '/etc/fw_env.config': No such file or directory Failed to find NVMEM device Press the [f] key and hit [enter] to enter failsafe mode Press the [1], [2], [3] or [4] key and hit [enter] to select the debug level [ 8.283261] procd: - early - [ 8.286750] procd: - watchdog - [ 8.873391] procd: - watchdog - [ 8.877264] procd: - ubus - [ 8.938412] procd: - init - Please press Enter to activate this console. [ 9.373514] kmodloader: loading kernel modules from /etc/modules.d/* [ 9.393440] Error: Driver 'gpio-keys' is already registered, aborting... [ 9.571814] Error: Driver 'gpio-keys' is already registered, aborting... [ 9.702590] kmodloader: 1 module could not be probed [ 9.708494] kmodloader: - gpio_keys - 0 [ 9.783728] urngd: v1.0.2 started. BusyBox v1.37.0 (2026-01-02 17:07:02 UTC) built-in shell (ash) _______ ________ __ | |.-----.-----.-----.| | | |.----.| |_ | - || _ | -__| || | | || _|| _| |_______|| __|_____|__|__||________||__| |____| |__| W I R E L E S S F R E E D O M ----------------------------------------------------- OpenWrt SNAPSHOT, r34211-e95a7554c6 ----------------------------------------------------- === WARNING! ===================================== There is no root password defined on this device! Use the "passwd" command to set up a new password in order to prevent unauthorized SSH logins. -------------------------------------------------- root@OpenWrt:~#
